Startech Vertical Wall-Mount Server Rack - Solid Steel - 6U RK619WALLV

Features

Startech

Startech's MPN:

RK619WALLV




Mount server, network or telecommunications devices vertically with this 6U wall-mountable rack


  • Save space in your office or server room by mounting IT or AV equipment vertically to a wall or horizontally under a desk or work bench


  • Hassle-free setup with wall-mount installation holes spaced 16 in. apart, matching standard construction framework


  • Easy equipment installation, with cage nuts and screws included


This wall-mount bracket provides 6U of storage space to vertically mount your equipment on the wall. The 6U wall-mount rack is EIA-310-D compliant to ensure compatibility with any 19” rack-mount equipment, such as your power strips, telecommunication, network and A/V devices.


Save space by mounting your equipment to the wall or other surface


The 6U rack optimizes your working space by mounting equipment to your wall instead of taking up desk space or other surface area. It's perfect for your SoHo (small office, home office) environment, server room or any other location where available space is limited.


Ensure a secure and hassle-free installation


The wall rack is constructed of solid steel to ensure a sturdy and safe mounting solution for your expensive, mission-critical equipment. Also, because the wall mounting holes are positioned 16”apart, it exactly matches standard drywall construction framework to ensure simple and secure wall-stud anchoring. Cage nuts and screws are also included with the wall-mount bracket, to save you the hassle of sourcing separate mounting hardware.


Customize your workspace with versatile installation options


To provide a suitable mounting solution for virtually any surface such as your wall, ceiling or desk, the 6U bracket features separate mounting patterns for both ceilings and walls. This means that you can mount the bracket vertically to your wall or horizontally to your ceiling or under your desk.


If you're looking for a mountable storage solution with fewer rack units, StarTech.com also offers a 1U wall-mount bracket, a 2U wall-mount bracket, a 3U wall-mount bracket and a 4U wall-mount bracket.


The RK619WALLV is backed by a StarTech.com lifetime warranty and free lifetime technical support.


Applications
  • Install networking and telecommunication equipment flush against the wall
  • Mount KVM switches or workstations under a desk or work bench to free up work space
  • Use in your small office environment where you can't comfortably fit a full-sized rack

Warranty Information

Warranty

Lifetime

Hardware

Fan(s)

No

Frame Type

Open Frame

Front Door Type

Open

Industry Standards

EIA RS310-C

Rack Type

2-Post

U Height

6U

Wallmountable

Yes

Performance

Weight Capacity

200.5 lb [90.7 kg]

Special Notes / Requirements

Note

Package includes 1½” screws for mounting to wood surfaces, additional hardware will be required for other materials

Physical Characteristics

Color

Black

External Depth

7.6 in [193.5 mm]

External Height

5.9 in [151 mm]

External Width

19.8 in [504 mm]

Internal Width

17.7 in [450 mm]

Product Height

5.9 in [150 mm]

Product Length

19.9 in [505 mm]

Product Weight

44.8 oz [1268 g]

Product Width

11 in [280 mm]

Packaging Information

Shipping (Package) Weight

3.3 lb [1.5 kg]

What's in the Box

Included in Package

1 - vertical wallmount bracket

16 - M5 cage nuts

16 - M5 screws with washers

6 - wood screws

1 - instruction manual



VERTICAL WALL-MOUNT SERVER RACK - SOLID STEEL - 6U


Brand Name: StarTech.com
Device Supported: A/V Equipment
Device Supported: KVM Switch
Device Supported: Power Strip
Device Supported: Server
Maximum Load Capacity: 56.84 kg
Product Type: Wall Mount


Basic

Brand Name:

StarTech.com

Device Supported:

A/V Equipment

KVM Switch

Power Strip

Server

Maximum Load Capacity:

56.84 kg

Product Type:

Wall Mount
General Information

Brand Name:

StarTech.com

Manufacturer Part Number:

RK619WALLV

Manufacturer Website Address:
http://www.startech.com/au

Manufacturer:

StarTech.com

Packaged Quantity:

1

Product Name:

6U 19-Inch Steel Vertical Rack and Wall Mountable Server Rack

Product Type:

Wall Mount
Miscellaneous

Application/Usage:

A/V Equipment

LAN Switch

Patch Panel

Server
Physical Characteristics

Colour:

Black

Depth:

19.3 cm

Height:

15 cm

Width:

50.3 cm
Product Information

Device Supported:

A/V Equipment

KVM Switch

Power Strip

Server

Maximum Load Capacity:

56.84 kg
