Startech USB Stereo Audio Adapter External Sound Card with SPDIF Digital Audio and Stereo Mic ICUSBAUDIO2D

Features

icusbaudio2d audio sound external digital

Click to view full size

Click to view full size

(Pictures are For Illustration Purposes Only)

Download Brochure

Startech's MPN:

ICUSBAUDIO2D

Add an SPDIF digital audio output and standard 3.5mm audio/microphone connections to your system through USB

96KHz / 24-bit Hi-Fi USB Audio
S/PDIF digital output with AC3 (Dolby Digital) and DTS pass-through support
5.1 Surround Sound supported (Windows® only)

The ICUSBAUDIO2D External USB Sound Card lets you add an S/PDIF digital audio output and standard 3.5mm analog audio/microphone connections to your system through USB - a convenient way to bypass or replace an internal sound card without having to open the computer case.

For home-theater quality sound, the USB DAC (digital-to-analog converter) offers 96KHz / 24-bit sampling rates for both playback and recording, and a 3.5mm S/PDIF port with support for Dolby® Digital 5.1 surround sound (AC3) and DTS® pass-through (Note: 5.1 surround sound is supported in Windows® only).

This versatile USB audio adapter features an integrated 3.5mm 4-position TRRS connection for your headphones or combination headset/microphone. Also a convenient external volume control for quick adjustments, a hardware EQ switch for Bass or Treble boosting, and an LED status bar to display the current sampling rate.

Backed by a StarTech.com 2-year warranty and free lifetime technical support.

The StarTech.com Advantage

Add home-theater surround sound support with the integrated digital S/PDIF output
Replace an internal sound card easily with a compact external USB device
Adjust sound output easily with external volume and EQ controls

Applications

Connect your computer to a home theater audio receiver through S/PDIF, without opening the case
Add digital audio support to an Ultrabook™ or small form factor system with no internal expansion options
Replace or upgrade the integrated audio on a laptop or portable computer

Warranty Information
Warranty	2 Years
Hardware
Bus Type	USB 2.0
Chipset ID	VIA - VT1630A
Performance
Audio Specifications	96 KHz / 24-bit Sample Rate Approx 91dB SNR (A-weighting) 16-100ohm Headphone Drive Ability
Connector(s)
Connector Type(s)	1 - 3.5 mm Mini-Jack (3 Position) Female
	1 - 3.5 mm Mini-Jack (4 Position) Female
	1 - 3.5mm Mini-Toslink (SPDIF, Optical) Female
	1 - USB Type-A (4 pin) USB 2.0 Male
Software
OS Compatibility	Windows® XP, Vista, 7, 8, 8.1, 10 Windows Server® 2003, 2008 R2, 2012, 2012 R2, 2016 Mac OS X® 10.6 to 10.8
Special Notes / Requirements
Note	5.1 surround sound output is supported in Windows only
System and Cable Requirements	Available USB Port
Indicators
LED Indicators	1 - Power
	3 - Playback / Recording sample rate
Power
Power Source	USB-Powered
Environmental
Humidity	10~90% RH (Non-Condensing)
Operating Temperature	0°C to 60°C (32°F to 140°F)
Storage Temperature	0°C to 70°C (32°F to 158°F)
Physical Characteristics
Cable Length	16 in [406.5 mm]
Color	Black
Enclosure Type	Plastic
Product Height	0.6 in [16 mm]
Product Length	1.9 in [47 mm]
Product Weight	1.4 oz [40 g]
Product Width	1.8 in [46 mm]
Packaging Information
Shipping (Package) Weight	4.2 oz [119 g]
What's in the Box
Included in Package	1 - USB Stereo Audio Adapter
	1 - Software CD
	1 - Instruction Manual

USB Stereo Audio Adapter External Sound Card with SPDIF Digital Audio Out - USB Sound Card Adapter - External USB to Audio Converter - USB SPDIF Sound Card - USB Audio Sound Card

Brand Name: StarTech.com

Form Factor: External

Host Interface: USB 2.0

Product Type: External Sound Box

Sound Channels: 5.1

Audio
Signal to Noise Ratio (SNR):	91 dB

Basic
Brand Name:	StarTech.com
Form Factor:	External
Host Interface:	USB 2.0
Product Type:	External Sound Box
Sound Channels:	5.1

Earpiece
Signal to Noise Ratio (SNR):	91 dB

General Information
Brand Name:	StarTech.com
Manufacturer Part Number:	ICUSBAUDIO2D
Manufacturer Website Address:	http://www.startech.com/au
Manufacturer:	StarTech.com
Packaged Quantity:	1
Product Name:	USB Stereo Audio Adapter External Sound Card with SPDIF Digital Audio
Product Type:	External Sound Box

Interfaces/Ports
Host Interface:	USB 2.0

Miscellaneous
Form Factor:	External
Platform Supported:	PC
System Requirements:	OS Compatibility: Windows® 10 (32/64), 8 / 8.1 (32/64), 7 (32/64), Vista (32/64), XP (32/64) Windows Server® 2012, 2008 R2, 2003 Mac OS® 10.x (tested up to 10.8) Linux

Physical Characteristics
Form Factor:	External
Height:	15.2 mm
Platform Supported:	PC
Thickness:	48.3 mm
Weight (Approximate):	36.9 g
Width:	45.7 mm

Product Information
Form Factor:	External
Packaged Quantity:	1
Platform Supported:	PC
Thickness:	48.3 mm
Width:	45.7 mm

Technical Information
Audio Processor Manufacturer:	VIA
Audio Processor Model:	VT1630A
Host Interface:	USB 2.0
Platform Supported:	PC
Signal to Noise Ratio (SNR):	91 dB
Sound Channels:	5.1

Information

SKU/Item No 537169

Vendor Part No ICUSBAUDIO2D

UPC/EAN Number 065030852296
