Startech Internal Mini-SAS to SATA Cable - SFF-8643 to 4x SATA - 1 m SAS43SAT1M

Features

Click to view full size

Click to view full size

(Pictures are For Illustration Purposes Only)

Startech's MPN:

SAS43SAT1M

Connect a SAS controller to four SATA drives

Compatible with 6Gbps SATA drives
Cost-effective replacement cable
Guaranteed reliability with a lifetime warranty

This internal mini-SAS to SATA cable provides a cost-saving solution for connecting a SAS or SATA controller to four SATA drives. It’s the perfect replacement for your SFF data-storage cables.

The cable is compatible with 6Gbps SATA drives.

The SAS43SAT1M is backed by StarTech.com's lifetime warranty for guaranteed reliability.

Applications

Connect a SAS controller to four SATA drives

Warranty Information
Warranty	Lifetime
Hardware
Cable Jacket Type	PVC - Polyvinyl Chloride
Cable Shield Type	Aluminum-polyester foil
Connector(s)
Connector A	1 - SFF-8643 (36 pin, Internal HD Mini SAS) Latching Plug
Connector B	1 - SATA (7 pin, Data) Plug
Physical Characteristics
Cable Length	3.3 ft [1 m]
Color	Black & Silver
Connector Style	Straight
Product Length	3.3 ft [1 m]
Product Weight	1.5 oz [42 g]
Wire Gauge	30 AWG
Packaging Information
Shipping (Package) Weight	1.6 oz [46 g]
What's in the Box
Included in Package	1 - 1 m SFF-8643 to 4x SATA Cable

INTERNAL MINI-SAS TO SATA CABLE - SFF-8643 TO 4X SATA - 1 M

American Wire Gauge: 30 AWG

Brand Name: StarTech.com

Cable Length: 1.01 m

Cable Type: Mini-SAS HD/SATA

Colour: Silver

Connector on First End: 1 x Male SATA

Connector on Second End: 4 x SFF-8643 Male Mini-SAS HD

Packaged Quantity: 1

Product Type: Data Transfer Cable

Basic
American Wire Gauge:	30 AWG
Brand Name:	StarTech.com
Cable Length:	1.01 m
Cable Type:	Mini-SAS HD/SATA
Colour:	Silver
Connector on First End:	1 x Male SATA
Connector on Second End:	4 x SFF-8643 Male Mini-SAS HD
Packaged Quantity:	1
Product Type:	Data Transfer Cable

General Information
Brand Name:	StarTech.com
Manufacturer Part Number:	SAS43SAT1M
Manufacturer Website Address:	http://www.startech.com/au
Manufacturer:	StarTech.com
Packaged Quantity:	1
Product Name:	1m Internal Mini SAS to SATA Cable - SFF-8643 to 4x SATA
Product Type:	Data Transfer Cable

Physical Characteristics
Colour:	Black
	Silver

Technical Information
American Wire Gauge:	30 AWG
Cable Length:	1.01 m
Cable Type:	Mini-SAS HD/SATA
Connector on First End:	1 x Male SATA
Connector on Second End:	4 x SFF-8643 Male Mini-SAS HD
Device Supported:	SATA Controller
Features:	Locking Latch
Shielding:	Yes

Warranty
Limited Warranty:	Lifetime

Information

SKU/Item No 553404

Vendor Part No SAS43SAT1M

UPC/EAN Number 065030866095
