Startech 1-Port Gigabit PoE+ Extender - 802.3at and 802.3af - 100 m (330 ft) POEEXT1GAT

Features

Startech

pdf brochure downloadDownload Brochure

Startech's MPN:

POEEXT1GAT




Scale your Power over Ethernet connection by 100m, or daisy chain up to four extenders for longer distance


  • Deploy and access your Gigabit PoE-powered devices (PD) further away


  • Extend your PoE PDs over longer distances by daisy-chaining four extenders up to 500m (1640ft) total range (reduced power output at each connection)


  • Compact, wall-mountable, and rugged metal housing for convenience and reliability


This Gigabit PoE+ extender spans your Power over Ethernet (PoE) device over longer distances, letting you double the 100m limitations of a traditional PoE infrastructure.

Diagram showing the extender connected to a PoE switch and a PoE access point over a long distance


Now you can connect your Gigabit PoE device up to a maximum of 200m away, so it’s easy to install a remote IP camera or access point. Plus the extender can be daisy-chained for more scalability.


Unrestricted PoE+ range and convenience


Need more distance? This convenient PoE+ repeater maximizes range and flexibility by extending your PoE connection by an extra 100m (330ft), while providing 24-watt power output to compatible devices.


Simply connect the extender to your power sourcing equipment (PSE) and your PoE-powered device (PD) and you’re all set. The extender is compliant with the 802.3at/af standard, so it will work with existing PSE, such as a StarTech.com PoE+ injector (POEINJ1G) or PoE+ switch (IES81000POE).


Daisy chain for longer distance and flexibility


Still need more distance? If an extra 100m isn’t enough, this full-featured PoE extender offers daisy chain capability.


You can easily connect four extenders together, letting you install your PoE+ PD up to 500m (1640ft) away. It’s perfect for business, education, and retail environments (output wattage is dependent on the number of daisy-chained extenders used).

Diagram showing four PoE extenders in a daisy chain configuration and connected to a PoE injector and IP phone


Convenient installation options and durable construction


Get up and running quickly. This Gigabit PoE+ extender can be positioned right where you need it, with a wall-mountable design that requires no external power adapter.


You can enjoy reliable performance with little worry of downtime or failure, the extender features a rugged metal housing with built-in ESD and surge protection.


The POEEXT1GAT is backed by a StarTech.com 2-year warranty and free lifetime technical support.


Applications
  • Ideal for Wi-Fi® access points, IP phones, surveillance cameras, and kiosks where a power connection is not available
  • Enable remote installation of PoE+ devices over longer distance than conventional PoE range capabilities
  • Perfect for SOHO, SMB, system integrators, and IT administrators

Warranty Information

Warranty
2 Years

Hardware

Industry Standards
IEEE 802.3af PoE, IEEE 802.3at PoE+

IEEE 802.3 10BASE-T, IEEE 802.3u 100BASE-TX, IEEE 802.3ab 1000BASE-T

Ports
1

Performance

Auto MDIX
Yes

Auto-Negotiation
Yes

Compatible Networks
10/100/1000 Mbps

Flow Control
Half-duplex back-pressure

IEEE 802.3x pause frame for full-duplex

Full Duplex Support
Yes

Jumbo Frame Support
No

Maximum Cable Length
328 ft [100 m]

Maximum Data Transfer Rate
2 Gbps (Full-Duplex)

MTBF
50,000 Hours

Power Output
One extender - 24W


Power Output:
Two extender daisy chain - 20W


Power Output:
Three extender daisy chain - 16W


Power Output:
Four extender daisy chain - 12W

Surge Protection
EN61000-4-2 (ESD) - 2kV

EN61000-4-5 (Surge) - 2kV

Switching Architecture
Store-and-Forward

Connector(s)

Connector Type(s)
2 - RJ-45 Female

Special Notes / Requirements

Note
Total extension distances can often be shorter due to power delivery voltage-drop on the connected cables. Maximum distances can vary based on the quality of the UTP cables and the environment.

You may daisy chain up to 4 POEEXT1GAT units total, for a maximum of 500m. The 4th unit will supply IEEE 802.3af up to 12W output.

Patents and Licenses
The following patents are licensed for this product. This list might not be all inclusive.

• United States Patent No. 5,406,260 (expired)

• United States Patent No. 6,650,622

• United States Patent No. 7,457,250

• United States Patent No. 8,155,012

• United States Patent No. 8,902,760

• United States Patent No. 8,942,107

• United States Patent No. 9,019,838

• United States Patent No. 9,049,019

• United States Patent Application No. 14/695,456

• United States Patent Application No. 14/726,940

System and Cable Requirements
If your connected device does not meet the IEEE 802.3af or IEEE 802.3at PoE standard, then the POEEXT1GAT will not pass-through power to the connected device / Ethernet cable.

Indicators

LED Indicators
1 - PoE IN

1 - LNK/ACT

1 - PoE OUT

Power

Output Voltage
52 ~ 56 DC

Power Consumption (In Watts)
3.2 W Max

Power Source
PoE-Powered

Environmental

Humidity
5~95% RH (Non-Condensing)

Operating Temperature
0°C to 50°C (32°F to 122°F)

Storage Temperature
-10°C to 85°C (14°F to 185°F)

Physical Characteristics

Color
Black

Enclosure Type
Steel

Product Height
1 in [25 mm]

Product Length
3.7 in [94 mm]

Product Weight
6.6 oz [188 g]

Product Width
2.7 in [69 mm]

Packaging Information

Shipping (Package) Weight
12 oz [339 g]

What's in the Box

Included in Package
1 - Gigabit Power over Ethernet extender

1 - instruction manual



Gigabit PoE+ Extender - 802.3at/af - 100m (330ft) - Power over Ethernet Extender - PoE Repeater Network Extender - Compact and Wall-Mountable Range Extender


Brand Name: StarTech.com
Product Type: Network Extender


Basic

Brand Name:
StarTech.com

Product Type:
Network Extender
General Information

Brand Name:
StarTech.com

Manufacturer Part Number:
POEEXT1GAT

Manufacturer Website Address: 		http://www.startech.com/au

Manufacturer:
StarTech.com

Packaged Quantity:
1

Product Name:
Network Extender

Product Type:
Network Extender
Miscellaneous

Additional Information:
  • Color: Black
  • Enclosure Type: Steel
  • Input Voltage: 52 ~ 56 DC
  • Power Consumption: 3.2 W Max
  • Connector Type(s): 2 - RJ-45 Female
  • MTBF: 50,000 Hours
  • Compatible Networks: 10/100/1000 Mbps
  • Flow Control: Half-duplex back-pressure, IEEE 802.3x pause frame for full-duplex
  • Maximum Cable Length: 328 ft [100 m]
Physical Characteristics

Height:
26 mm

Length:
70 mm


Weight (Approximate):

197 g

Width:
94 mm
Warranty

Limited Warranty:
2 Year
