Samsung SSD 883 Dct 2TB, 1.92TB V-NAND 3bit MLC, 2.5" 7mm, Sataiii 6 GB/s, R/W(Max) 550MB/s/520MB/s MZ-7LH1T9NE

MZ-7LH1T9NE

1920GB, Samsung V-NAND 3bit MLC, 2.5" 7mm, SATAIII 6 GB/s, R/W(Max) 560MB/s/520MB/s,98K/28K IOPS, 2,733TBW (1.3DWPD), MTBF: 2M hours, 3Years Warranty

Features

• SATA 3.3 compliant

• Form factor: 2.5” 7mmT

• Samsung V-NAND 3bit MLC

• Fully complies with ATA/ATAPI-7 Standard

• Support NCQ (up to 32 depth) command set

• Hardware based AES 256-bit Encryption

• Support TRIM Command

• RoHS compliant


Performance

• Data transfer rate

• Sequential Reads: up to 560 MB/s

• Sequential Writes: up to 520 MB/s

• Random 4KB Reads: up to 98 KIOPS

• Random 4KB Writes: up to 28 KIOPS

• IOPS consistency (4KB)

• Reads: 99%

• Writes: 90%

• Latency (4KB)

• Reads: up to 140us

• Write: up to 70us

• Quality of Service (99.99%)

• Read(4KB, QD1/QD32): 0.5ms/0.9ms

• Write(4KB, QD1/QD32): 0.3ms/3.2ms


Power

• Supply Voltage: +5V ± 5%

• Voltage Ripple/Noise (max.): 100mV p-p

• Active (Typ. Read/Write) up to 2.3W/3.6W

• Idle (Typ.) up to 1.3W

• Vibration

• Non-operating 20 G

• (20 ~ 2,000 Hz, Sweep Sine)

• 20min /axis on 3 axes,


Physical Dimension

• Width 100.20 ±0.25 mm

• Depth 69.85 ±0.25 mm

• Height 6.80 ± 0.20 mm

• Weight Up to 60 g


Reliability

• Endurance(TBW):

• 3,840 GB: 5,466 TB

• 1,920 GB: 2,733 TB

• 960 GB: 1,366 TB

• 480 GB: 683 TB

• 240 GB: 341 TB

• Non-Recoverable Read Error:

• 1sector per 1017 bits read

• MTBF: 2,000,000 hours
