Startech 1-Port Gigabit Midspan - PoE+ Injector - 802.3at and 802.3af POEINJ1GW

Features

Startech

pdf brochure downloadDownload Brochure

Startech's MPN:

POEINJ1GW




Deliver power and data to your Power over Ethernet device using this mountable PoE+ midspan


  • Easily connect, power, and operate a Gigabit PoE-powered device (PD)


  • Supplies up to 30-watts power output


  • Flexible setup, with a desktop-sized, or surface-mountable housing


This Gigabit Power over Ethernet (PoE+) injector supplies power and data connectivity to a Gigabit PoE-compliant device using standard Ethernet cable, at distances of up to 100 m (330 ft.).


The PoE midspan is a cost-effective alternative to upgrading your existing network switch to a PoE-capable model.


Convenience and cost savings


This versatile PoE injector lets you connect a PoE-powered device (PD) to a non-PoE network switch, so you can avoid the expense and aggravation of replacing your existing switch with a PoE-enabled model. It supplies up to 30 watts of power, so you can easily power and access a high-power PoE-compliant device, such as an IP camera or a wireless access point (WAP), using traditional copper (RJ45) Ethernet cable. The midspan injector makes it easy to extend data and power connectivity to your PoE+ device across long distances, even in a remote location where a typical power outlet isn’t available.


Easy to set up in mixed environments


You can integrate this compact injector discreetly into a variety of environments. It features a surface-mountable housing that’s perfect for installing on walls or under a desk, but it’s also palm-sized, for use on desktop surfaces.


Plus, with plug-and-play operation, you can enjoy fast and hassle-free setup without disrupting your workflow.


Intelligent power allocation


Not sure which class your PoE device is? The Gigabit PoE+ injector automatically detects the power requirements of your connected PoE PD, and delivers the appropriate level of power without damaging your device.


The POEINJ1GW is backed by a StarTech.com 2-year warranty and free lifetime technical support.


Applications
  • Ideal for high-power PoE+ devices requiring Gigabit speeds such as PTZ (Pan, Tilt, Zoom) cameras and Wi-Fi® access points (WAP)
  • Enable remote installation of touchscreens, information kiosks, and phones in locations where a power connection isn’t available
  • Perfect for small and home offices, as well as SMB applications, including system integrations, and IT administration

Warranty Information

Warranty

2 Years

Hardware

Industry Standards

IEEE 802.3af PoE, IEEE 802.3at PoE+

IEEE 802.3 (10BASE-T), IEEE 802.3u (100BASE-TX), IEEE 802.3ab (1000BASE-T)

Ports

1

Performance

Maximum Cable Length

328 ft [100 m]

Maximum Data Transfer Rate

2 Gbps (Full-Duplex)

Power Output

48 V DC, 30 W

Connector(s)

Connector Type(s)

2 - RJ-45 Female

Special Notes / Requirements

Patents and Licenses

The following patents are licensed for this product. This list might not be all inclusive.

• United States Patent No. 5,406,260 (expired)

• United States Patent No. 6,650,622

• United States Patent No. 7,457,250

• United States Patent No. 8,155,012

• United States Patent No. 8,902,760

• United States Patent No. 8,942,107

• United States Patent No. 9,019,838

• United States Patent No. 9,049,019

• United States Patent Application No. 14/695,456

• United States Patent Application No. 14/726,940

System and Cable Requirements

If your connected devices do not meet the IEEE 802.3af or IEEE 802.3at PoE standard, then the POEINJ1GW will not inject power to the connected device(s) / Ethernet cable(s)

Indicators

LED Indicators

1 - Power

Power

Center Tip Polarity

Positive

Input Current

0.75 A

Input Voltage

100 ~ 240 AC

Output Current

0. 64 A

Output Voltage

56 DC

Plug Type

M

Power Consumption (In Watts)

36

Power Source

AC Adapter Included

Environmental

Humidity

10~90% RH (Non-Condensing)

Operating Temperature

0°C to 45°C (32°F to 113°F)

Storage Temperature

-20°C to 85°C (-4°F to 185°F)

Physical Characteristics

Color

Black

Enclosure Type

Plastic

Product Height

1 in [25 mm]

Product Length

2.8 in [70 mm]

Product Weight

1.8 oz [50 g]

Product Width

2.5 in [63 mm]

Packaging Information

Shipping (Package) Weight

2.3 lb [1 kg]

What's in the Box

Included in Package

1 - Gigabit midspan

4 - screws

1 - universal power adapter

3 - power cords (EU, UK, ANZ)

1 - quick-start guide



1-PORT GIGABIT MIDSPAN - POE+ INJECTOR - 802.3AT AND 802.3AF


Brand Name: StarTech.com
Colour: Black
Mount Type: Wall Mountable
Network Technology: 10/100/1000Base-T
Output Ports: 1
Product Type: PoE Injector


Basic

Brand Name:

StarTech.com

Colour:

Black

Mount Type:

Wall Mountable

Network Technology:

10/100/1000Base-T

Output Ports:

1

Product Type:

PoE Injector
General Information

Brand Name:

StarTech.com

Manufacturer Part Number:

POEINJ1GW

Manufacturer Website Address:
http://www.startech.com/au

Manufacturer:

StarTech.com

Packaged Quantity:

1

Product Name:

1-Port Gigabit Midspan - PoE+ Injector - 802.3at and 802.3af - Wall-Mountable

Product Type:

PoE Injector
Interfaces/Ports

Input Ports:

1 10/100/1000Base-T

Output Ports:

1 10/100/1000Base-T
Miscellaneous

Certifications & Standards:
  • C-Tick
  • FCC
  • CE
  • IEEE 802.3af PoE
  • IEEE 802.3at PoE+
  • IEEE 802.3 (10BASE-T)
  • IEEE 802.3u (100BASE-TX)
  • IEEE 802.3ab (1000BASE-T)

Compatibility:

StarTech NETRS2321POE Terminal & Device Server

Environmentally Friendly:

Yes
Physical Characteristics

Colour:

Black

Form Factor:

Desktop

Height:

25.4 mm

Length:

71.1 mm

Mount Type:

Wall Mountable


Weight (Approximate):

52 g

Width:

63.5 mm
Power Description

Input Voltage:

120 V AC

230 V AC

Maximum Input Current:

750 mA

Maximum Output Current:

640 mA

Maximum Output Power:

30 W

Maximum Output Voltage:

56 V DC
