Startech Mini-SAS Adapter - Dual SFF-8643 to SFF-8644 - with Full and Low-Profile Brackets - 12Gbps SFF86448PLT2

Features

sff86448plt2 adapter sff-8643 sff-8644 mini-sas

Click to view full size

external product startech internal ports

Click to view full size

(Pictures are For Illustration Purposes Only)

Download Brochure

Startech's MPN:

SFF86448PLT2

Convert two internal SFF-8643 ports into two external SFF-8644 ports

Compatible with 12Gbps SAS drives and backward compatible with 6Gbps SAS and SATA drives
Equipped with a full-profile bracket and includes a half-height/low-profile bracket for installation in small form-factor computers

This Mini-SAS adapter lets you convert two internal SFF-8643 ports on a controller card into two external SFF-8644 ports. This enables you to connect external SAS or SATA drives in devices such as a Direct Attached Storage (DAS) device to an internal backplane or SAS controller for additional storage.

The adapter can connect up to eight drives in total and is compatible with 12Gbps SAS drives as well as 6Gbps SATA drives. For a hassle-free installation, you can mount the adapter into any new or legacy desktop expansion slot, including: PCI, AGP, and PCIe. To ensure compatibility with most computer cases, full-profile and low-profile mounting brackets are included.

The SFF86448PLT2 is backed by a StarTech.com 2-year warranty and free lifetime technical support.

Applications

Convert two internal SFF-8643 ports into two external SFF-8644 ports
Connect external SAS or SATA drives to an internal backplane or SAS controller

Warranty Information
Warranty	2 Years
Hardware
Ports	4
Performance
Supported Protocols	SATA and SAS
Connector(s)
Connector A	2 - SFF-8643 (36 pin, Internal HD Mini SAS) Receptacle
Connector B	2 - SFF-8644 (36 pin, External HD Mini SAS) Receptacle
Physical Characteristics
Product Height	0.9 in [22 mm]
Product Length	2.9 in [74 mm]
Product Weight	2 oz [58 g]
Product Width	4.7 in [120 mm]
Packaging Information
Shipping (Package) Weight	4.3 oz [121 g]
What's in the Box
Included in Package	1 - dual SFF-8643 to SFF-8644 Mini-SAS HD adapter
	1 - low-profile bracket

Mini-SAS Adapter - Dual SFF-8643 to SFF-8644 - with Full and Low-Profile Brackets - 12Gbps

Brand Name: StarTech.com

Product Type: Mini-SAS Card Adapter

Basic
Brand Name:	StarTech.com
Product Type:	Mini-SAS Card Adapter

General Information
Brand Name:	StarTech.com
Manufacturer Part Number:	SFF86448PLT2
Manufacturer Website Address:	http://www.startech.com/au
Manufacturer:	StarTech.com
Product Name:	Dual SFF-8643 to SFF-8644 Mini-SAS HD Adapter
Product Type:	Mini-SAS Card Adapter

Miscellaneous
Additional Information:	Hardware Ports: 4 Performance Supported Protocols: SATA and SAS Connector(s) Connector A: 2 - SFF-8643 (36 pin; Internal HD Mini SAS) Receptacle Connector B: 2 - SFF-8644 (36 pin; External HD Mini SAS) Receptacle
Environmental Certification:	RoHS
	WEEE
Environmentally Friendly:	Yes
Package Contents:	Dual SFF-8643 to SFF-8644 Mini-SAS HD Adapter 1 x Low-profile Bracket

Warranty
Limited Warranty:	2 Year

Information

SKU/Item No 553405

Vendor Part No SFF86448PLT2

UPC/EAN Number 065030866484
