Startech 2U Vented Sliding Rack Shelf w/ Cable Management Arm & Adjustable Mounting Depth - 50lbs / 22.7kg UNISLDSHF192

Features

(Pictures are For Illustration Purposes Only)

Startech

Startech's MPN:

UNISLDSHF192




Add a vented, sliding shelf with integrated cable management into virtually any server rack or cabinet


  • Supports up to 50lbs (22.7kg)


  • Adjustable mounting depth from 27.7in (702.2mm) to 31.6in (802.2mm)


  • TAA compliant for GSA Schedule purchases


The UNISLDSHF192 Adjustable Sliding Rack Shelf lets you add a vented, sliding shelf with cable management into virtually any 4-post server rack or cabinet. This TAA compliant product adheres to the requirements of the US Federal Trade Agreements Act (TAA), allowing government GSA Schedule purchases.


The adjustable mounting depth design allows the shelf to be installed easily into server cabinets with mounting depths from 27.7in (702.2mm) to 31.6in (802.2mm). The sliding rails also offer a locking mechanism to stop the shelf from sliding out too far, or sliding back into the rack before maintenance is complete.


Offering a weight capacity of up to 50 lbs (22.7 kg), this sliding rack shelf features a ventilated, cold-rolled steel construction for increased airflow and durability in your server room or wiring closet installations.


For ease in routing cables neatly through your rack, we've included a reversible cable management arm that can be attached to the back of the shelf, plus an adjustable bezel to keep your equipment where you want it on the shelf.


Backed by a StarTech.com 2-year warranty.


The StarTech.com Advantage
  • Access equipment on the shelf easily with the simple sliding and locking mechanism
  • Mount into virtually any standard 4-post rack with adjustable mounting depth rails
  • Route cables neatly through your rack with the included cable management arm

Applications
  • Supply additional storage space for hardware or non-rackmount equipment and peripherals
  • Install into virtually any standard 4-post rack or cabinet

Warranty Information

Warranty

2 Years

Hardware

Industry Standards

EIA RS310-D

Mounting Options

Front Mount (Front and Rear)

U Height

2U

Performance

Weight Capacity

50.1 lb [22.7 kg]

Physical Characteristics

Color

Black

Enclosure Thickness

0.1 in [2 mm]

Enclosure Type

Steel

External Depth

24 in [609.6 mm]

External Height

3.4 in [85.2 mm]

External Width

19 in [483 mm]

Maximum Mounting Depth

31.6 in [802.2 mm]

Minimum Mounting Depth

27.6 in [702.2 mm]

Packaging Information

Shipping (Package) Weight

21.8 lb [9.9 kg]

What's in the Box

Included in Package

1 - Shelf Assembly

2 - Ear Hook and Slide Assembly (Left / Right)

2 - Ear Hook Bracket (Left / Right)

1 - Cable Management Assembly

1 - Instruction Manual



2U Vented Sliding Rack Shelf w/ Cable Management Arm & Adjustable Mounting Depth - 50lbs / 22.7kg


Application/Usage: Server
Brand Name: StarTech.com
Colour: Black
Depth: 609.6 mm
Form Factor: Rack-mountable
Height: 86.4 mm
Material: Steel
Product Type: Rack Shelf
Rack Depth: 802.64 mm
Rack Height: 2U
Width: 482.6 mm


Basic

Application/Usage:

Server

Brand Name:

StarTech.com

Colour:

Black

Depth:

609.6 mm

Form Factor:

Rack-mountable

Height:

86.4 mm

Material:

Steel

Product Type:

Rack Shelf

Rack Depth:

802.64 mm

Rack Height:

2U

Width:

482.6 mm
General Information

Brand Name:

StarTech.com

Manufacturer Part Number:

UNISLDSHF192

Manufacturer Website Address:
http://www.startech.com/au

Manufacturer:

StarTech.com

Product Name:

Rack Shelf

Product Type:

Rack Shelf
Physical Characteristics

Colour:

Black

Depth:

609.6 mm

Form Factor:

Rack-mountable

Height:

86.4 mm

Material:

Steel

Maximum Weight Capacity:

22.68 kg

Rack Depth:

802.64 mm

Rack Height:

2U

Width:

482.6 mm
Technical Information

Application/Usage:

Server

Features:

Cable Management
