Startech Mountable 4 Port Rugged Industrial USB Hub ST4200USBM

Features

st4200usbm ports startech product external

Click to view full size

power mounting warranty information terminal

Click to view full size

Click to view full size

(Pictures are For Illustration Purposes Only)

Download Brochure

Startech's MPN:

ST4200USBM

Add four rugged external USB 2.0 ports from a single USB connection

High Speed USB 2.0 compliant, supporting transfer rates up to 480 Mbps
Support for multiple mounting methods (Wall/Surface mount and DIN rail)
All metal construction

This sturdy, industrial grade USB hub can be wall mounted or installed onto a DIN rail for convenient access to its 4 female USB ports, providing a work area, server room, or industrial area with USB 2.0 connectivity.

With support for Hi-Speed USB 2.0 data transfer rates of up to 480 Mbps, this 4 port USB hub is backwards compatible with USB 1.1 specifications and can be powered through the host USB bus, or self powered using a three wire terminal block connector (7-24V).

The StarTech.com Advantage

An all metal chassis and surface mounting or DIN rail mounting options makes this versatile for almost any environment
Optional external terminal block DC power connector can ensure full power to all four USB ports simultaneously
Backed by a StarTech.com 2-year warranty and free lifetime technical support

Applications

Locations where a USB hub needs to be securely mounted to a surface, such as a wall or under a desk
Environments subject to large temperature variances or where physical damage may occur, such as within a factory

Warranty Information
Warranty	2 Years
Hardware
Industry Standards	USB 2.0
Interface	USB 2.0
Ports	4
Performance
Maximum Data Transfer Rate	480 Mbps
MTBF	193,317.8 Hours
Connector(s)
External Ports	1 - Terminal Block (3 Wire)
	1 - USB B (4 pin) Female
	4 - USB Type-A (4 pin) USB 2.0 Female
Software
OS Compatibility	OS independent; No software or drivers required
Special Notes / Requirements
System and Cable Requirements	Any computer with a USB 2.0 port
Indicators
LED Indicators	1 - Power
Power
Input Voltage	7 ~ 24 DC
Power Source	Terminal Block
Environmental
Operating Temperature	0°C to 55°C (32°F to 131°F)
Storage Temperature	-20°C to 85°C (-4°F to 185°F)
Physical Characteristics
Color	Black
Enclosure Type	Steel
Product Height	1 in [26.3 mm]
Product Length	4.5 in [114.5 mm]
Product Weight	14.5 oz [410 g]
Product Width	2.3 in [57.3 mm]
Packaging Information
Shipping (Package) Weight	0.9 lb [0.4 kg]
What's in the Box
Included in Package	1 - USB Cable
	1 - DIN Mounting Rails
	1 - USB 2.0 Hub
	1 - Instruction Manual

Mountable 4 Port Rugged Industrial USB Hub

Brand Name: StarTech.com

Form Factor: External

Host Interface: USB

Product Type: USB Hub

Total Number of USB Ports: 5

Basic
Brand Name:	StarTech.com
Form Factor:	External
Host Interface:	USB
Product Type:	USB Hub
Total Number of USB Ports:	5

General Information
Brand Name:	StarTech.com
Manufacturer Part Number:	ST4200USBM
Manufacturer Website Address:	http://www.startech.com/au
Manufacturer:	StarTech.com
Product Model:	ST4200USBM
Product Name:	4-Port USB 2.0 Hub
Product Type:	USB Hub

Interfaces/Ports
Host Interface:	USB
Number of USB 2.0 Ports:	5
Total Number of USB Ports:	5

Miscellaneous
Additional Information:	An all metal chassis and surface mounting or DIN rail mounting options makes this versatile for almost any environment Optional external terminal block DC power connector can ensure full power to all four USB ports simultaneously Backed by a StarTech.com 2-year warranty and free lifetime technical support
Form Factor:	External
Platform Supported:	PC

Physical Characteristics
Colour:	Black
Depth:	114.6 mm
Form Factor:	External
Height:	26.4 mm
Platform Supported:	PC
Width:	57.4 mm

Product Information
Form Factor:	External
Platform Supported:	PC
Width:	57.4 mm

Technical Information
Host Interface:	USB
Platform Supported:	PC

Warranty
Limited Warranty:	2 Year

Information

SKU/Item No 537233

Vendor Part No ST4200USBM

UPC/EAN Number 065030831024

Our Stock ** (click for more info)

Price

$127.47
