Startech CFast Card to SATA Adapter with 2.5" Housing CFAST2SAT25

Features

(Pictures are For Illustration Purposes Only)

Startech

Startech's MPN:

CFAST2SAT25




Convert your CFast card into a 2.5in SATA drive for faster data transfer


  • Make your CFast card work like a 2.5in SATA SSD


  • Supports SATA III with data transfer speeds of up to 6 Gbps


  • SATA and power combo connector (7 + 15 pin) - same as a 2.5" SATA hard drive


Now you can use your CFast™ memory card like a standard 2.5" SATA solid-state drive. This unique adapter lets you access and recover data from a CFast card through SATA at faster data transfer speeds.

Turn CFast into SATA with ease


This CFast to SATA adapter creates a permanent conversion from CFast to SATA for use inside small form factor or embedded solutions. The drive frame and the connector on the adapter mimic the exact size and connector location of a 2.5" SATA hard drive.


Standard 2.5" housing allows the converted card to be installed into a laptop or other standard mounting bracket. Once the CFast card is mounted inside this adapter, you can use it just like a 2.5" SATA drive - in your laptop, docking station, enclosure or desktop computer.

Access your data faster with SATA performance


Transfer data from your CFast card to your PC through SATA, with file transfer speeds of up to 6 Gbps. You can offload data from your DSLR cameras and camcorders, or transfer graphic design files, videos and other files from your CFast card.


Faster file transfer speeds means you'll spend less time waiting for file transfers to complete. The actual speed will depend on the speed of the CFast media.


Engineered with a durable protective housing, the CFAST2SAT25 adapter is backed by a StarTech.com 2-year warranty and free lifetime technical support.


Applications
  • Access and recover data from a CFAST card quickly through SATA
  • Offload data from high-end digital cameras and camcorders, or to transfer graphic design files and videos

Warranty Information

Warranty

2 Years

Hardware

Compatible Drive Types

CFast Type I, II

Drive Size

CFast (I/II Card)

Interface

SATA

Number of Drives

1

Supported Drive Height(s)

3.3mm

5mm

Performance

Insertion Rating

10,000

Maximum Data Transfer Rate

6 Gbps

Memory Media Type

CFast (I/II Card)

MTBF

50,000

RAID

No

Type and Rate

SATA III (6 Gbps)

Connector(s)

Drive Connectors

1 - CFast Data & Power Combo (7+17 pin) Plug

Host Connectors

1 - SATA Data & Power Combo (7+15 pin) Plug

Software

OS Compatibility

OS independent; No software or drivers required

Environmental

Humidity

5%~95% RH

Operating Temperature

0°C to 75°C (32°F to 167°F)

Storage Temperature

-40°C to 85°C (-40°F to 185°F)

Physical Characteristics

Color

Black & Silver

Enclosure Type

Steel and Plastic

Product Height

0.4 in [9.9 mm]

Product Length

3.9 in [99 mm]

Product Weight

1.9 oz [54 g]

Product Width

2.7 in [69 mm]

Packaging Information

Shipping (Package) Weight

0.2 lb [0.1 kg]

What's in the Box

Included in Package

1 - CFast card to SATA converter

1 - Assembly screw kit

1 - Quick install guide



CFast Card to SATA Converter - 2.5in Enclosure - CFAST Card to SATA Adapter - Supports SATA III (6 Gbps) - Install a CFast card into 2.5in SATA bay for high speed data transfer


Brand Name: StarTech.com
Colour: Black
Colour: Silver
Drive Interface: CompactFlash
Form Factor: Internal
Host Interface: Serial ATA/600
Number of 1.8" Bays: No
Number of 2.5" Bays: 1
Number of 2.5"/3.5" Bays: No
Number of 3.5" Bays: No
Number of 5.25" Bays: No
Number of Total Expansion Bays: 1
Product Type: Drive Bay Adapter


Basic

Brand Name:

StarTech.com

Colour:

Black

Silver

Drive Interface:

CompactFlash

Form Factor:

Internal

Host Interface:

Serial ATA/600

Number of 1.8" Bays:

No

Number of 2.5" Bays:

1

Number of 2.5"/3.5" Bays:

No

Number of 3.5" Bays:

No

Number of 5.25" Bays:

No

Number of Total Expansion Bays:

1

Product Type:

Drive Bay Adapter
General Information

Brand Name:

StarTech.com

Manufacturer Part Number:

CFAST2SAT25

Manufacturer Website Address:
http://www.startech.com/au

Manufacturer:

StarTech.com

Product Name:

CFast Card to SATA Adapter with 2.5" Housing - Supports SATA III (6 Gbps)

Product Type:

Drive Bay Adapter
I/O Expansions

Number of 1.8" Bays:

No

Number of 2.5" Bays:

1

Number of 2.5"/3.5" Bays:

No

Number of 3.5" Bays:

No

Number of 5.25" Bays:

No

Number of Total Expansion Bays:

1
Interfaces/Ports

Drive Interface:

CompactFlash

Host Interface:

Serial ATA/600
Physical Characteristics

Colour:

Black

Silver

Depth:

99.1 mm

Form Factor:

Internal

Height:

10.2 mm

Material:

Plastic


Weight (Approximate):

51 g

Width:

68.6 mm
