Startech 2U Adjustable Mounting Depth Vented Sliding Rack Mount Shelf – 50lbs / 22.7kg UNISLDSHF19
Features
(Pictures are For Illustration Purposes Only)
Startech's MPN:
UNISLDSHF19
Increase peripheral and equipment accessibility with this vented sliding cabinet shelf
Constructed from 16 gauge cold rolled steel
Highly ventilated to reduce airflow impedance
TAA compliant for GSA Schedule purchases
The UNISLDSHF19 19in Vented Adjustable Mounting Depth Sliding Server Rack Cabinet Shelf offers a simple way to install non rack mountable equipment into a server cabinet or open server rack. This TAA compliant product adheres to the requirements of the US Federal Trade Agreements Act (TAA), allowing government GSA Schedule purchases.
Offering a weight capacity of up to 50 lbs (22.7 kg), the sliding rack shelf features a ventilated, cold-rolled steel shelf on two locking adjustable rails which allow the shelf to be installed into cabinets or racks with mounting depths from 20in (510mm) to 30in (744mm). The locking feature locks the shelf 3/4 of the way out, preventing the shelf from accidentally falling out of the rack or sliding back in before maintenance is complete.
Backed by a StarTech.com lifetime warranty.
The StarTech.com Advantage
Ventilated shelf design improves air flow and helps lower temperatures in the rack
Simple sliding and locking mechanism makes it easy to access anything even deep on the shelf
Adjustable rails offer compatibility with almost any server rack or cabinet
Applications
For use with all 19" wide Server Racks and Cabinets
Add a sliding rack mounting option for non rack mountable equipment
Warranty Information
Warranty
Lifetime
Hardware
Frame Type
Steel
Industry Standards
EIA RS310-C
U Height
2U
Performance
Weight Capacity
50.1 lb [22.7 kg]
Physical Characteristics
Color
Black
External Depth
24 in [610 mm]
External Height
3.5 in [88.6 mm]
External Width
18.9 in [480 mm]
Maximum Mounting Depth
29.3 in [744 mm]
Minimum Mounting Depth
20.1 in [510 mm]
Product Weight
9.1 lb [4.1 kg]
Packaging Information
Shipping (Package) Weight
296.5 oz [8400 g]
What's in the Box
Included in Package
1 - Sliding Shelf
8 - M6 Screws
8 - M6 Cage Nuts
2U Adjustable Mounting Depth Vented Sliding Rack Mount Shelf # 50lbs / 22.7kg
Brand Name : StarTech.com
Depth : 610.1 mm
Height : 88.6 mm
Material : Cold-rolled Steel (CRS) Frame
Product Type : Rack Shelf
Rack Height : 1U
Rack Width : 482.60 mm
Weight (Approximate) : 4.11 kg
Width : 480.1 mm
Basic
Brand Name:
StarTech.com
Depth:
610.1 mm
Height:
88.6 mm
Material:
Cold-rolled Steel (CRS) Frame
Product Type:
Rack Shelf
Rack Height:
1U
Rack Width:
482.60 mm
Weight (Approximate) :
4.11 kg
Width:
480.1 mm
General Information
Brand Name:
StarTech.com
Manufacturer Part Number:
UNISLDSHF19
Manufacturer Website Address:
http://www.startech.com/au
Manufacturer:
StarTech.com
Product Model:
UNISLDSHF19
Product Name:
19" Adjustable Sliding Server Rack Cabinet Shelf
Product Type:
Rack Shelf
Physical Characteristics
Depth:
610.1 mm
Height:
88.6 mm
Material:
Cold-rolled Steel (CRS) Frame
Maximum Weight Capacity:
22.68 kg
Rack Height:
1U
Rack Width:
482.60 mm
Weight (Approximate) :
4.11 kg
Width:
480.1 mm
Warranty
Limited Warranty:
2 Year
