Startech 2 Port HDMI Switch w/ Automatic and Priority Switching - 1080p VS221HDQ

Features

Startech

pdf brochure downloadDownload Brochure

Startech's MPN:

VS221HDQ




Discover hassle-free HDMI connection and automatic video port selection with high-definition picture quality


  • Auto switching


  • Priority switching


  • Built-in manual control console


  • EDID emulation


Save time and hassle by automatically switching between your HDMI audio/video sources, using the VS221HDQ 2-Port HDMI Auto Switcher. This easy-to-use HDMI switch ensures seamless transition while switching video sources, with EDID copy maintaining your video resolution.


Seamless Signal Selection


Ensure seamless transition while switching video sources, with EDID copy maintaining native resolution with support for 1080p. Video connection emulation ensures the settings on any connected computers are not disrupted while switching to a different video source.


Effortless Control


Save time by connecting two HDMI video source devices to your HDMI display instead of manually connecting individual cables. Mounting hardware is also included for a tidy, professional installation.


Versatile Switching Options


Enjoy hassle-free operation with three different switching modes:

Automatic port selection: Enables your most recently activated video source to be displayed automatically.

Priority port selection: Prioritizes input number two above input number one. If the video source connected to input number two is activated that source will be displayed.

Manual port selection: Enables you to manually select your HDMI source with easy-to-use front panel buttons.


The StarTech.com Advantage
  • Save your time, by conveniently accessing multiple HDMI source devices with a single HDMI display
  • Worry-free switching, with EDID copy video and connection emulation ensuring no signal loss
  • Hassle-free operation, with three video selection modes including automatic, priority, and manual

Applications
  • Automatically switch between your Blu-ray player, set top box, or gaming console in a home theatre environment
  • Connect and switch between two video sources on a test bench, for troubleshooting computers
  • Switch between different video sources on your digital signage display in hospitals, shopping centers, or schools

Warranty Information

Warranty
2 Years

Hardware

Audio
Yes

Cabling
HDMI

Output Signal
HDMI

Ports
2

Rack-Mountable
Yes

Performance

Audio Specifications
7.1 surround sound

Max Distance
10 m / 33 ft

Maximum Digital Resolutions
1920x1200 / 1080p

Supported Resolutions
1920x1200

1920x1080 (1080p)

1280x720 (720p)

Connector(s)

Connector A
2 - HDMI (19 pin) Female

Connector B
1 - HDMI (19 pin) Female

Indicators

LED Indicators
1 - Source #1 activated

1 - Source #2 activated

Power

Input Current
0.6 A

Input Voltage
100 ~ 240 AC

Output Current
1.5 A

Output Voltage
12 DC

Plug Type
M

Power Consumption (In Watts)
18

Power Source
AC Adapter Included

Environmental

Humidity
0%~80%

Operating Temperature
0°C to 40°C (32°F to 104°F)

Storage Temperature
-20°C to 60°C (-4°F to 140°F)

Physical Characteristics

Color
Black

Enclosure Type
Aluminum and Plastic

Product Height
0.8 in [20 mm]

Product Length
6.1 in [156 mm]

Product Weight
10.1 oz [285 g]

Product Width
2.6 in [65 mm]

Packaging Information

Shipping (Package) Weight
19.2 oz [545 g]

What's in the Box

Included in Package
1 - HDMI auto switch

1 - universal power adapter (NA, EU, UK, AU)

1 - remote control

1 - foot pad set

1 - mounting kit

1 - instruction Manual



2 Port HDMI Switch w/ Automatic and Priority Switching 2 In 1 Out HDMI Selector Box with Automatic Priority Port Switching 2 pt HDMI Auto Switch with Auto and Priority Selection


Brand Name: StarTech.com
Connectivity Technology: Cable
Device Supported: Blu-ray Disc Player
Device Supported: Display
Device Supported: Gaming Console
Device Supported: Set-top Box
Form Factor: Rack-mountable
HDMI In: Yes
HDMI Out: Yes
Maximum Operating Distance: 10 m
Number of Displays Supported: 1
Number of HDMI Inputs: 2
Number of Input Devices Supported: 2
Product Type: Audio/Video Switchbox


Basic

Brand Name:
StarTech.com

Connectivity Technology:
Cable

Device Supported:
Blu-ray Disc Player

Display

Gaming Console

Set-top Box

Form Factor:
Rack-mountable

HDMI In:
Yes

HDMI Out:
Yes

Maximum Operating Distance:
10 m

Number of Displays Supported:
1

Number of HDMI Inputs:
2

Number of Input Devices Supported:
2

Product Type:
Audio/Video Switchbox
General Information

Brand Name:
StarTech.com

Manufacturer Part Number:
VS221HDQ

Manufacturer Website Address: 		http://www.startech.com/au

Manufacturer:
StarTech.com

Packaged Quantity:
1

Product Name:
2 Port HDMI Switch w/ Automatic and Priority Switching - 1080p

Product Type:
Audio/Video Switchbox
Interfaces/Ports

HDMI In:
Yes

HDMI Out:
Yes

Number of HDMI Inputs:
2

Number of HDMI Outputs:
1
Media & Performance

Maximum Operating Distance:
10 m
Miscellaneous

Certifications & Standards:
  • CE
  • FCC

Environmentally Friendly:
Yes
Physical Characteristics

Colour:
Black

Depth:
156 mm

Form Factor:
Rack-mountable

Height:
20 mm

Material:
Aluminium

Plastic


Weight (Approximate):

285 g

Width:
65 mm
Power Description

Input Voltage:
110 V AC

12 V DC

220 V AC
Technical Information

Connectivity Technology:
Cable

Device Supported:
Blu-ray Disc Player

Display

Gaming Console

Set-top Box

Number of Displays Supported:
1

Number of Input Devices Supported:
2
Video

Graphics Modes:
Full HD

Maximum Video Resolution:
1920 x 1200
