Startech Gigabit 850nm Multi Mode SFP Fiber Optical Transceiver - LC 550m SFPSXMM

Features

sfpsxmm technology ethernet gigabit data

Click to view full size

Click to view full size

network 1000base-sx usage networking application

Click to view full size

information name product media mini-gbic

Click to view full size

(Pictures are For Illustration Purposes Only)

Download Brochure

Startech's MPN:

SFPSXMM

Add, replace or upgrade SFP modules on gigabit fiber equipment

1.25Gbps IEEE 802.3z 1000BASE-SX Compliant
Complies with SFP Multi-Source Agreements standards (MSA)
Equipped with a 850nm VCSEL Laser with Class 1 laser safety standards IEC825 compliance

The SFPSXMM Gigabit 850nm Multi Mode SFP Fiber Optical Transceiver - LC 550m is built to comply with MSA (Multi-Sourcing Agreement) standards to offer a cost-effective way to increase performance and connectivity of your fiber-connected network devices.

Using a short wavelength (850nm) VCSEL laser diode, enabling a maximum cable distance of 550m (0.3 miles) over multi mode fiber, this Small Form Factor Pluggable (SFP) Gigabit Multi Mode module can be installed into any fiber networking devices with an MSA compliant SFP port, providing a simple solution to upgrade existing network devices to connect to remote locations using LC terminated multimode fiber.

Delivering convenience and scalability, the optical transceiver allows you to install the multimode LC module without interrupting network traffic or requiring a device reboot.

Backed by a StarTech.com 2-year warranty and free lifetime technical support.

The StarTech.com Advantage

Fully compliant with MSA standards, this hot pluggable module can be installed into any networking device with an MSA compliant port
Equipped with an industry standard multimode LC interface, this module can extend your network connectivity up to 550m away

Applications

Perfect for network extension and fiber backbones
Replacing defective or damaged SFPs in MSA compliant equipment
Use in Multimode fiber installations
Expand your network to remote segments over fiber

Warranty Information
Warranty	2 Years
Hardware
Industry Standards	IEEE 802.3z 1000BASE-SX
Performance
Compatible Networks	1000 Mbps (1 Gbps)
DDM	No
Fiber Operating Mode	Full-Duplex
Fiber Type	Multi Mode
Max Transfer Distance	550 m (1804 ft)
Maximum Data Transfer Rate	1.25 Gbps
Wavelength	850nm
Connector(s)
Remote Unit Connectors	1 - Fiber Optic LC Duplex Female
Environmental
Humidity	5 to 95% RH
Operating Temperature	0°C to 70°C (32°F to 158°F)
Storage Temperature	-40°C to 85°C (-40°F to 85°F)
Physical Characteristics
Product Height	0.4 in [9 mm]
Product Length	2.2 in [55 mm]
Product Weight	0 lb [0 kg]
Product Width	0.5 in [13 mm]
Packaging Information
Shipping (Package) Weight	0.1 lb [0 kg]
What's in the Box
Included in Package	1 - SFP Multimode LC Transceiver

Gigabit 850nm Multi Mode SFP Fiber Optical Transceiver - LC 550m

Brand Name: StarTech.com

Ethernet Technology: Gigabit Ethernet

Interfaces/Ports Details: 1 x 1000Base-SX

Maximum Data Transfer Rate: 1

Media Type Supported: Optical Fiber

Network Technology: 1000Base-SX

Product Type: SFP (mini-GBIC)

Basic
Brand Name:	StarTech.com
Ethernet Technology:	Gigabit Ethernet
Interfaces/Ports Details:	1 x 1000Base-SX
Maximum Data Transfer Rate:	1
Media Type Supported:	Optical Fiber
Network Technology:	1000Base-SX
Product Type:	SFP (mini-GBIC)

Battery Information
Application/Usage:	Data Networking

General Information
Brand Name:	StarTech.com
Manufacturer Part Number:	SFPSXMM
Manufacturer Website Address:	http://www.startech.com/au
Manufacturer:	StarTech.com
Product Name:	Gigabit SFP (mini-GBIC) Fiber Optical Transceiver
Product Type:	SFP (mini-GBIC)

Interfaces/Ports
Ethernet Technology:	Gigabit Ethernet
Interfaces/Ports Details:	1 x 1000Base-SX

Media & Performance
Ethernet Technology:	Gigabit Ethernet
Fiber Mode Supported:	Multi-mode
Maximum Data Transfer Rate:	1
Media Type Supported:	Optical Fiber
Network Technology:	1000Base-SX

Miscellaneous
Additional Information:	Optical Wavelength: 850 nm Distance: 550m Compatibility: 3COM Cisco Lucent Nortel
Application/Usage:	Data Networking
Compatibility:	MSA compliant
Green Compliant:	Yes

Network & Communication
Ethernet Technology:	Gigabit Ethernet
Network Technology:	1000Base-SX

Network
Network Technology:	1000Base-SX

Physical Characteristics
Application/Usage:	Data Networking

Product Information
Application/Usage:	Data Networking
Compatibility:	MSA compliant

Technical Information
Application/Usage:	Data Networking
Ethernet Technology:	Gigabit Ethernet
Fiber Mode Supported:	Multi-mode
Maximum Data Transfer Rate:	1
Media Type Supported:	Optical Fiber

Information

SKU/Item No 543198

Vendor Part No SFPSXMM

UPC/EAN Number 065030834940
