Startech 16 Port 1U Rackmount USB KVM Switch Kit with OSD and Cables SV1631DUSBUK

Features

sv1631dusbuk cables product startech switch

Click to view full size

maximum control number supported computers

Click to view full size

Click to view full size

(Pictures are For Illustration Purposes Only)

Download Brochure

Startech's MPN:

SV1631DUSBUK

A complete 16-port USB KVM kit, including all necessary cables and accessories

Package includes 16x 6ft USB KVM cables
USB Keyboard and Mouse combo supported on 1 USB connection
Rugged, all metal 1U chassis for use in harsh environments and server cabinets

The SV1631DUSBUK 16 Port 1U Rack Mount USB KVM Switch Kit with OSD and Cables offers a well-appointed KVM switch that includes all of the cables and accessories required to connect to 16 servers or PCs right out of the box, making setup convenient and simple.

The USB KVM delivers a dependable computer management tool that allows you to control up to 16 USB-connected computers from a single keyboard, mouse and display, providing maximum control through hotkey command-based switching or front panel push-buttons, with the added configurability and convenience of an On-Screen Display.

A suitable addition to server room operations, the 16-port switch can be rackmounted into 1U of cabinet space and can be cascaded with multiple KVM switches to enable control of up to 136 computers from this single switch.

Backed by a StarTech.com 3-year warranty and free lifetime technical support.

The StarTech.com Advantage

For simple setup, the KVM cables to connect all 16 ports to servers and PCs are included in the box
Maximum compatibility with USB keyboard and mouse combos, and wireless setups; this unique KVM extracts the keyboard strokes from the USB connection ensuring your setup will work flawlessly
Rugged rack mountable metal chassis allows for versatility and durability in almost any environment

Applications

Effectively manage your server farms from a single console
Useful in Software QA labs where testing is being done across multiple platforms
Great for PC test/burn-in computer control, avoiding the cost of buying additional peripherals
Central control for multiple systems in a Datacenter
Systems management in Co-location/ISP facilities
Manufacturing line computer control and management

Warranty Information
Warranty	3 Years
Hardware
Audio	No
Cables Included	Yes
Daisy-Chain	Yes
KVM Ports	16
Number of Monitors Supported	1
PC Interface	USB
PC Video Type	VGA
Rack-Mountable	Yes
Performance
Hot-Key Selection	Yes
IP Control	No
Maximum Analog Resolutions	1920 x 1440@60Hz (1920 x 1200@60Hz - Wide Screen)
Maximum Cascaded Computers	136
Maximum Number of Users	1
On-Screen Display	Yes
Port Selection Support	Push Button, Hotkeys, and OSD (On Screen Display)
Wide Screen Supported	Yes
Connector(s)
Console Interface(s)	1 - VGA (15 pin, High Density D-Sub) Female
	2 - USB Type-A (4 pin) USB 2.0 Female
Host Connectors	16 - VGA (15 pin, High Density D-Sub) Female
Software
OS Compatibility	OS independent; No software or drivers required
Indicators
LED Indicators	1 - Green - Power
	16 - Green - PC Online
	16 - Red - PC Selected
Power
Center Tip Polarity	Positive
Input Voltage	110V-240V AC
Output Current	1A
Output Voltage	9 DC
Power Consumption (In Watts)	9
Power Source	AC Adapter Included
Environmental
Humidity	0~80% RH
Operating Temperature	5&degC to 40°C (41°F to 104°F)
Storage Temperature	-20&degC to 60°C (-4°F to 140°F)
Physical Characteristics
Color	Black
Enclosure Type	Steel
Product Depth	7.5 in [190 mm]
Product Height	1.8 in [45 mm]
Product Weight	84.4 oz [2390 g]
Product Width	17.3 in [440 mm]
Packaging Information
Shipping (Package) Weight	14.9 lb [6.7 kg]
What's in the Box
Included in Package	1 - 16-port USB KVM switch
	2 - mounting brackets
	16 - 6ft 2-in-1 USB VGA KVM cables
	1 - screw kit
	4 - foot pads
	1 - universal power adapter (NA/EU/UK/AU)
	1 - instruction manual

16 Port 1U Rackmount USB KVM Switch Kit with OSD and Cables

Brand Name: StarTech.com

Number of Computers Supported: 16

Product Type: KVM Switchbox

USB: Yes

VGA: Yes

Basic
Brand Name:	StarTech.com
Number of Computers Supported:	16
Product Type:	KVM Switchbox
USB:	Yes
VGA:	Yes

Camera
Maximum Video Resolution:	1920 x 1440

Display & Graphics
Maximum Video Resolution:	1920 x 1440

General Information
Brand Name:	StarTech.com
Manufacturer Part Number:	SV1631DUSBUK
Manufacturer Website Address:	http://www.startech.com/au
Manufacturer:	StarTech.com
Product Model:	SV1631DUSBUK
Product Name:	16 Port 1U Rack Mount USB KVM Switch Kit w/ OSD & Cables
Product Type:	KVM Switchbox

Interfaces/Ports
Number of USB Ports:	2
Number of VGA Ports:	1
USB:	Yes
VGA:	Yes

Miscellaneous
Form Factor:	Rack-mountable

Physical Characteristics
Form Factor:	Rack-mountable
Rack Height:	1U

Product Information
Form Factor:	Rack-mountable

Technical Information
Daisy Chain Supported:	Yes
Number of Computers Supported:	16
USB:	Yes

Video
Maximum Video Resolution:	1920 x 1440

Information

SKU/Item No 559338

Vendor Part No SV1631DUSBUK

UPC/EAN Number 065030840828

Our Stock ** (click for more info)

Price

$1,277.93
