Startech 4U 19in Steel Vertical Wall Mount Equipment Rack Bracket RK419WALLV

Features

(Pictures are For Illustration Purposes Only)

Startech

Startech's MPN:

RK419WALLV




Mount server, network or telecommunications devices vertically with this 4U wall-mountable rack


  • 4U Wallmount design


  • Equipment can be vertically wall mounted, or horizontally under a desk


  • TAA compliant for GSA Schedule purchases


The RK419WALLV 4U Wallmount Rack Bracket offers a versatile storage solution, allowing equipment (Network devices, power strips, patch panels) to be mounted vertically (flush with the wall) to save space. Alternatively, the 4U bracket can be installed under a desk for horizontal installation, making it easy to access installed equipment directly from your workspace. This TAA compliant product adheres to the requirements of the US Federal Trade Agreements Act (TAA), allowing government GSA Schedule purchases.


Perfect for SoHo (small office, home office) environments, the wallmount bracket offers space-saving installation for environments lacking the footprint space for a full size server equipment rack.


Suitable for mounting on virtually any wall/ceiling surface (e.g. drywall), the bracket mounting holes (used to mount to a wall or the desk underside) are positioned at exactly 16in apart, matching standard construction framework.


Constructed to EIA-310 19in rack standards, the wallmount bracket features a sturdy steel design and is backed by StarTech.com's Lifetime Warranty.


Need more storage space? StarTech.com also offers a 1U 19in Wallmount Bracket, a 2U 19in Wallmount Bracket and a 3U 19in Wallmount Bracket.


The StarTech.com Advantage
  • Save space by mounting IT or AV equipment directly to the wall
  • Quick and easy setup with the included cage screws and nuts for mounting equipment

Applications
  • Mount networking and telecommunication equipment flush against the wall
  • Mount KVM switches or workstations under a desk or work bench to free up work space
  • Ideal for small and medium businesses needing rack solutions

Warranty Information

Warranty

Lifetime

Hardware

Fan(s)

No

Frame Type

Open Frame

Front Door Type

Open

Industry Standards

EIA RS310-C

Rack Type

2-Post

U Height

4U

Wallmountable

Yes

Performance

Weight Capacity

125.3 lb [56.7 kg]

Special Notes / Requirements

Note

Package includes 1½” screws for mounting to wood surfaces, additional hardware will be required for other materials

Physical Characteristics

Color

Black

External Depth

7.6 in [193.5 mm]

External Height

5.9 in [151 mm]

External Width

19.8 in [504 mm]

Internal Width

17.7 in [450 mm]

Product Weight

37.4 oz [1060 g]

Packaging Information

Flat Pack

No

Shipping (Package) Weight

2.5 lb [1.1 kg]

What's in the Box

Included in Package

1 - Vertical Wall Mount Bracket

16 - Cage nuts and screws (16 Each)

6 - Self Tapping Wood Screws - 3/16" x 1 1/2"



4U 19in Steel Vertical Wall Mount Equipment Rack Bracket


Brand Name: StarTech.com
Device Supported: A/V Equipment
Product Type: Mounting Bracket


Basic

Brand Name:

StarTech.com

Device Supported:

A/V Equipment

Product Type:

Mounting Bracket
General Information

Brand Name:

StarTech.com

Manufacturer Part Number:

RK419WALLV

Manufacturer Website Address:
http://www.startech.com/au

Manufacturer:

StarTech.com

Packaged Quantity:

1

Product Model:

RK419WALLV

Product Name:

4U 19in Steel Vertical Wall Mount Equipment Rack Bracket

Product Type:

Mounting Bracket
Miscellaneous

Certifications & Standards:
  • CE
  • UL

Compatibility:
  • Network Device
  • Power Strip
  • Patch Panel

Environmental Certification:

RoHS

Environmentally Friendly:

Yes
Physical Characteristics

Colour:

Black

Depth:

19.4 cm

Height:

15.1 cm


Weight (Approximate):

1.06 kg

Width:

50.4 cm
Product Information

Device Supported:

A/V Equipment
Warranty

Limited Warranty:

2 Year
Print this page
Information
SKU/Item No559423
Vendor Part NoRK419WALLV
UPC/EAN Number065030834414
Our Stock **     (click for more info)
Price
$158.69
