Startech Mini DisplayPort to HDMI Adapter - 4K 60Hz MDP2HD4K60S

Features

(Pictures are For Illustration Purposes Only)

Startech

pdf brochure downloadDownload Brochure

Startech's MPN:

MDP2HD4K60S




Connect your mDP computer to an HDMI display using this converter, which supports UHD resolutions up to 4K at 60Hz


  • Astonishing picture quality with support for UHD 4K resolution at 60Hz


  • Maximum portability with a compact, lightweight design


  • Hassle-free setup with an active Mini DisplayPort conversion


This Mini DisplayPort to HDMI® adapter lets you output HDMI video and audio from an mDP device, with support for Ultra HD 4K at 60Hz.


Astonishing picture quality with support for  Ultra HD 4K at 60 Hz


The adapter lets you harness the video capabilities that are built into your Mini DisplayPort connection, to deliver the astonishing quality of UHD to your 4K 60Hz display. This makes it easier for you to multitask while using multiple monitors to work on resource-demanding applications.


Unlike many 4K Mini DisplayPort to HDMI adapters that only support a 30Hz refresh rate, this adapter works with HDMI 2.0 displays that can deliver output resolutions of up to 3840 x 2160p at 60Hz. Support for HDMI 2.0 means this adapter can support bandwidth up to 18Gbps, making it an ideal solution for performing high-resolution tasks such as editing 4K video.


The adapter is backward compatible with 1080p displays, which ensures compatibility with lower resolution displays such as TVs or projectors around your home or office.


Ultimate portability with a compact, lightweight design


The compact video adapter is highly portable and lightweight. It’s the perfect accessory for your portable mDP devices, fitting easily into your laptop bag or carrying case.


The portable adapter is the perfect accessory for deployment with company computers, enabling your employees to interface with BYOD (Bring Your Own Device) HDMI applications around the office, such as working at a hot-desk with an HDMI display or sharing your laptop’s screen on a boardroom projector.


Hassle-free setup with an active adapter that features plug-and-play installation


To ensure compatibility with any Mini DisplayPort output, the mDP adapter offers active conversion. Active video conversion is required to maintain 4K resolutions when converting Mini DisplayPort to HDMI. An active mDP adapter is also ideal for outputting 1080p resolutions by ensuring compatibility with graphics cards that are not capable of outputting multi-mode DP++ signals, such as ATI Eyefinity™ cards.


For a hassle-free setup, the Mini DisplayPort to HDMI adapter allows for plug-and-play installation without any additional software or drivers.

Note: To achieve 4K resolution at 60 Hz a DisplayPort 1.2 output and an HDMI 2.0 display are required.


The MDP2HD4K60S is backed by a 2-year StarTech.com warranty and free lifetime technical support.


Applications
  • Connect your 4K 60Hz HDMI display to a Mini DisplayPort output port
  • Deploy this adapter with company laptops to ensure your employees can interface with BYOD displays around the office
  • Hassle-free setup with an active Mini DisplayPort conversion

Warranty Information

Warranty

2 Years

Hardware

Adapter Style

Adapter

Audio

Yes

Chipset ID

PS176-B0

Converter Type

Active

Industry Standards

DPCP (DisplayPort Content Protection)

HDCP 2.2 (High Definition Content Protection)

DisplayPort 1.2

HDMI 2.0

Ports

1

Performance

Audio Specifications

7.1 Surround Sound

Maximum Digital Resolutions

4K x 2K @ 60 Hz

Supported Resolutions

4k x 2K (Ultra HD) @ 60 Hz

1920x1200

1920x1080 (1080p)

1280x720 (720p)

Wide Screen Supported

Yes

Connector(s)

Connector A

1 - Mini-DisplayPort (20 pin) Male Input

Connector B

1 - HDMI (19 pin) Female Output

Special Notes / Requirements

Note

This video adapter is not compatible with cables that use RedMere™ technology.

Environmental

Humidity

-25°C to 85°C (77°F to 185°F) at 80% - 95%

Operating Temperature

5°C to 35°C (41°F to 95°F)

Storage Temperature

-25°C to 70°C (13°F to 149°F)

Physical Characteristics

Cable Length

5.8 in [148 mm]

Color

Black

Product Height

0.4 in [10 mm]

Product Length

6 in [152 mm]

Product Weight

0 lb [0 kg]

Product Width

0.9 in [22 mm]

Packaging Information

Shipping (Package) Weight

0.1 lb [0 kg]

What's in the Box

Included in Package

1 - Mini DisplayPort to HDMI adapter



Mini DisplayPort to HDMI Adapter - mDP to HDMI Converter - UHD 4K 60Hz - Connect your mDP computer to an HDMI display using this converterwhich supports Ultra HD resolutions


Brand Name: StarTech.com
Cable Length: 15.24 cm
Cable Type: HDMI/Mini DisplayPort
Colour: Black
Connector on First End: 1 x Mini DisplayPort Male Digi
Connector on Second End: 1 x HDMI Female Digital Audio/
Packaged Quantity: 1
Product Type: A/V Cable


Basic

Brand Name:

StarTech.com

Cable Length:

15.24 cm

Cable Type:

HDMI/Mini DisplayPort

Colour:

Black

Connector on First End:

1 x Mini DisplayPort Male Digi

Connector on Second End:

1 x HDMI Female Digital Audio/

Packaged Quantity:

1

Product Type:

A/V Cable
General Information

Brand Name:

StarTech.com

Manufacturer Part Number:

MDP2HD4K60S

Manufacturer Website Address:
http://www.startech.com/au

Manufacturer:

StarTech.com

Packaged Quantity:

1

Product Name:

Mini DisplayPort to HDMI Adapter - 4K mDP to HDMI Converter - UHD 4K 60Hz

Product Type:

A/V Cable
Physical Characteristics

Colour:

Black
Technical Information

Cable Length:

15.24 cm

Cable Type:

HDMI/Mini DisplayPort

Connector on First End:

1 x Mini DisplayPort Male Digital Audio/Video

Connector on Second End:

1 x HDMI Female Digital Audio/Video

Device Supported:

Audio/Video Device

Projector

Features:

Active

Lightweight

Supported Resolution:

3840 x 2160
