Startech 2-port HDMI splitter and signal amplifier ST122HDMI2

Features

Click to view full size

Click to view full size

startech product blu-ray information amplifier

Click to view full size

(Pictures are For Illustration Purposes Only)

Download Brochure

Startech's MPN:

ST122HDMI2

Split an HDMI® audio and video signal to two displays simultaneously

Splits an HDMI source signal to two displays, with no loss of signal quality
Supports resolutions up to 1080p (1920x1200)
Supports HDMI audio or separate 3.5mm stereo audio connection

The ST122HDMI2 2-Port High Speed HDMI® Splitter and Signal Amplifier lets you share a single HDMI source signal with audio between two HDMI or DVI (using HDMI to DVI adapter - see Accessories) enabled displays simultaneously.

Supporting True HD 1080p video resolutions, the HDMI splitter acts as a distribution amplifier that enables you to situate your HDMI-capable displays up to 50ft (15m) away from the splitter, and features 3.5mm audio connections, giving you the option of sending your accompanying audio signal through the HDMI cable, or through a separate channel.

The HDMI splitter is easy to install and use with no software or configuration required, for a completely plug-and-play setup that can be used with HDMI output devices such as Blu-ray players or desktop/laptop computers.

Backed by a StarTech.com 3-year warranty and free lifetime technical support.

The StarTech.com Advantage

Signal amplification distributes HDMI® signals without degradation or loss of signal quality
Support for High Speed HDMI ensures compatibility with the latest HDMI devices and features
Plug-and-play setup with no software or configuration allows you to be setup in minutes

Applications

Connect HDMI® enabled projectors, monitors, plasma screens, commercial billboards, and wall display systems
Ideal for business conference rooms and trade show displays
Great for digital signage applications displaying video advertisements with audio in retail environments
Perfect for classrooms and business multimedia presentations
Display information in waiting rooms or to patients in healthcare facilities
Financial applications, including stock tickers or promotion of new products/services

Warranty Information
Warranty	2 Years
Hardware
Audio	Yes
Ports	2
Performance
Maximum Cable Length	49.2 ft [15 m]
Maximum Digital Resolutions	HDTV 1080p PC Resolution 1920x1200
Wide Screen Supported	Yes
Connector(s)
Connector A	1 - 3.5 mm Mini-Jack (3 Position) Female
	1 - HDMI (19 pin) Female
Connector B	2 - 3.5 mm Mini-Jack (3 Position) Female
	2 - HDMI (19 pin) Female
Indicators
LED Indicators	3 - Port Power/Input - Green indicates connection, Blue indicates activity
Power
Center Tip Polarity	Positive
Input Voltage	Universal 115 ~ 230 AC
Output Current	2.6A
Output Voltage	5 DC
Power Consumption (In Watts)	13
Power Source	AC Adapter Included
Environmental
Humidity	0~80% RH
Operating Temperature	0°C to 40°C (32°F to 104°F)
Storage Temperature	-20°C to 60°C (-4°F to 140°F)
Physical Characteristics
Color	Black
Enclosure Type	Steel
Product Height	1 in [25 mm]
Product Length	7.2 in [183 mm]
Product Weight	13.4 oz [380 g]
Product Width	3.1 in [80 mm]
Packaging Information
Shipping (Package) Weight	1.5 lb [0.7 kg]
What's in the Box
Included in Package	1 - HDMI splitter
	1 - universal power adapter (NA / EU / UK / AU)
	1 - instruction manual

2 Port High Speed HDMI Video Splitter and Signal Amplifier

Brand Name: StarTech.com

Device Supported: Blu-ray Disc Player

Device Supported: Computer

HDMI In: Yes

HDMI Out: Yes

Maximum Operating Distance: 15 m

Number of Displays Supported: 2

Number of HDMI Inputs: 1

Number of Input Devices Supported: 1

Product Type: Audio/Video Switchbox

Basic
Brand Name:	StarTech.com
Device Supported:	Blu-ray Disc Player
	Computer
HDMI In:	Yes
HDMI Out:	Yes
Maximum Operating Distance:	15 m
Number of Displays Supported:	2
Number of HDMI Inputs:	1
Number of Input Devices Supported:	1
Product Type:	Audio/Video Switchbox

Camera
Maximum Video Resolution:	1920 x 1200

Display & Graphics
Graphics Modes:	WUXGA
Maximum Video Resolution:	1920 x 1200

General Information
Brand Name:	StarTech.com
Manufacturer Part Number:	ST122HDMI2
Manufacturer Website Address:	http://www.startech.com/au
Manufacturer:	StarTech.com
Packaged Quantity:	1
Product Name:	2-Port Hdmi Splitter And Signal Amplifier
Product Type:	Audio/Video Switchbox

Interfaces/Ports
Audio Line In:	Yes
Audio Line Out:	Yes
HDMI In:	Yes
HDMI Out:	Yes
Number of HDMI Inputs:	1
Number of HDMI Outputs:	2

Media & Performance
Maximum Operating Distance:	15 m

Miscellaneous
Device Supported:	Blu-ray Disc Player
	Computer
Green Compliant:	Yes

Physical Characteristics
Depth:	182.9 mm
Height:	25.4 mm
Weight (Approximate):	379.9 g
Width:	78.7 mm

Product Information
Device Supported:	Blu-ray Disc Player
	Computer
	Display
Number of Displays Supported:	2
Packaged Quantity:	1
Width:	78.7 mm

Technical Information
Device Supported:	Blu-ray Disc Player
	Computer
	Display
Maximum Operating Distance:	15 m
Number of Displays Supported:	2
Number of Input Devices Supported:	1
Scan Format:	1080p

Video
Graphics Modes:	WUXGA
Maximum Video Resolution:	1920 x 1200
Scan Format:	1080p

Information

SKU/Item No 557793

Vendor Part No ST122HDMI2

UPC/EAN Number 065030842457
