Startech Mountable Rugged Industrial 7 Port USB Hub ST7200USBM

Features

st7200usbm ports startech product industrial

Click to view full size

Click to view full size

Click to view full size

Click to view full size

(Pictures are For Illustration Purposes Only)

Download Brochure

Startech's MPN:

ST7200USBM

Add 7 external, wall/DIN rail mountable USB 2.0 ports from a single USB connection

Provides 7 USB 2.0 ports
USB bus powered or external terminal block with support for 7 ~ 24VDC input
Compact and lightweight design with surface or DIN rail mounting options

This sturdy, industrial grade USB 2.0 hub can be wall mounted or installed onto a DIN rail for convenient access to its 7 female USB 2.0 ports, providing a work area, server room, or industrial environment with USB 2.0 connectivity.

With support for Hi-Speed USB 2.0 data transfer rates of up to 480 Mbps, this 7 port USB hub is backwards compatible with USB 1.1 specifications and can be powered through the host USB bus, or self powered using a three wire terminal block connector (7-24V).

The StarTech.com Advantage

A single USB host connection provides 7 additional USB ports with per port surge protection
Surface and DIN mounting options and terminal block power input to suit a wide range of industrial applications
Backed by a StarTech.com 2-year warranty and free lifetime technical support

Applications

Add additional, easy to access USB ports to rack mounted equipment
Install a USB hub that can be securely mounted to a surface or inside an equipment rack DIN rail

Warranty Information
Warranty	2 Years
Hardware
Chipset ID	Terminus FE2.1
Industry Standards	USB 2.0
Interface	USB 2.0
Ports	7
Performance
Maximum Data Transfer Rate	Up to 480Mbps
MTBF	170,227 Hours
Surge Protection	15KV ESD protection
Connector(s)
External Ports	1 - Terminal Block (2 Wire)
	1 - USB B (4 pin) Female
	7 - USB Type-A (4 pin) USB 2.0 Female
Software
OS Compatibility	OS independent; No software or drivers required
Special Notes / Requirements
System and Cable Requirements	Any computer with a USB 2.0 port
Indicators
LED Indicators	1 - Power
Power
Input Voltage	7 ~ 24 DC
Power Source	Terminal Block
Environmental
Humidity	5~95% RH
Operating Temperature	0°C to 55°C (32°F to 131°F)
Storage Temperature	-20°C to 85°C (-4°F to 185°F)
Physical Characteristics
Color	Black
Enclosure Type	Steel
Product Height	1.4 in [36.3 mm]
Product Length	5.2 in [133 mm]
Product Weight	17.6 oz [500 g]
Product Width	2.4 in [61.5 mm]
Packaging Information
Shipping (Package) Weight	1.1 lb [0.5 kg]
What's in the Box
Included in Package	1 - USB 2.0 Hub
	2 - DIN rail mounting bracket
	1 - Locking USB Cable
	1 - Screw kit
	1 - Instruction Manual

Mountable Rugged Industrial 7 Port USB Hub

Brand Name: StarTech.com

Form Factor: External

Host Interface: USB

Product Type: USB Hub

Total Number of USB Ports: 7

Basic
Brand Name:	StarTech.com
Form Factor:	External
Host Interface:	USB
Product Type:	USB Hub
Total Number of USB Ports:	7

General Information
Brand Name:	StarTech.com
Manufacturer Part Number:	ST7200USBM
Manufacturer Website Address:	http://www.startech.com/au
Manufacturer:	StarTech.com
Product Name:	Mountable Rugged Industrial 7 Port USB Hub
Product Type:	USB Hub

Interfaces/Ports
Host Interface:	USB
Number of USB 2.0 Ports:	7
Total Number of USB Ports:	7

Miscellaneous
Additional Information:	A single USB host connection provides 7 additional USB ports with per port surge protection Surface and DIN mounting options and terminal block power input to suit a wide range of industrial applications Backed by a StarTech.com 2-year warranty and free lifetime technical support
Form Factor:	External
Green Compliance Certificate/Authority:	RoHS
Green Compliant:	Yes
Platform Supported:	PC

Physical Characteristics
Colour:	Black
Depth:	133.1 mm
Form Factor:	External
Height:	36.3 mm
Platform Supported:	PC
Weight (Approximate):	500.4 g
Width:	61.5 mm

Product Information
Form Factor:	External
Platform Supported:	PC
Width:	61.5 mm

Technical Information
Host Interface:	USB
Platform Supported:	PC

Warranty
Limited Warranty:	2 Year

Information

SKU/Item No 537232

Vendor Part No ST7200USBM

UPC/EAN Number 065030837910
