Startech USB 3.0 to Gigabit Ethernet NIC Network Adapter – 10/100/1000 Mbps USB31000NDS

Features

usb31000nds network ethernet gigabit supported

Click to view full size

Click to view full size

Click to view full size

Click to view full size

(Pictures are For Illustration Purposes Only)

Download Brochure

Startech's MPN:

USB31000NDS

Add Gigabit Ethernet network connectivity to a Laptop or Desktop through a USB 3.0 port

Full Gigabit bandwidth support over USB 3.0
IEEE 802.3, 802.3u and 802.3ab (10BASE-T, 100BASE-TX, and 1000BASE-T) compatible
USB-Powered

The USB31000NDS USB 3.0 to Gigabit Ethernet Network Adapter adds a single RJ45 Ethernet port to a USB-enabled computer system, with support for Gigabit network connections at full bandwidth when used with a USB 3.0 host connection, unlike USB 2.0 adapters.

This compact USB 3.0 NIC works with 10/100/1000 Mbps networks and offers backward compatibility with USB 2.0/1.x computer systems (speed limited by USB bus), making it an ideal portable replacement LAN adapter or laptop accessory. Support for features such as Jumbo Frames, VLAN tagging and Wake on LAN (WOL), provides versatile Gigabit network performance for home or business use.

Backed by a StarTech.com 2-year warranty and free lifetime technical support.

The StarTech.com Advantage

Full Gigabit bandwidth support through a USB 3.0 host connection
Highly portable design, with no need for an external power adapter

Applications

Add Gigabit Ethernet capabilities to a desktop or laptop
Replace a failed integrated network adapter with an external, USB Ethernet solution to avoid opening the computer case

Warranty Information
Warranty	2 Years
Hardware
Bus Type	USB 3.0
Chipset ID	ASIX - AX88179
Industry Standards	IEEE802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3az
Interface	RJ45 (Gigabit Ethernet)
Ports	1
Performance
Auto MDIX	Yes
Compatible Networks	10/100/1000 Mbps
Full Duplex Support	Yes
Jumbo Frame Support	4K max.
Max Distance	100 m / 330 ft
Maximum Data Transfer Rate	1Gbps (Gigabit Ethernet)
Type and Rate	USB 3.0 - 5 Gbit/s
Connector(s)
Connector Type(s)	1 - RJ-45 Female
	1 - USB Type-A (9 pin) USB 3.0 Male
Software
OS Compatibility	Windows® XP, Vista, 7, 8, 8.1, 10 Windows® Server 2003, 2008 R2, 2012, 2012 R2, 2016 Mac OS® 10.6 to 10.12 VLAN tagging is currently not supported in Mac OS Linux Kernel 2.6.25 to 4.4.x LTS Versions only
Special Notes / Requirements
System and Cable Requirements	Host computer system with an available USB 3.0/2.0 port
Indicators
LED Indicators	1 - Activity (Yellow)
	1 - Link (Green)
Power
Power Source	USB-Powered
Environmental
Humidity	10~90% RH
Operating Temperature	0°C to 50°C (32°F to 122°F)
Storage Temperature	0°C to 70°C (32°F to 158°F)
Physical Characteristics
Color	Black
Enclosure Type	Plastic
Form Factor	Dongle
Product Height	1 in [26 mm]
Product Length	2.7 in [68 mm]
Product Weight	0.7 oz [21 g]
Product Width	0.9 in [22.6 mm]
Packaging Information
Shipping (Package) Weight	3.5 oz [100 g]
What's in the Box
Included in Package	1 - USB 3.0 to Gigabit Ethernet Adapter
	1 - Driver CD
	1 - Instruction Manual

USB 3.0 to Gigabit Ethernet NIC Network Adapter - 10/100/100 Mbps Network Adapter - USB to Ethernet LAN Adapter - USB to RJ45

Brand Name: StarTech.com

Device Supported: PC

Host Interface: USB

Network Technology: 10/100/1000Base-T

Number of Network (RJ-45) Ports: 1

Product Type: Gigabit Ethernet Card

Total Number of Ports: 1

Basic
Brand Name:	StarTech.com
Device Supported:	PC
Host Interface:	USB
Network Technology:	10/100/1000Base-T
Number of Network (RJ-45) Ports:	1
Product Type:	Gigabit Ethernet Card
Total Number of Ports:	1

Drive Performance
Data Transfer Rate:	1024 MB/s

General Information
Brand Name:	StarTech.com
Manufacturer Part Number:	USB31000NDS
Manufacturer Website Address:	http://www.startech.com/au
Manufacturer:	StarTech.com
Packaged Quantity:	1
Product Name:	USB 3.0 to Gigabit Ethernet NIC Network Adapter - 10/100/1000 Mbps
Product Type:	Gigabit Ethernet Card

Input Devices
Data Transfer Rate:	1024 MB/s

Interfaces/Ports
Ethernet AUI:	No
Host Interface:	USB
InfiniBand:	No
Network (Rj-45):	Yes
Number of Network (RJ-45) Ports:	1
PoE (RJ-45) Port:	No
Serial Port:	No
Total Number of Ports:	1
USB:	No
XJACK:	No

Media & Performance
Data Transfer Rate:	1024 MB/s
Media Type Supported:	Twisted Pair
Network Technology:	10/100/1000Base-T

Miscellaneous
Device Supported:	PC
Platform Supported:	PC
System Requirements:	OS Compatibility: Windows 10 Windows 8.1 (32/64bit) Windows 8 (32/64) Windows 7 (32/64) Windows Vista(32/64) Windows XP(32/64) Windows Server 2012 Windows 2008 R2 Windows 2003 (32/64) Mac OS 10.6 - 10.9 Linux Kernel 2.6.25 - 3.13.0

Network & Communication
InfiniBand:	No
Network Technology:	10/100/1000Base-T

Network
Network Technology:	10/100/1000Base-T

Physical Characteristics
Height:	25.4 mm
Length:	68.6 mm
Platform Supported:	PC
Weight (Approximate):	19.8 g
Width:	22.9 mm

Power Description
PoE (RJ-45) Port:	No

Product Information
Device Supported:	PC
Length:	68.6 mm
Packaged Quantity:	1
Platform Supported:	PC
Width:	22.9 mm

Storage
Data Transfer Rate:	1024 MB/s

Technical Information
Data Transfer Rate:	1024 MB/s
Device Supported:	PC
Host Interface:	USB
Length:	68.6 mm
Media Type Supported:	Twisted Pair
Number of Network (RJ-45) Ports:	1
Platform Supported:	PC
USB:	No

Warranty
Limited Warranty:	2 Year

Information

SKU/Item No 481569

Vendor Part No USB31000NDS

UPC/EAN Number 065030850810
