Startech SATA Drive to mSATA Host Adapter for 2.5in / 3.5in SATA Drives MSAT2SAT3

Features

Click to view full size

Click to view full size

(Pictures are For Illustration Purposes Only)

Download Brochure

Startech's MPN:

MSAT2SAT3

Turn an mSATA host connection into a standard SATA port

Compliant with SATA revision I/II/III (1.5/3.0/6.0 Gbps)

The MSAT2SAT3 mSATA to SATA adapter enables you to connect a standard SATA drive to an available mSATA port.

The adapter improves system capacity by enabling an mSATA port to host a larger SATA hard drive (tested up to 4TB). For guaranteed compatibility and performance the adapter is compliant with SATA I/II/III revisions, allowing for transfer speeds up to 6Gb per second.

The MSAT2SAT3 is backed by a StarTech.com 2-year warranty and free lifetime technical support.

The StarTech.com Advantage

Improve system capacity by connecting a larger SATA hard drive to an mSATA host controller

Applications

Add a larger SATA hard drive to a system board that only supports mSATA
Turn an unused mSATA port into a supporting SATA port to connect a standard SATA hard drive

Warranty Information
Warranty	2 Years
Hardware
Compatible Drive Types	SATA
Drive Installation	Fixed
Drive Size	2.5in & 3.5in
Interface	Micro SATA
	SATA
Number of Drives	1
Performance
Max Drive Capacity	Currently tested with up to 4TB 7200 RPM hard drive
Type and Rate	SATA III (6 Gbps)
Connector(s)
Drive Connectors	1 - SATA (7 pin, Data) Receptacle
Host Connectors	1 - mSATA (52 pin, Mini SATA) Male
Software
OS Compatibility	OS independent; No software or drivers required
Environmental
Humidity	Operating 20% to 80% Non Operating 15% to 90%
Operating Temperature	5°C to 50°C (41°F to 122°F)
Storage Temperature	-25°C to 70°C (-13°F to 158°F)
Physical Characteristics
Product Height	0.3 in [8 mm]
Product Length	2 in [51 mm]
Product Weight	0.1 oz [4 g]
Product Width	1.2 in [30 mm]
Packaging Information
Shipping (Package) Weight	0 lb [0 kg]
What's in the Box
Included in Package	1 - mSATA to SATA Adapter
	1 - Screw kit
	1 - Installation Guide

mSATA to SATA HDD/SSD Adapter Mini SATA to SATA ConverterCard - mSATA to SATA 2.5/3.5 Hard Drive Adapter Converter Card - mSATA port to SATA port Adapter Converter Card

Brand Name: StarTech.com

Product Type: mSATA to SATA Adapter

Basic
Brand Name:	StarTech.com
Product Type:	mSATA to SATA Adapter

General Information
Brand Name:	StarTech.com
Manufacturer Part Number:	MSAT2SAT3
Manufacturer Website Address:	http://www.startech.com/au
Manufacturer:	StarTech.com
Packaged Quantity:	1
Product Name:	mSATA to SATA HDD / SSD Adapter - Mini SATA to SATA Converter Card
Product Type:	mSATA to SATA Adapter

Miscellaneous
Additional Information:	Improve system capacity by connecting a larger SATA hard drive to an mSATA host controller
Environmental Certification:	RoHS
Environmentally Friendly:	Yes
Package Contents:	mSATA to SATA HDD/SSD Adapter - Mini SATA to SATA Converter Card 1 x Screw Kit 1 x Installation Guide

Physical Characteristics
Height:	7.6 mm
Length:	50.8 mm
Weight (Approximate):	59.5 g
Width:	30.5 mm

Warranty
Limited Warranty:	2 Year

Information

SKU/Item No 537747

Vendor Part No MSAT2SAT3

UPC/EAN Number 065030854825
