Startech Gigabit Ethernet Multi Mode Fiber Media Converter SC 550m - 1000 Mbps ET91000SC2

Features

Click to view full size

Click to view full size

(Pictures are For Illustration Purposes Only)

Download Brochure

Startech's MPN:

ET91000SC2

Convert and extend a Gigabit Ethernet connection up to 550 m / 1804 ft over Multi Mode SC fiber

Supports standalone operation, or installation into the ETCHS2U Rackmount Chassis
Cost-effective way to extend/bridge networks using fiber cabling
Advanced features include Link-loss forwarding, remote monitor status, two frame lengths

The ET91000SC2 1000 Mbps Gigabit Multimode Fiber Media Converter (SC, 550m) lets you extend a Gigabit Ethernet network over multimode fiber, at distances up to 550m (1804 ft).

A cost-effective solution for connecting a Gigabit Ethernet (1000Base-T) network to remote network segments over a (1000Base-LX/SX) fiber backbone, the GbE to MM fiber converter supports full Gigabit speeds for ideal network performance and scalability. Designed to offer a durable and convenient Ethernet to fiber solution, this Ethernet to SC Fiber converter features an all-steel chassis, and a simple plug-and-play installation with minimal configuration required.

For added versatility, the fiber media converter supports standalone operation, or installation into the 20 Slot, 2U Rackmount Chassis (ETCHS2U).

Backed by a StarTech.com 2-year warranty and free lifetime technical support.

The StarTech.com Advantage

Link loss forwarding, remote status monitoring help ensure maximum up-time
Provides Ethernet to Fiber conversion as a standalone device, or can be installed into the ETCHS2U 20 slot chassis for added versatility
Rugged steel casing for durability in harsh environments

Applications

Provides network connectivity to users or network segments located in isolated areas of a large complex or separate building
Suitable for environments such as government agencies, where security threats (network tapping, etc.) need to be prevented
Connect traffic control/monitoring systems at extreme distances to the main office
Extend network connectivity to remote areas of stadiums, auditoriums or other venues
Converts 1000Base-LX fiber optic signals to 1000Base-T Ethernet over multimode fiber cable

Warranty Information
Warranty	2 Years
Hardware
PoE	No
WDM	No
Performance
Auto MDIX	Yes
Fiber Operating Mode	Half/Full-Duplex
Fiber Type	Multi Mode
Max Transfer Distance	550 m (1804 ft)
Maximum Data Transfer Rate	2000 Mbps (full duplex mode)
MTBF	65,000 Hours
Wavelength	850nm
Connector(s)
Local Unit Connectors	1 - Fiber Optic SC Duplex Female
	1 - RJ-45 Female
Power
Center Tip Polarity	Positive
Input Current	0.36A
Input Voltage	115V-230V AC
Output Current	1.6 A
Output Voltage	12 DC
Plug Type	M
Power Consumption (In Watts)	4
Power Source	AC Adapter Included
Environmental
Humidity	10~90% RH
Operating Temperature	0°C to 60°C (32°F to 140°F)
Storage Temperature	-10°C to 70°C (14°F to 158°F)
Physical Characteristics
Color	Black
Enclosure Type	Steel
Product Height	1 in [25 mm]
Product Length	5.9 in [150 mm]
Product Weight	19.8 oz [562 g]
Product Width	3.5 in [90 mm]
Packaging Information
Shipping (Package) Weight	1.9 lb [0.9 kg]
What's in the Box
Included in Package	1 - Fiber Media Converter
	1 - Universal Power Adapter: comes ready for NA/EU/UK only when you buy in NA/EU/UK; comes ready for Australia and New Zealand only when you buy in Australia and New Zealand
	1 - Instruction Manual

Gigabit Ethernet Multi Mode Fiber Media Converter SC 550m - 1000 Mbps

Brand Name: StarTech.com

DVI: No

Fiber Mode Supported: Multi-mode

Form Factor: Desktop

Form Factor: Rack-mountable

Maximum Distance Supported: 550 m

Media Type Supported: Optical Fiber

Media Type Supported: Twisted Pair

Network (RJ-45): Yes

Network Technology: 10/100/1000Base-T

Network Technology: 1000Base-SX/LX

Number of Network (RJ-45) Ports: 1

Number of SC Ports: 1

Product Type: Transceiver/Media Converter

Total Number of Ports: 2

USB: No

Basic
Brand Name:	StarTech.com
DVI:	No
Fiber Mode Supported:	Multi-mode
Form Factor:	Desktop
	Rack-mountable
Maximum Distance Supported:	550 m
Media Type Supported:	Optical Fiber
	Twisted Pair
Network (Rj-45):	Yes
Network Technology:	10/100/1000Base-T
	1000Base-SX/LX
Number of Network (RJ-45) Ports:	1
Number of SC Ports:	1
Product Type:	Transceiver/Media Converter
Total Number of Ports:	2
USB:	No

General Information
Brand Name:	StarTech.com
Manufacturer Part Number:	ET91000SC2
Manufacturer Website Address:	http://www.startech.com/au
Manufacturer:	StarTech.com
Packaged Quantity:	1
Product Name:	Gigabit Ethernet Multi Mode Fiber Media Converter SC 550m - 1000 Mbps
Product Type:	Transceiver/Media Converter

Interfaces/Ports
DVI:	No
Digital Audio/Video:	No
Digital Audio:	No
Management Port:	No
Network (Rj-45):	Yes
Number of Network (RJ-45) Ports:	1
Number of SC Ports:	1
Parallel Port:	No
Total Number of Ports:	2
USB:	No

Media & Performance
Fiber Mode Supported:	Multi-mode
Maximum Distance Supported:	550 m
Media Type Supported:	Optical Fiber
	Twisted Pair
Network Technology:	10/100/1000Base-T

Miscellaneous
Certifications & Standards:	IEEE 802.3 IEEE 802.3u IEEE 802.3ab FC FCC
Compatibility:	ETCHS2U Rackmount Chassis
Form Factor:	Desktop
Green Compliant:	Yes

Network & Communication
Network Technology:	10/100/1000Base-T

Network
Network Technology:	10/100/1000Base-T
	1000Base-SX/LX

Physical Characteristics
Colour:	Black
Depth:	160 mm
Form Factor:	Desktop
	Rack-mountable
Height:	20.3 mm
Weight (Approximate):	601 g
Width:	94 mm

Power Description
Input Voltage:	12 V DC

Product Information
Compatibility:	ETCHS2U Rackmount Chassis
Form Factor:	Desktop
	Rack-mountable
Packaged Quantity:	1
Width:	94 mm

Technical Information
Fiber Mode Supported:	Multi-mode
Media Type Supported:	Twisted Pair
Number of Network (RJ-45) Ports:	1
Number of SC Ports:	1
USB:	No

Information

SKU/Item No 537282

Vendor Part No ET91000SC2

UPC/EAN Number 065030846233
