Startech 2 Port High Resolution VGA Video Splitter - 350 MHz ST122PRO

Features
st122pro video high resolution startech
Click to view full size
displays supported monitors signal splitter
Click to view full size

(Pictures are For Illustration Purposes Only)

Startech

pdf brochure downloadDownload Brochure

Startech's MPN:

ST122PRO




Split a single high resolution VGA video signal to 2 monitors or projectors


  • Allows 1 VGA video source to simultaneously display on 2 different monitors


  • Supports resolutions up to 2048x1536 @ 80Hz


  • High video bandwidth (350 MHz)


The ST122PRO 2 Port High Resolution VGA Video Splitter - 350 MHz splits a VGA video source signal to 2 monitors or projectors simultaneously - a professional grade solution that is perfect for presentations, classrooms, tradeshows, or in-store displays, where the highest quality video on several monitors is needed.


This High Resolution VGA Splitter supports monitors with up to 350MHz of video bandwidth and display resolutions up to 2048x1536 @80Hz. For added versatility, the VGA splitter features an integrated booster circuit that allows the video signal to be extended up to 210 feet (65 meters), enabling you to situate your displays in the most convenient location based on your application.


Backed by a StarTech.com 2-year warranty and free lifetime technical support. Male to Female VGA extension cable required (MXT101HQ)


The StarTech.com Advantage
  • An integrated signal amplifier boosts your connection range to 210 feet (65 meters)
  • High quality construction and high resolution support maintains signal strength for crisp, sharp imaging
  • Multiple screens let you broadcast your message to large audiences with greater impact

Applications
  • Create engaging multimedia presentations for demonstration in lecture halls and classrooms
  • Display travel schedules and alerts in airports, bus terminals and train stations etc.
  • Create eye-catching displays in trade-shows and auditoriums
  • Use for in-store product merchandising in retail environments to give your advertisements greater visibility
  • Get your message across multiple displays for trade-shows or information booths/kiosks
  • Quick and easy solution to split a video signal in an auditorium or house of worship

Warranty Information

Warranty
2 Years

Hardware

Audio
No

Industry Standards
DDC compatible - all other monitors must be able to support the highest video resolution of the DDC-type monitor connected to Video Out 1

Ports
2

Regulatory Approvals
FCC Part 15 Class A, CE Mark

Performance

Bandwidth

(-3Db):
350 MHz

General Specifications
Male to Female VGA extension cable required (MXT101HQ)

Maximum Analog Resolutions
2048x1536 @ 80Hz

Maximum Cable Length
213.2 ft [65 m]

MTBF
1,588,136 Hours

Connector(s)

Connector Type(s)
1 - VGA (15 pin, High Density D-Sub) Male

2 - VGA (15 pin, High Density D-Sub) Female

Power

Output Current
0.6A

Output Voltage
5 DC

Plug Type
N

Power Consumption (In Watts)
3

Power Source
AC Adapter Included

Environmental

Humidity
0~80% RH Non-condensing

Operating Temperature
5°C to 40°C (41°F to 104°F)

Physical Characteristics

Color
Black

Product Height
0.8 in [21 mm]

Product Length
7.1 in [180 mm]

Product Weight
2.1 lb [1 kg]

Product Width
3.1 in [80 mm]

Packaging Information

Shipping (Package) Weight
2.5 lb [1.1 kg]

What's in the Box

Included in Package
1 - 2 Port High Res. Video Splitter

4 - Rubber feet

1 - Power Adapter

1 - Instruction Manual



2 PORT HIGH RESOLUTION VGA VIDEO SPLITTER - 350 MHZ


Brand Name: StarTech.com
Device Supported: Computer
Maximum Operating Distance: 60.96 m
Number of Displays Supported: 2
Number of Input Devices Supported: 1
Product Type: Video Switchbox


Basic

Brand Name:
StarTech.com

Device Supported:
Computer

Maximum Operating Distance:
60.96 m

Number of Displays Supported:
2

Number of Input Devices Supported:
1

Product Type:
Video Switchbox
General Information

Brand Name:
StarTech.com

Manufacturer Part Number:
ST122PRO

Manufacturer Website Address: 		http://www.startech.com/au

Manufacturer:
StarTech.com

Marketing Content:
The ST122PRO 2 Port High Resolution VGA Video Splitter - 350 MHz splits a VGA video source signal to 2 monitors or projectors simultaneously - a professional grade solution that is perfect for presentations, classrooms, tradeshows, or in-store displays, where the highest quality video on several monitors is needed.

Product Name:
2 Port High Res. Video Splitter

Product Type:
Video Switchbox
Media & Performance

Maximum Operating Distance:
60.96 m
Miscellaneous

Additional Information:
  • Allows one computer to provide simultaneous displays on 2 different monitors
  • Daisy chainable for almost unlimited expansion
  • Built-in video amplifier boosts the signal to allow a cable length of up to 210 ft or 65m
  • Uses standard monitor extension cables (StarTech coaxial VGA cables recommended for best picture quality)
  • DDC compatible (all other monitors must be able to support the highest video resolution of the DDC-type monitor connected to Video Out 1)
  • Enclosure: Metal
Physical Characteristics

Colour:
Black

Depth:
116.8 mm

Height:
40.6 mm

Width:
172.7 mm
Technical Information

Device Supported:
Computer

Number of Displays Supported:
2

Number of Input Devices Supported:
1
Video

Graphics Modes:
SVGA

VGA

XGA

Maximum Video Bandwidth:
350 MHz

Maximum Video Resolution:
2048 x 1536
