Startech Dual Port PCI Express (PCIe x4) Gigabit Ethernet Server Adapter Network Card - Intel i350 NIC ST2000SPEXI

Features

Startech

pdf brochure downloadDownload Brochure

Startech's MPN:

ST2000SPEXI




Add dual Gigabit Ethernet ports to a client, server or workstation through a PCI Express slot


  • Two 10/100/1000Mbps compatible RJ-45 Ethernet ports


  • Fully Compliant with IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE802.3ad (link aggregation) and supports IEEE 802.1Q VLAN tagging


  • Jumbo Frame support up to 9k bytes


The ST2000SPEXI PCI Express Dual Port Gigabit Network Card lets you add two gigabit Ethernet ports to a desktop computer through a single, four-lane (x4 or higher)PCI Express slot.Each port is fully compatible with IEEE 802.3/u/ab standards, for 10/100/1000 Mbps auto-negotiation.


This 2-port GbE network card is based on the high-performance Intel® I350 chipset, which offers several advanced driver options including IEEE 802.3ad link aggregation / teaming support, enabling you to add additional bandwidth to your system. Support for Jumbo Frames, full-duplex operation and 802.1q VLAN tagging also aid in creating an efficient network configuration.


Also useful for virtualization applications (check your VM software for chipset compatibility) or setting up a dual-homed host configuration, this dual-port network card lets you accommodate several complex network scenarios, to meet your business needs. For added versatility, the controller card is equipped with a standard profile bracket and includes a low-profile/half-height bracket for installation in small form-factor computers.


Backed by a StarTech.com 2-year warranty and free lifetime technical support.


The StarTech.com Advantage
  • Double the network bandwidth to a single system through link aggregation / teaming support
  • Optimize network traffic with support for advanced features such as Jumbo Frames and VLAN tagging
  • Maximize your virtualized server networking efficiency with dedicated ports

Applications
  • Ideal for VM environments with multiple operating systems, requiring shared or dedicated NICs
  • Provide redundant connectivity to ensure an uninterrupted network connection
  • Configure a dual-homed proxy or gateway system for an added layer of security
  • Specially designed for desktop PC clients, servers, and workstations with few PCI Express slots available

Warranty Information

Warranty
2 Years

Hardware

Bus Type
PCI Express

Card Type
Standard Profile (LP bracket incl.)

Chipset ID
Intel - I350-AM2

Industry Standards
IEEE 802.3, IEEE 802.3u, IEEE 802.3ab

PCI Express Base Specification 2.1

Interface
RJ45 (Gigabit Ethernet)

Port Style
Integrated on Card

Ports
2

Performance

Auto MDIX
Yes

Compatible Networks
10/100/1000 Mbps

Full Duplex Support
Yes

Jumbo Frame Support
9K max.

Maximum Data Transfer Rate
2000 Mbps (full-duplex), 1000 Mbps (half-duplex)

Promiscuous Mode
Yes

Supported Protocols
IEEE 802.3ad (link aggregation), IEEE 1588 (time sync) / 802.1AS, IEEE 802.1q (VLAN tagging)

Connector(s)

Connector Type(s)
1 - PCI Express x4 Male

External Ports
2 - RJ-45 Female

Software

OS Compatibility
Windows® 7, 8, 8.1, 10

Windows Server® 2008 R2, 2012, 2012 R2, 2016

Linux 2.4.x to 4.4.x LTS versions only

Special Notes / Requirements

Note
Creating Intel® ANS teams and VLANs on Microsoft Windows® 10 is currently not supported. As a result, when created, teams and VLANs do not pass traffic. We expect that ANS will be supported on Microsoft Windows 10 client in a future release.

System and Cable Requirements
Available PCI Express x4 or higher (x8, x16) slot

Indicators

LED Indicators
2 - 10/100/1000 Mbps Indicator

2 - Link / Activity

Environmental

Humidity
5~85% RH

Operating Temperature
0°C to 50°C (32°F to 122°F)

Storage Temperature
-20°C to 60°C (-4°F to 140°F)

Physical Characteristics

Product Height
4.8 in [121 mm]

Product Length
2.6 in [67 mm]

Product Weight
2.8 oz [80 g]

Product Width
0.7 in [19 mm]

Packaging Information

Shipping (Package) Weight
5.9 oz [166 g]

What's in the Box

Included in Package
1 - 2 Port Network Card

1 - Low Profile Bracket

1 - Driver CD

1 - Instruction Manual



Dual Port PCI Express (PCIe x4) Gigabit Ethernet Server Adapter - 2 Port Network Card - Intel i350 Chipset NIC - GbE Network Card - 2Port Ethernet Card - PCIe Dual NIC Card


Brand Name: StarTech.com
Device Supported: Computer
Form Factor: Plug-in Card
Host Interface: PCI Express x4
Network Technology: 10/100/1000Base-T
Number of Network (RJ-45) Ports: 2
Product Type: Gigabit Ethernet Card
Total Number of Ports: 2


Basic

Brand Name:
StarTech.com

Device Supported:
Computer

Form Factor:
Plug-in Card

Host Interface:
PCI Express x4

Network Technology:
10/100/1000Base-T

Number of Network (RJ-45) Ports:
2

Product Type:
Gigabit Ethernet Card

Total Number of Ports:
2
General Information

Brand Name:
StarTech.com

Manufacturer Part Number:
ST2000SPEXI

Manufacturer Website Address: 		http://www.startech.com/au

Manufacturer:
StarTech.com

Packaged Quantity:
1

Product Name:
2 Port Network Card

Product Type:
Gigabit Ethernet Card
Interfaces/Ports

Ethernet AUI:
No

Host Interface:
PCI Express x4


Network (Rj-45):

Yes

Number of Network (RJ-45) Ports:
2

PoE (RJ-45) Port:
No

Serial Port:
No

Total Number of Ports:
2

USB:
No

XJACK:
No
Media & Performance

Data Transfer Rate:
1024 MB/s

Media Type Supported:
Twisted Pair
Miscellaneous

Device Supported:
Computer

Platform Supported:
PC

System Requirements:

OS Compatibility:

  • Windows 10
  • Windows 8 / 8.1 (32/64bit)
  • Windows 7 (32/64)
  • Windows Vista(32/64)
  • Windows XP(32/64)
  • Windows Server 2012
  • Windows 2008 R2
  • Windows 2003(32/64)
  • Linux 2.4.x/ 2.6.x / 3.x (Tested up to 3.5)
Network & Communication

InfiniBand:
No

Network Technology:
10/100/1000Base-T
Physical Characteristics

Form Factor:
Plug-in Card

Height:
121.9 mm

Length:
66 mm


Weight (Approximate):

79.4 g

Width:
17.8 mm
Warranty

Limited Warranty:
2 Year
