Startech HDMI and DVI/VGA Dual-Monitor Docking Station for Laptops - USB 3.0 USB3SDOCKHDV

Features

Startech

pdf brochure downloadDownload Brochure

Startech's MPN:

USB3SDOCKHDV




Add HDMI and DVI-D, or HDMI and VGA dual-monitors, as well as audio and Gigabit Ethernet to your laptop through USB 3.0


  • Connect dual displays using either HDMI + DVI-D, or HDMI + VGA combinations


  • 10/100/1000 Mbps compatible RJ45 Ethernet port


  • Speaker and Microphone support via 3.5mm stereo mini-jacks


The USB3SDOCKHDV Dual Video Universal USB 3.0 Laptop Docking Station with Audio and Ethernet lets you add dual HD video outputs, as well as audio and Gigabit Ethernet connections to any notebook or Ultrabook™ computer through a single USB 3.0 connection.


This versatile USB 3.0 docking station features three external monitor outputs (HDMI, DVI-D and VGA) that can be used in either HDMI and DVI-D, or HDMI and VGA combinations to expand or mirror your desktop. Each video output supports HD video resolutions (2048x1152 max) and HD video playback for an ideal solution to expanding your notebook's video capability.


An all-in-one mobile solution, the universal docking station combines a USB 3.0 hub (backward compatible with USB 2.0/1.1), Gigabit Ethernet RJ45 and headphone and microphone audio connectors into a single universal port replicator, perfect for enhancing laptop connectivity.


With a range of convenient connections, the dock is ideal for hoteling in shared workspaces, and for hot desks.


Plus, unlike some proprietary docking stations designed only to work with specific laptop models, this universal laptop dock works with multiple brands. All you need is your laptop’s USB 3.0 port and you can be up and running quickly. With universal support, you can use this dock with different laptops now, or in the future.


Backed by a StarTech.com 3-year warranty and free lifetime technical support.


The StarTech.com Advantage
  • Save time by connecting multiple peripherals through a single cable
  • Increase available screen space with dual independent HD video outputs
  • Expand connectivity with additional USB 3.0 ports

Applications
  • Ideal for hoteling in shared workspaces, or for short-term hot desk applications
  • Turn a laptop into a multi-monitor workstation (up to 3 screens total) for increased productivity
  • Add dual video outputs to a laptop or small form factor computer, where the video card cannot be replaced
  • Connect a wide variety of peripherals at home/office to a laptop all from a single USB connection

Warranty Information

Warranty
3 Years

Hardware

4K Support
No

Bus Type
USB 3.0

Chipset ID
DisplayLink - DL-3900

Genesys - GL3520

Realtek - RTL8211E

Displays Supported
2

Fast-Charge Port(s)
No

Industry Standards
IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, USB 3.0

Performance

Audio Specifications
The HDMI port supports audio output

Auto MDIX
Yes

Compatible Networks
10/100/1000 Mbps

Full Duplex Support
Yes

Maximum Analog Resolutions
2048x1152 (VGA)

Maximum Data Transfer Rate
5 Gbps (USB 3.0)

2 Gbps (Ethernet; Full-Duplex)

Maximum Digital Resolutions
1920x1200 (DVI-D)

1920x1080 (HDMI)

Type and Rate
USB 3.0 - 5 Gbit/s

Connector(s)

Connector Type(s)
1 - DVI-D (25 pin) Female

1 - HDMI (19 pin) Female

1 - RJ-45 Female

1 - USB Type-B (9 pin) USB 3.0 Female

1 - VGA (15 pin, High Density D-Sub) Female

2 - 3.5 mm Mini-Jack (3 Position) Female

3 - USB Type-A (9 pin) USB 3.0 Female

Software

OS Compatibility
Windows® XP SP3 (32-bit), Vista, 7, 8, 8.1, 10

Mac OS® 10.6 to 10.12

Special Notes / Requirements

System and Cable Requirements
Available AC electrical outlet

HDMI (and either DVI-D or VGA if dual display is desired) enabled display device(s) e.g. monitor, projector, HTDV, etc. with cables

USB 3.0 enabled computer system with available USB 3.0 port

Power

Center Tip Polarity
Positive

Input Current
0.9 A

Input Voltage
100 ~ 240 AC

Output Current
4 A

Output Voltage
5 DC

Plug Type
B

Power Consumption (In Watts)
20

Power Source
AC Adapter Included

Environmental

Humidity
0~90% RH

Operating Temperature
0°C to 40°C (32°F to 104°F)

Storage Temperature
-10°C to 60°C (14°F to 140°F)

Physical Characteristics

Cable Length
3 ft [0.9 m]

Color
Black

Enclosure Type
Plastic

Product Height
1.7 in [44 mm]

Product Length
12 in [304 mm]

Product Weight
10.2 oz [289 g]

Product Width
7 in [178 mm]

Packaging Information

Shipping (Package) Weight
26.8 oz [760 g]

What's in the Box

Included in Package
1 - Docking Station

1 - 0.9m USB 3.0 Cable

1 - Universal Power Adapter (NA/EU/UK/AU)

1 - Installation CD

1 - Instruction Manual



Universal USB 3.0 Laptop Docking Station - Dual Video HDMI DVI VGA - Notebook / Ultrabook Docking Station - Universal LaptopDock - Dual Monitor Docking Station - Port Replicator


Brand Name: StarTech.com
Connectivity Technology: Wired
DVI: Yes
Device Supported: Notebook
HDMI: Yes
Microphone: Yes
Network (RJ-45): Yes
Number of USB 3.0 Ports: 3
Product Type: Docking Station
Total Number of USB Ports: 3
VGA: Yes


Audio

Headphone:
Yes

Microphone:
Yes
Basic

Brand Name:
StarTech.com

Connectivity Technology:
Wired

DVI:
Yes

Device Supported:
Notebook

HDMI:
Yes

Microphone:
Yes


Network (Rj-45):

Yes

Number of USB 3.0 Ports:
3

Product Type:
Docking Station

Total Number of USB Ports:
3

VGA:
Yes
Built-in Devices

Microphone:
Yes
General Information

Brand Name:
StarTech.com

Manufacturer Part Number:
USB3SDOCKHDV

Manufacturer Website Address: 		http://www.startech.com/au

Manufacturer:
StarTech.com

Product Name:
HDMI DVI VGA Dual Video Universal USB 3.0 Laptop Docking Station

Product Type:
Docking Station
Interfaces/Ports

DVI:
Yes

HDMI:
Yes

Headphone:
Yes

Host Interface:
USB

Microphone:
Yes


Network (Rj-45):

Yes

Number of USB 3.0 Ports:
3

Total Number of USB Ports:
3

VGA:
Yes
Lock

Cable Length:
90 cm
Media & Performance

Connectivity Technology:
Wired
Miscellaneous

Device Supported:
Notebook

Features:
Cable Lock Slot

Green Compliant:
Yes
Network & Communication

Connectivity Technology:
Wired
Physical Characteristics

Colour:
Black

Height:
34 mm

Length:
263 mm


Weight (Approximate):

289 g

Width:
87 mm
Product Information

Cable Length:
90 cm

Device Supported:
Notebook

Features:
Cable Lock Slot

Length:
263 mm

Width:
87 mm
Storage

Features:
Cable Lock Slot
Technical Information

Cable Length:
90 cm

Connectivity Technology:
Wired

Device Supported:
Notebook

Features:
Cable Lock Slot

Headphone:
Yes

Host Interface:
USB

Length:
263 mm

Microphone:
Yes
Wireless Specifications

Features:
Cable Lock Slot
