Startech VGA Video Extender over Cat5 (ST121 Series) ST121UTP

Features

Click to view full size

Click to view full size

Click to view full size

(Pictures are For Illustration Purposes Only)

Download Brochure

Startech's MPN:

ST121UTP

Extend and distribute a VGA signal to 2 local, and 2 remote displays over Cat5 or better cabling

Consists of 1 Base unit for the local display, and 1 Remote unit for the remote display (up to 2 monitors can be connected at each location)
Extends video cables by up to 500 ft. (150m)
Uses standard Category 5 straight-wired, twisted-pair, network patch cable for economical and reliable data transmission
Included mounting brackets

The ST121UTP VGA Video Extender over Cat5 allows you to extend your VGA video signal by up to 150 meters (500 feet) and connect up to 4 displays (2 local and 2 remote) from that single source. The ST121UTP is a bundled kit including both a local transmitter and a remote receiver unit, offering a complete solution for scenarios in which remote monitor displays are required.

The local unit features a single VGA input as well as two VGA outputs giving you the ability to view and split your source VGA signal to two independent displays locally. The VGA video signal is then sent over standard 4 pair Category 5 or better UTP cable to the remote unit which also features two additional VGA outputs giving you the freedom to display your VGA source on up to four monitors in total.

The included a mounting bracket for the ST121UTP receiver provides versatile mounting options such as a wall, desk or cabinet.

Backed by a StarTech.com 2-year warranty and free lifetime technical support.

The StarTech.com Advantage

Cost-effective VGA extension through non-proprietary network cabling
Optional installation bracket included, for a tidy and professional installation

Applications

Place the display in a convenient viewing area, while the system equipment is placed elsewhere in a clean and secure environment
Ideal for digital signage applications in financial, educational, and business sectors
Extend your display across harsh environment industrial sites
Perfect for video conferencing solutions in boardrooms and office settings
Optimize placement of your demo stations at tradeshows and in auditoriums

Warranty Information
Warranty	2 Years
Hardware
Audio	No
Cabling	Cat 5e UTP or better
Daisy-Chain	No
Ports	1
Performance
Max Distance	150 m / 500 ft
Supported Resolutions	1440x900 @ 150ft / 50m 1280x1024 @ 300ft / 100m 1024x768 @ 500ft / 150m
Connector(s)
Local Unit Connectors	1 - RJ-45 Female
	1 - VGA (15 pin, High Density D-Sub) Male
	2 - VGA (15 pin, High Density D-Sub) Female
Remote Unit Connectors	1 - RJ-45 Female
	2 - VGA (15 pin, High Density D-Sub) Female
Power
Center Tip Polarity	Positive
Output Current	0.6A
Output Voltage	9 DC
Power Consumption (In Watts)	5.4
Power Source	AC Adapter Included
Physical Characteristics
Color	Black
Enclosure Type	Aluminum
Product Height	0.8 in [20 mm]
Product Length	2.4 in [60 mm]
Product Weight	6.4 oz [181 g]
Product Width	3.3 in [83 mm]
Packaging Information
Shipping (Package) Weight	2.5 lb [1.1 kg]
What's in the Box
Included in Package	1 - Local VGA Extender Unit
	1 - Remote VGA Extender Unit
	1 - Mounting Bracket for Receiver (w/ screws)
	2 - Sets Rubber Feet
	2 - Power Adapter
	1 - Instruction Manual

VGA VIDEO EXTENDER OVER CAT5 (ST121 SERIES)

Brand Name: StarTech.com

Connectivity Technology: Wired

Maximum Operating Distance: 152.40 m

Media Type Supported: Twisted Pair

Number of Input Devices Supported: 1

Number of Network (RJ-45) Ports: 2

Number of Output Devices Supported: 4

Product Type: Video Extender Transmitter/Rec

Basic
Brand Name:	StarTech.com
Connectivity Technology:	Wired
Maximum Operating Distance:	152.40 m
Media Type Supported:	Twisted Pair
Number of Input Devices Supported:	1
Number of Network (RJ-45) Ports:	2
Number of Output Devices Supported:	4
Product Type:	Video Extender Transmitter/Rec

General Information
Brand Name:	StarTech.com
Manufacturer Part Number:	ST121UTP
Manufacturer Website Address:	http://www.startech.com/au
Manufacturer:	StarTech.com
Marketing Content:	The ST121UTP VGA Video Extender over Cat5 allows you to extend your VGA video signal by up to 150 meters (500 feet) and connect up to 4 displays (2 local and 2 remote) from that single source.
Product Name:	VGA Video Extender over CAT5 (ST121 Series)
Product Type:	Video Extender Transmitter/Receiver

Interfaces/Ports
Network (Rj-45):	Yes
Number of Network (RJ-45) Ports:	2

Media & Performance
Media Type Supported:	Twisted Pair
Twisted Pair Cable Standard:	Category 5e

Miscellaneous
Additional Information:	Cat5 extension design allows you to make use of existing Cat 5 or better wiring infrastructure Extends the connection distance of VGA displays by up to 500 feet (150 meters) offering flexibility in the placement of your equipment

Physical Characteristics
Depth:	59.9 mm
Height:	20.1 mm
Width:	83.1 mm

Technical Information
Connectivity Technology:	Wired
Maximum Operating Distance:	152.40 m
Number of Input Devices Supported:	1
Number of Output Devices Supported:	4

Video
Graphics Modes:	SXGA
Maximum Video Resolution:	1280 x 1024
