Startech USB 3.0 SATA III Hard Drive Docking Station SSD / HDD with UASP SDOCKU33BV

Features

Click to view full size

Click to view full size

(Pictures are For Illustration Purposes Only)

Startech's MPN:

SDOCKU33BV

Dock your 2.5in or 3.5in SATA III SSDs/HDDs over USB 3.0 with UASP

Supports 2.5in and 3.5in form factor SATA hard drives (HDD) and solid state drives (SSD)
UASP Support (Attached SCSI Protocol Specification Revision 1.0)
Compatible with USB 3.0/2.0/1.1 (5 Gbps / 480 Mbps / 1.5 Mbps)

The SDOCKU33BV UASP-enabled USB 3.0 docking station makes it easy for you to connect and swap 2.5in or 3.5in SATA III hard drives (HDD) and solid state drives (SSD) through an available USB port. The dock performs up to 70% faster than conventional USB 3.0 when paired with a UASP-enabled host controller to utilize the full potential of your SATA III hard drives.

With support for large capacity SATA I/II/III drives (tested up to 4TB), and 2.5in or 3.5in drives this HDD/SSD docking station is compatible with virtually any SATA drive, and greatly increases the storage/backup capabilities of your computer.

Extend the value of this hard drive docking station further with the addition of our SATA to IDE Hard Drive Adapter (SAT2IDEADP), allowing easy insertion of any 2.5 or 3.5in IDE hard drive into a SATA hard drive dock.

To ensure compatibility with your computer system, the SDOCKU33BV supports all of the leading operating systems, including: Microsoft Windows® (8/7/Vista/XP/Server 2008/Server 2003), Apple® OSX (10.9/10.8/10.7/10.6), Linux, and Google Chrome OS™.

The SDOCKU33BV is backed by a 2-year StarTech.com warranty and free lifetime technical support.

Improved Performance with UASP

UASP is supported in Windows 8, Mac OSX (10.8 or above), and Linux. In testing, UASP performs with a 70% faster read speed and 40% faster write speed over traditional USB 3.0 at peak performance.

UASP Speed Diagram

At the same peak in testing UASP also shows an 80% reduction in required processor resources.

UASP Speed Diagram

Testing results were obtained using an Intel® Ivy Bridge system, a UASP-enabled StarTech.com Enclosure, and a SATA III solid state drive.

The StarTech.com Advantage

Save time, with file transfers up to 70% faster than traditional USB 3.0 when used with a UASP-supported host
Hassle-free access to drive data, with hot-swappable top slot-loading dock design that supports both 2.5in and 3.5in HDD/SSDs

Applications

Add quick access to drives for data recovery or retrieval.
Backup data quickly to an external data archiving
Test or benchmark different hard drives and swap between them
Quickly access drives for imaging

Warranty Information
Warranty	2 Years
Hardware
Chipset ID	ASMedia - ASM1053 - 6G
Compatible Drive Types	SATA
Drive Installation	Removable
Drive Size	2.5in & 3.5in
Fan(s)	No
Interface	USB 3.0
Number of Drives	1
Connector(s)
Drive Connectors	1 - SATA Data & Power Combo (7+15 pin) Receptacle
Host Connectors	1 - USB Type-B (9 pin) USB 3.0 Female
Software
Microsoft WHQL Certified	Yes
OS Compatibility	OS independent; No software or drivers required
Indicators
LED Indicators	1 - Power/Activity
Power
Input Voltage	100 ~ 240 AC
Output Voltage	12 DC
Power Source	AC Adapter Included
Environmental
Humidity	20%RH ~ 80%RH
Operating Temperature	5°C to 35°C (41°F to 95°F)
Storage Temperature	-20°C to 50°C (-4°F to 122°F)
Physical Characteristics
Color	Black
Product Height	2 in [52 mm]
Product Length	5.5 in [139 mm]
Product Weight	24.9 oz [704 g]
Product Width	3.6 in [91 mm]
Packaging Information
Shipping (Package) Weight	24.9 oz [704 g]
What's in the Box
Included in Package	1 - USB 3.0 SATA hard drive docking station
	1 - USB 3.0 Cable
	1 - Universal Power Adapter: comes ready for NA/EU/UK only when you buy in NA/EU/UK; comes ready for Australia and New Zealand only when you buy in Australia and New Zealand
	1 - Instruction Manual

USB 3.0 SATA III Hard Drive Docking Station SSD / HDD with UASP - 2.5/3.5 USB 3.0 SATA I/II/III SSD / HDD Dock Station with UASP - USB 3.0Hard Drive Dock - Black

Brand Name: StarTech.com

Drive Interface: Serial ATA/600

Form Factor: External

Host Interface: USB 3.0

Number of 1.8" Bays: No

Number of 2.5"/3.5" Bays: 1

Number of 5.25" Bays: No

Number of Total Expansion Bays: 1

Product Type: Drive Dock

Wireless LAN: No

Basic
Brand Name:	StarTech.com
Drive Interface:	Serial ATA/600
Form Factor:	External
Host Interface:	USB 3.0
Number of 1.8" Bays:	No
Number of 2.5"/3.5" Bays:	1
Number of 5.25" Bays:	No
Number of Total Expansion Bays:	1
Product Type:	Drive Dock
Wireless LAN:	No

General Information
Brand Name:	StarTech.com
Manufacturer Part Number:	SDOCKU33BV
Manufacturer Website Address:	http://www.startech.com/au
Manufacturer:	StarTech.com
Packaged Quantity:	1
Product Name:	USB 3.0 SATA III Hard Drive Docking Station SSD / HDD with UASP
Product Type:	Drive Dock

I/O Expansions
Number of 1.8" Bays:	No
Number of 2.5"/3.5" Bays:	1
Number of 5.25" Bays:	No
Number of Total Expansion Bays:	1

Interfaces/Ports
Drive Interface:	Serial ATA/600
Host Interface:	USB 3.0

Miscellaneous
Certifications & Standards:	FCC CE
Environmentally Friendly:	Yes
Platform Supported:	Mac
	PC

Network & Communication
Wireless LAN:	No

Physical Characteristics
Cooling Fan:	No
Form Factor:	External

Power Description
Input Voltage:	110 V AC
	220 V AC
Power Source:	AC Adapter

Information

SKU/Item No 559487

Vendor Part No SDOCKU33BV

UPC/EAN Number 065030855303
