Startech HDMI and DVI Dual-Monitor Docking Station for Laptops - USB 3.0 USB3SDOCKHD

Features

Startech

pdf brochure downloadDownload Brochure

Startech's MPN:

USB3SDOCKHD




Add HDMI® and DVI video, as well as audio and Gigabit Ethernet connection ports to a laptop computer through a single USB 3.0 port


  • HDMI and DVI video output with DVI to VGA adapter included


  • 10/100/1000 Mbps compatible RJ45 Ethernet port


  • Speaker and Microphone support via 3.5mm stereo mini-jacks


The USB3SDOCKHD Universal USB 3.0 Laptop Docking Station with DVI, HDMI, Audio and Ethernet adds dual video outputs, headphone and microphone jacks, as well as Gigabit Ethernet and additional USB 3.0 and USB 2.0 ports to a laptop computer, all from a single device and over a single SuperSpeed USB 3.0 connection.


Offering flexible dual video combinations right out-of-the-box, this versatile universal docking station features HDMI and DVI external monitor outputs, as well as an included DVI to VGA adapter. Plus, each of the video outputs provided by the docking station supports video resolutions up to 1920x1200 and HD video playback - an ideal solution for adding robust video capability while remaining conveniently mobile.


An all-in-one mobile solution, the universal laptop docking station combines USB 2.0 and USB 3.0 hubs, headphone and microphone audio connectors and a Gigabit Ethernet RJ45 port into a single docking station, making it the perfect accessory for enhancing your laptop's capabilities.


With an upright design, the dock occupies minimal desk space, so it's perfect for hoteling or hot desk environments.


The USB3SDOCKHD is backed by a StarTech.com 3-year warranty and free lifetime technical support.


The StarTech.com Advantage
  • Flexible video output to extend or mirror your desktop at up to 1920x1200, with HDMI and DVI ports, plus included DVI to VGA adapter
  • USB 3.0 port replicator adds Gigabit Ethernet networking and audio (Headphone/Mic) from one device
  • The laptop docking station provides two additional USB 3.0 ports and four USB 2.0 ports to connect additional devices from a single USB 3.0 connection

Applications
  • Ideal for hoteling in shared workspaces, or for short-term hot desk applications
  • Add dual video outputs to a laptop or small form factor computer, where the video card cannot be replaced
  • Connect a wide variety of peripherals at home/office to a laptop and be able to instantly disconnect them all from a single USB connection
  • Turn a laptop into a multi-monitor workstation (up to 3 screens total) for increased productivity

Warranty Information

Warranty
3 Years

Hardware

4K Support
No

Bus Type
USB 3.0

Chipset ID
DisplayLink - DL-3900

VLI - VL810

Terminus - FE1.1

Realtek - RTL8211E

Displays Supported
2

Fast-Charge Port(s)
No

Industry Standards
IEEE 802.3, 802.3u, and 802.3ab

Performance

Auto MDIX
Yes

Compatible Networks
10/100/1000 Mbps

Full Duplex Support
Yes

Maximum Digital Resolutions
1920 x 1200

Type and Rate
USB 2.0 - 480 Mbit/s

USB 3.0 - 5 Gbit/s

Connector(s)

Connector Type(s)
1 - DVI-I (29 pin) Female

1 - HDMI (19 pin) Female

1 - RJ-45 Female

1 - USB Type-B (9 pin) USB 3.0 Female

2 - 3.5 mm Mini-Jack (3 Position) Female

2 - USB Type-A (9 pin) USB 3.0 Female

4 - USB Type-A (4 pin) USB 2.0 Female

Software

OS Compatibility
Windows® XP SP3 (32-bit), Vista, 7, 8, 8.1, 10

Mac OS® 10.6 to 10.12

Chrome OS v55+

Special Notes / Requirements

System and Cable Requirements

Cpu:
i3 Dual core 2.8GHz or better RAM: 2GB or higher Available USB 3.0 port

Indicators

LED Indicators
1 - Power (Blue)

1 - USB Hub Link (Blue)

Power

Input Current
0.8A

Input Voltage
100 ~ 240 AC

Output Current
4A

Output Voltage
5 DC

Plug Type
C

Power Consumption (In Watts)
20

Power Source
AC Adapter Included

Environmental

Operating Temperature
10°C to 40°C (50°F to 104°F)

Storage Temperature
-10°C to 80°C (14°F to 176°F)

Physical Characteristics

Color
Black

Enclosure Type
Plastic

Product Height
7.7 in [195 mm]

Product Length
4.9 in [125 mm]

Product Weight
12.8 oz [362 g]

Product Width
2.8 in [70 mm]

Packaging Information

Package Quantity
1

Shipping (Package) Weight
32.8 oz [929 g]

What's in the Box

Included in Package
1 - USB 3.0 Docking Station

1 - USB 3.0 Cable

1 - DVI to VGA Adapter

1 - Universal Power Adapter (NA/EU/UK/AU)

1 - Driver CD

1 - Instruction Manual



Universal USB 3.0 Laptop Docking Station Dual Video HDMI DVI w/ Audio Ethernet - Port Replicator Notebook Dock


Brand Name: StarTech.com
Connectivity Technology: Wired
DVI Out: Yes
DVI: Yes
Device Supported: Notebook
HDMI Out: Yes
HDMI: Yes
Microphone: Yes
Network (RJ-45): Yes
Number of USB 2.0 Ports: 4
Number of USB 3.0 Ports: 2
Product Type: Docking Station
Total Number of USB Ports: 6


Audio

Headphone:
Yes

Microphone:
Yes

Speakers:
Yes
Basic

Brand Name:
StarTech.com

Connectivity Technology:
Wired

DVI Out:
Yes

DVI:
Yes

Device Supported:
Notebook

HDMI Out:
Yes

HDMI:
Yes

Microphone:
Yes


Network (Rj-45):

Yes

Number of USB 2.0 Ports:
4

Number of USB 3.0 Ports:
2

Product Type:
Docking Station

Total Number of USB Ports:
6
Built-in Devices

Microphone:
Yes

Speakers:
Yes
General Information

Brand Name:
StarTech.com

Manufacturer Part Number:
USB3SDOCKHD

Manufacturer Website Address: 		http://www.startech.com/au

Manufacturer:
StarTech.com

Product Name:
Universal USB 3.0 Laptop Docking Station - Dual Video HDMI DVI w/ Audio Ethernet

Product Type:
Docking Station
Interfaces/Ports

DVI Out:
Yes

DVI:
Yes

HDMI Out:
Yes

HDMI:
Yes

Headphone:
Yes

Host Interface:
USB

Microphone:
Yes


Network (Rj-45):

Yes

Number of USB 2.0 Ports:
4

Number of USB 3.0 Ports:
2

Total Number of USB Ports:
6
Media & Performance

Connectivity Technology:
Wired
Miscellaneous

Additional Information:
  • Universal docking station adds dual independant external monitor outputs (HDMI, DVI) that can extend or mirror the desktop at up to 2048x1152
  • USB 3.0 port replicator adds Gigabit Ethernet networking and audio (Headphone/Mic) from one device
  • The laptop docking station provides two additional USB 3.0 ports and four USB 2.0 ports to connect additional devices from a single USB 3.0 connection

Device Supported:
Notebook

Green Compliant:
Yes
Network & Communication

Connectivity Technology:
Wired
Physical Characteristics

Colour:
Black

Height:
126.2 mm

Length:
195.8 mm


Weight (Approximate):

364.3 g

Width:
77 mm
Product Information

Device Supported:
Notebook

Length:
195.8 mm

Width:
77 mm
Technical Information

Connectivity Technology:
Wired

Device Supported:
Notebook

Headphone:
Yes

Host Interface:
USB

Length:
195.8 mm

Microphone:
Yes

Speakers:
Yes
