Startech 7.1 USB Audio Adapter External Sound Card with SPDIF Digital Audio ICUSBAUDIO7D

Features

Click to view full size

Click to view full size

warranty optical factor information windows

Click to view full size

(Pictures are For Illustration Purposes Only)

Startech's MPN:

ICUSBAUDIO7D

Turn your laptop or desktop computer into a 7.1-channel home theater-ready sound system

Full 7.1 audio outputs via 3.5mm mini-jacks
Optical S/PDIF input (pass through) and output
Dual microphone input

This versatile External USB Sound Card/Audio Adapter offers a high quality solution for upgrading desktop or laptop sound.

Providing a robust USB audio experience, the USB sound card connects to a host computer through a single USB 2.0 connection, to deliver impressive external audio capability that can instantly be swapped between systems, without having to open the computer case for installation.

Supporting analog and digital audio for 2 to 7.1 channel audio applications, the external USB sound card provides a cost-saving upgrade from built-in/on-board sound that turns desktop/laptop sound into a home theater-ready audio solution.

The external USB sound card features easy-to-use volume control and two external microphone inputs - a convenient solution for any audio application requiring high quality sound with multi-input capability with support for 44.1 KHz and 48 KHz sampling rates for analog playback and recording or 48 KHz for SPDIF.

A more than suitable solution for home theater, gaming or multi-media presentations, the External USB Sound Card is easy to install with plug and play support in Windows XP and Windows Vista operating systems.

Designed to deliver a long-lasting and dependable sound solution, the External USB Sound Card/Audio Adapter is backed by our 2-year warranty and free lifetime technical support.

Note: The audio adapter’s SPDIF optical pass-through port supports two-channel audio, this port does not support 5.1 or 7.1 audio.

The StarTech.com Advantage

Full 7.1 audio output support in a compact and portable external sound card
Connect to external speakers through 3.5mm mini-jacks or optical S/PDIF
Backed by a StarTech.com 2-year warranty and free lifetime technical support

Applications

Add 7.1 audio support to laptop or small form factor system with no internal expansion options
Replace or upgrade the existing integrated audio on a laptop or portable computer
Connect your computer to an home theater audio receiver through optical S/PDIF

Warranty Information
Warranty	2 Years
Hardware
Chipset ID	C-Media - CM6206
Performance
Audio Specifications	8 16-bit DAC Channels (7.1 Surround Sound) Supports 44.1 and 48 KHz sampling rates for analog playback and recording or 48 KHz for SPDIF 3.5mm output connectors for Front, Surround, Rear, Centre/bass
Connector(s)
Connector Type(s)	1 - USB B (4 pin) Female
External Ports	2 - Toslink (SPDIF, Optical) Female
	8 - 3.5 mm Mini-Jack (3 Position) Female
Software
OS Compatibility	Windows® 10 (32/64), 8 / 8.1 (32/64), 7 (32/64), Vista (32/64), XP (32/64), 2000 Windows Server® 2008 R2, 2003 (32/64)
Special Notes / Requirements
Note	The audio adapter’s SPDIF optical pass-through port supports two-channel audio, this port does not support 5.1 or 7.1 audio.
Indicators
LED Indicators	1 - Microphone Mute
	1 - Power/Activity
Environmental
Humidity	20 to 80% NC RH
Operating Temperature	0°C to 55°C (32°F to 131°F)
Storage Temperature	0°C to 70°C (32°F to 158°F)
Physical Characteristics
Color	Silver
Product Height	1 in [25 mm]
Product Length	3.9 in [100 mm]
Product Weight	3.5 oz [100 g]
Product Width	2.4 in [60 mm]
Packaging Information
Shipping (Package) Weight	0.5 lb [0.2 kg]
What's in the Box
Included in Package	1 - USB to Audio Adapter
	1 - USB Cable
	1 - Installation CD
	1 - Instruction Manual

7.1 USB Audio Adapter External Sound Card with SPDIF Digital Audio - External USB Laptop Sound Card

Brand Name: StarTech.com

Form Factor: External

Maximum Playback Sampling Rate: 48 kHz

Number of Audio Line Out: 1

Product Type: External Sound Box

Sound Channels: 7.1

Basic
Brand Name:	StarTech.com
Form Factor:	External
Maximum Playback Sampling Rate:	48 kHz
Number of Audio Line Out:	1
Product Type:	External Sound Box
Sound Channels:	7.1

General Information
Brand Name:	StarTech.com
Manufacturer Part Number:	ICUSBAUDIO7D
Manufacturer Website Address:	http://www.startech.com/au
Manufacturer:	StarTech.com
Product Name:	7.1 USB Audio Adapter External Sound Card
Product Type:	External Sound Box

Interfaces/Ports
Number of Audio Line Out:	1
USB:	Yes

Miscellaneous
Additional Information:	Full 7.1 audio output support in a compact and portable external sound card Connect to external speakers through 3.5mm mini-jacks or optical S/PDIF Backed by a StarTech.com 2-year warranty and free lifetime technical support
Form Factor:	External
Platform Supported:	PC
System Requirements:	OS Compatibility: Windows® 10 (32/64), 8 / 8.1 (32/64), 7 (32/64), Vista (32/64), XP (32/64), 2000 Windows Server® 2008 R2, 2003 (32/64)

Physical Characteristics
Form Factor:	External
Height:	24.9 mm
Platform Supported:	PC
Weight (Approximate):	100.1 g
Width:	59.9 mm

Product Information
Form Factor:	External
Platform Supported:	PC
Width:	59.9 mm

Technical Information
Maximum Playback Sampling Rate:	48 kHz
Platform Supported:	PC
Sound Channels:	7.1
USB:	Yes

Warranty
Limited Warranty:	2 Year

Information

SKU/Item No 537170

Vendor Part No ICUSBAUDIO7D

UPC/EAN Number 065030835466
