Startech 4x4 HDMI Matrix Video Switch Splitter with Audio and RS232 VS440HDMI

Features

Click to view full size

Click to view full size

display number control included displays

Click to view full size

(Pictures are For Illustration Purposes Only)

Download Brochure

Startech's MPN:

VS440HDMI

Share and switch four distinct HDMI® audio/video signals between four displays

Included software allows storage of up to 4 distinct display combinations
Allows four PCs/Media Players to provide video to four displays
Allows storage and recall of a display combination using front panel buttons

The VS440HDMI 4x4 HDMI® Audio/Video Matrix Switch/Splitter (with Audio and RS232) lets you share up to 4 distinct HDMI or DVI inputs (using HDMI to DVI adapters - not included), with audio, between 4 independent displays or projectors.

Providing convenient front push-button and RS232 PC software control, this matrix switch allows each input and the corresponding audio to be switched individually, meaning that different A/V sources can be shown on each output, or a single source can be output to several offering maximum flexibility.

The switcher features a front panel LCD display for easy status monitoring, plus an included remote control and IR extender module for simple control from a distance.

Designed to provide maximum functionality while saving space, the HDMI Video Matrix Switch can be used as a standalone solution or rack-mounted using ear-mounts (included).

Backed by a StarTech.com 2-year warranty and free lifetime technical support.

The StarTech.com Advantage

Matrix switching functionality gives you full control of the video source displayed on each monitor, at the touch of a button
Front panel push-buttons, RS-232 PC port and IR remote included for simple control and flexible switching options
Storage of display configurations allow for convenient recall of preferred combinations

Applications

Ideal for connecting/switching multiple sources in Test Bench Facilities, Data Centers, Help Desks and Video Broadcasting Facilities
Perfect for digital signage applications in retail environments requiring more than one media player or PC to be connected
Allow trainees/students to see what is on your display and then switch them back to their own display after the demonstration completes
Run multimedia presentations with supporting data displayed on another monitor in business conference rooms or at trade shows
Take full control of your A/V sources and displays/projectors - select any source on any display

Warranty Information
Warranty	2 Years
Hardware
Audio	Yes
Cabling	HDMI
Ports	4
Rack-Mountable	Yes
Performance
Bandwidth	225MHz
Maximum Cable Length	32.8 ft [10 m]
Supported Resolutions	1920x1200 or 1080p
Wide Screen Supported	Yes
Connector(s)
Connector A	4 - HDMI (19 pin) Female
Connector B	4 - HDMI (19 pin) Female
Connector Type(s)	1 - DB-9 (9 pin, D-Sub) Female
Power
Center Tip Polarity	Positive
Input Current	0.6A
Input Voltage	100 ~ 240 AC
Output Current	1.5A
Output Voltage	12 DC
Plug Type	M
Power Consumption (In Watts)	18
Power Source	AC Adapter Included
Environmental
Humidity	0~95%
Operating Temperature	0°C to 70°C (32°F to 158°F)
Storage Temperature	-20°C to 85°C (-4°F to 185°F)
Physical Characteristics
Color	Black
Enclosure Type	Steel
Product Height	1.7 in [42 mm]
Product Length	17.3 in [440 mm]
Product Weight	5.2 lb [2.4 kg]
Product Width	7.3 in [185 mm]
Packaging Information
Shipping (Package) Weight	6.9 lb [3.1 kg]
What's in the Box
Included in Package	1 - HDMI Matrix Selector Switch
	2 - Rack Mount Brackets
	1 - RS232 Cable
	1 - IR Remote Control
	6 - Screws for rack mount brackets
	1 - Universal Power Adapter (US/UK/EU/AU)
	1 - Software Installation CD
	1 - Instruction Manual

4x4 HDMI Matrix Video Switch Splitter with Audio and RS232 - 4x1 HDMI Video Switch - 4 Port HDMI Switcher

Brand Name: StarTech.com

Device Supported: Computer

Form Factor: Rack-mountable

HDMI In: Yes

HDMI Out: Yes

Maximum Operating Distance: 10 m

Number of Displays Supported: 4

Number of HDMI Inputs: 4

Number of Input Devices Supported: 4

Product Type: Audio/Video Switchbox

Basic
Brand Name:	StarTech.com
Device Supported:	Computer
Form Factor:	Rack-mountable
HDMI In:	Yes
HDMI Out:	Yes
Maximum Operating Distance:	10 m
Number of Displays Supported:	4
Number of HDMI Inputs:	4
Number of Input Devices Supported:	4
Product Type:	Audio/Video Switchbox

Camera
Maximum Video Resolution:	1920 x 1080

Display & Graphics
Maximum Video Resolution:	1920 x 1080

General Information
Brand Name:	StarTech.com
Manufacturer Part Number:	VS440HDMI
Manufacturer Website Address:	http://www.startech.com/au
Manufacturer:	StarTech.com
Product Name:	4x4 HDMI Matrix Video Switch Splitter with Audio and RS232
Product Type:	Audio/Video Switchbox

Interfaces/Ports
HDMI In:	Yes
HDMI Out:	Yes
Number of HDMI Inputs:	4
Serial Port:	Yes

Media & Performance
Maximum Operating Distance:	10 m

Miscellaneous
Device Supported:	Computer
Form Factor:	Rack-mountable

Physical Characteristics
Form Factor:	Rack-mountable
Weight (Approximate):	2.35 kg
Width:	184.9 mm

Product Information
Device Supported:	Computer
Form Factor:	Rack-mountable
Number of Displays Supported:	4
Width:	184.9 mm

Technical Information
Device Supported:	Computer
Maximum Operating Distance:	10 m
Number of Displays Supported:	4
Number of Input Devices Supported:	4
Scan Format:	1080p

Video
Maximum Video Resolution:	1920 x 1080
Scan Format:	1080p

Information

SKU/Item No 536911

Vendor Part No VS440HDMI

UPC/EAN Number 065030842105
