APC - Schneider APC SMART-UPS 3000VA LCD RM 2U 230V With Smartconnect SMT3000RMI2UC

APC/Schneider's MPN:

SMT3000RMI2UC

Basic


Backup/Run Time (Full Load):
3.20 Minute


Brand Name:
APC by Schneider Electric


Form Factor:
Rack-mountable


Hot Swappable:
Yes


Input Voltage Range:
160 V AC - 286 V AC


Input Voltage:
230 V AC


Load Capacity (Va):
3 kVA


Load Capacity (Watt):
2.70 kW


Network (Rj-45):
Yes


Product Family:
Smart-UPS


Product Type:
Line-interactive UPS


Rack Height:
2U


Receptacles:
1 x IEC 60320 C19
3 x IEC Jumper
8 x IEC 60320 C13


Waveform Type:
Sine Wave
Battery Information


Backup/Run Time (Full Load):
3.20 Minute


Hot Swappable:
Yes


Typical Battery Recharge Time:
3 Hour
General Information


Brand Name:
APC by Schneider Electric


Manufacturer Website Address:
http://www.schneider-electric.com.au


Manufacturer:
Schneider Electric SA


Product Line:
Smart-UPS


Product Name:
Smart-UPS 3kVA Rack-mountable UPS


Product Type:
Line-interactive UPS
Interfaces/Ports


Network (Rj-45):
Yes
Miscellaneous


Environmentally Friendly:
Yes
Physical Characteristics


Depth:
683 mm


Form Factor:
Rack-mountable


Height:
86 mm


Rack Height:
2U


Weight (Approximate):
44.28 kg


Width:
480 mm
Power Description


Input Voltage Range:
160 V AC - 286 V AC


Input Voltage:
230 V AC


Load Capacity:
3 kVA/2.70 kW


Output Voltage:
220 V AC
230 V AC
240 V AC


Waveform Type:
Sine Wave
Technical Information


Receptacles:
1 x IEC 60320 C19
3 x IEC Jumper
8 x IEC 60320 C13


Transfer Time: 10 ms
