Startech 4 Bay Aluminum Trayless Hot Swap Mobile Rack Backplane for 3.5in SAS II/SATA III - 6 Gbps HDD HSB4SATSASBA

Features

Click to view full size

hsb4satsasba drive bays number sata image 2

Click to view full size

drives interface hard startech product image 2

Click to view full size

serial enclosure width data system image 2

Click to view full size

(Pictures are For Illustration Purposes Only)

Download Brochure

Startech's MPN:

HSB4SATSASBA

Connect and hot swap four 3.5in SATA III or SAS II hard drives to your computer system in three 5.25” bays, with support for transfer speeds up to 6 Gbps

Solid aluminum construction
Key lock design
Built-in fan
4 drive bay design

The HSB4SATSASBA Removable 4-drive Backplane makes inserting and removing drives fast and easy, by turning three 5.25" bays into a hot-swappable interface for up to four 3.5” SATA or SAS hard drives (HDD).

For added versatility, the hot swap bay can interface with SATA I/II/III and SAS I/II hard drives -- an ideal solution for enterprise system applications.

For a quick and secure method of installing and removing drives, the backplane features ejection levers and a key-lock design. To help prevent drive failure, the bay provides drive cooling with a built-in fan and excellent heat dissipation with a vented aluminum enclosure.

The HSB4SATSASBA is backed by a StarTech.com 2-year warranty and free lifetime technical support.

The StarTech.com Advantage

Delivers peak drive performance, with support for full SATA III/SAS II data transfer speeds up to 6Gbps
Flexible drive options with support for both SATA and SAS drive interfaces
Helps maintain ideal drive operating temperatures by maximizing heat dissipation and expelling built-up heat, with a vented aluminum housing and built-in fan

Applications

Imaging - for new system builds or configurations, use the hot swap bay in your master system to quickly copy the Windows OS to multiple blank hard drives
Add a hot-swap bay to a server or workstation computer that you can use as a removable backup solution
IT environments where you need to quickly insert/replace hard drives with no external HDD enclosure required
Onsite data backup as a secure alternative to cloud storage

Warranty Information
Warranty	2 Years
Hardware
Compatible Drive Types	SAS & SATA
Drive Installation	Removable
Drive Size	3.5in
Fan Bearing Type	Sleeve Bearing
Fan(s)	Yes
Fans	1 - 70 mm
Interface	SATA
	SAS
Key Lock	Yes
Number of Drives	4
Number of internal 3.5 inch bays	4
Performance
Max Drive Capacity	Currently tested with up to 6TB 7200 RPM hard drives
Maximum Data Transfer Rate	6 Gbit/s
Connector(s)
Drive Connectors	4 - SFF-8482 (29 pin, Data & Power, Internal SAS) Receptacle
Host Connectors	2 - SATA Power (15 pin) Receptacle
	4 - SATA (7 pin, Data) Receptacle
Software
OS Compatibility	OS independent; No software or drivers required
Special Notes / Requirements
System and Cable Requirements	Flammability Rating: UL94 - V0
Indicators
LED Indicators	1 - Power LED
	1 - Drive 1 Activity LED
	1 - Drive 2 Activity LED
	1 - Drive 3 Activity LED
	1 - Drive 4 Activity LED
Environmental
Humidity	5%~85% RH
Operating Temperature	0°C to 55°C (23°F to 95°F)
Storage Temperature	-20°C to 60°C (-4°F to 122°F)
Physical Characteristics
Product Height	4.9 in [124 mm]
Product Length	7.8 in [197 mm]
Product Weight	2.9 lb [1.3 kg]
Product Width	5.7 in [145 mm]
Packaging Information
Shipping (Package) Weight	3.5 lb [1.6 kg]
What's in the Box
Included in Package	1 - 4 Drive Trayless 3.5in SATA/SAS Mobile Rack
	8 - Installation screws
	2 - Drive bay keys
	4 - SATA cables
	1 - Instruction manual

4 Drive Bay Aluminum Trayless Hot Swap Mobile Rack Backplane with Fan & Lock for 3.5in SAS II / SATA III - 6 Gbps Hard Drive - 3 Bay 5.25in Mounted Mobile Rack Backplane

Brand Name: StarTech.com

Compatible Drive Bay Width: 5.25"

Drive Interface: Serial ATA/600

Form Factor: Internal

Host Interface: 6Gb/s SAS

Host Interface: Serial ATA/600

Number of 1.8" Bays: No

Number of 2.5" Bays: No

Number of 2.5"/3.5" Bays: No

Number of 3.5" Bays: 4

Number of 5.25" Bays: No

Number of Total Expansion Bays: 4

Product Type: Drive Enclosure

Basic
Brand Name:	StarTech.com
Compatible Drive Bay Width:	5.25"
Drive Interface:	Serial ATA/600
Form Factor:	Internal
Host Interface:	6Gb/s SAS
	Serial ATA/600
Number of 1.8" Bays:	No
Number of 2.5" Bays:	No
Number of 2.5"/3.5" Bays:	No
Number of 3.5" Bays:	4
Number of 5.25" Bays:	No
Number of Total Expansion Bays:	4
Product Type:	Drive Enclosure

General Information
Brand Name:	StarTech.com
Manufacturer Part Number:	HSB4SATSASBA
Manufacturer Website Address:	http://www.startech.com/au
Manufacturer:	StarTech.com
Product Name:	4 Drive Trayless 3.5in SATA/SAS Mobile Rack
Product Type:	Drive Enclosure

I/O Expansions
Number of 1.8" Bays:	No
Number of 2.5" Bays:	No
Number of 2.5"/3.5" Bays:	No
Number of 3.5" Bays:	4
Number of 5.25" Bays:	No
Number of Total Expansion Bays:	4

Interfaces/Ports
Drive Interface:	Serial ATA/600
Host Interface:	6Gb/s SAS
	Serial ATA/600

Physical Characteristics
Compatible Drive Bay Width:	5.25"
Cooling Fan:	Yes
Depth:	198.1 mm
Form Factor:	Internal
Height:	124.5 mm
Material:	Aluminium
Weight (Approximate):	119.1 g
Width:	144.8 mm

Technical Information
Number of Hard Drives Installed:	No
Number of Hard Drives Supported:	4
