Startech MA-SFP-1GB-TX 1000Base-T SFP Transceiver MASFP1GBTXST

MASFP1GBTXST

•
  Delivers reliable RJ45 Ethernet connections for 1000Base-T networks

•
  100% Cisco Meraki compatible, equivalent to the Cisco Meraki MA-SFP-1GB-TX

•
  Backed by lifetime warranty and free lifetime technical support

• •
    Meets or exceeds OEM specifications and MSA (Multi-Source Agreement) industry standards

  •
    RJ45 copper interface

  •
    Maximum distance of up to 100 m (328 ft.)

  •
    Maximum data rates up to 1000Mbps

  •
    Supports auto-negotiation

  •
    Hot-pluggable

  •
    This Cisco Meraki® compatible copper SFP is engineered by StarTech.com to deliver what you need most in your network connections: reliable performance. Built to exacting specifications and fully tested to ensure maximum performance, this high-quality Gb RJ45 copper SFP can be installed into Cisco Meraki networking devices that support the Cisco Meraki MA-SFP-1GB-TX transceiver module, as well as other major brands of networking equipment.


    The SFP transceiver provides 10Base-T / 100Base-TX / 1000Base-T throughput over a distance of up to 100 m (328 ft.) using a copper RJ-45 connection. It provides a dependable and cost-effective way to add, replace or upgrade a copper Ethernet port on your networking equipment, and it's backed by a lifetime warranty.


    Built for reliable network performance


    This Gigabit RJ45 copper SFP is manufactured by StarTech.com to meet or exceed OEM specifications and comply with the industry’s MSA (Multi-Source Agreement) standards. Committed to the highest standards of quality, StarTech.com provides an extensive range of networking products including copper and fiber network cards, fiber media converters, Ethernet switches and wireless products.


    Fully compatible with Cisco Meraki and other major brands


    This Gigabit Copper SFP is engineered to the highest quality standards and is 100% Cisco Meraki compatible, equivalent to the Cisco Meraki MA-SFP-1GB-TX transceiver. The StarTech.com transceiver is configured and fully tested to ensure it works seamlessly with Cisco Meraki or other major brands of networking equipment.


    You can be assured that the use of StarTech.com SFP products should not affect the warranty protection of your networking equipment.


    Convenient and scalable


    Delivering both convenience and scalability, this SFP is fully hot-pluggable, which enables you to install it without interrupting network traffic or having to reboot your equipment. It provides a versatile and convenient solution that’s compatible with a multitude of multi and single-port Gigabit Ethernet networking devices.


    Ideal for use in HP switches, routers and other networking equipment, the SFP provides reliable performance, enabling you to expand your network to remote segments cost-effectively. The SFP supports auto-negotiation, maximum distance of up to 100 m (328 ft.), and maximum data rates of up to 1000Mbps.


    You can count on MASFP1GBTXST for reliable performance, backed by a lifetime warranty and free lifetime technical support.

  • Warranty Information
    Warranty	Lifetime
    Hardware
    Industry Standards	IEEE 802.3 10BASE-T
    	IEEE 802.3ab 1000BASE-T
    	IEEE 802.3u 100BASE-TX
    Performance
    Auto MDIX	Yes
    Compatible Networks	10/100/1000 Mbps
    Fiber Operating Mode	Full-Duplex
    Max Transfer Distance	100 m (328 ft)
    Maximum Data Transfer Rate	1000 Mbps
    Connector(s)
    Local Unit Connectors	1 - RJ-45 Female
    Special Notes / Requirements
    System and Cable Requirements	MSA or Cisco Meraki compliant SFP port
    	For use in 1 Gigabit networking equipment and media converters
    Environmental
    Humidity	5~95% RH
    Operating Temperature	0°C to 70°C (32°F to 158°F)
    Storage Temperature	-40°C to 85°C (-40°F to 185°F)
    Physical Characteristics
    Color	Silver
    Enclosure Type	Aluminum
    Product Height	13.8 mm [0.5 in]
    Product Length	68 mm [2.7 in]
    Product Weight	35 g [1.2 oz]
    Product Width	13.7 mm [0.5 in]
    Packaging Information
    Shipping (Package) Weight	0.1 kg [0.1 lb]
    What's in the Box
    Included in Package	1 - SFP transceiver
