Startech 2 Port PCI Express PCIe SuperSpeed USB 3.0 Controller Card w/ SATA Power PEXUSB3S23

Features

Startech

pdf brochure downloadDownload Brochure

Startech's MPN:

PEXUSB3S23




Add two USB 3.0 ports to your desktop computer through a PCI Express slot


  • Provides two external USB 3.0 connections


  • Supports data rates up to 5 Gbps


  • SATA power connector (required) provides up to 900mA per USB port


The PEXUSB3S23 2-Port PCI Express USB 3.0 Card lets you add two USB 3.0 ports to any PCI Express-enabled computer system. The USB card requires SATA power for functionality, and delivers 900mA of power per port to USB 3.0 bus-powered devices (500mA for USB 2.0) via your computers SATA power connector.


The PCIe USB 3.0 adapter is compliant with USB 3.0 standards for data transfer speeds up to 5 Gbps, while still offering backward compatibility with existing USB 2.0 / 1.1 devices. For added versatility, the controller card is equipped with a standard profile bracket and includes a low-profile/half-height bracket for installation in small form-factor computers.


Backed by a StarTech.com 2-year warranty and free lifetime technical support.


The StarTech.com Advantage
  • Increase efficiency of your USB 3.0 devices with up to 5 Gbps of bandwidth
  • Fits into full or low profile/small form factor (SFF) systems, with a dual profile design

Applications
  • Upgrade an older PCIe-based system with USB 3.0 connectivity to fully utilize USB 3.0 devices
  • Expand the USB capabilities of your system with two additional external ports
  • Connect additional external hard drives, CD/DVD drives, MP3 players, printers, scanners, webcams, game controllers, digital cameras, etc. to a computer system

Warranty Information

Warranty
2 Years

Hardware

Bus Type
PCI Express

Card Type
Standard Profile (LP bracket incl.)

Chipset ID
Etron - EJ168A

Interface
USB 3.0

Port Style
Integrated on Card

Ports
2

Performance

Maximum Cable Length
9.8 ft [3 m]

Type and Rate
USB 3.0 - 5 Gbit/s

UASP Support
No

Connector(s)

Connector Type(s)
1 - PCI Express x1 Male

External Ports
2 - USB Type-A (9 pin) USB 3.0 Female

Internal Ports
1 - SATA Power (15 pin) Plug

Software

OS Compatibility
Windows® XP, Vista, 7, 8, 8.1, 10

Windows Server® 2003, 2008 R2, 2012, 2012 R2, 2016

Special Notes / Requirements

System and Cable Requirements
Available 15-pin SATA power connector

Available PCI Express slot

Environmental

Humidity
10~90% RH, Non-condensing

Operating Temperature
0°C to 60°C (32°F to 140°F)

Storage Temperature
0°C to 80°C (32°F to 176°F)

Physical Characteristics

Product Height
4.7 in [120 mm]

Product Length
3.1 in [80 mm]

Product Weight
2.1 oz [60 g]

Product Width
0.8 in [21 mm]

Packaging Information

Shipping (Package) Weight
4.6 oz [130 g]

What's in the Box

Included in Package
1 - PCI Express USB 3.0 card

1 - Low Profile Bracket

1 - Driver CD

1 - Instruction Manual



2 Port PCI Express (PCIe) SuperSpeed USB 3.0 Controller Card w/ SATA Power - PCIe USB 3.0 Card - Dual Port PCI Express USB 3 Adapter - 5 Gbps USB 3.0 PCIe Controller


Brand Name: StarTech.com
Form Factor: Plug-in Card
Host Interface: PCI Express x1
Product Type: USB Adapter
Total Number of USB Ports: 2


Basic

Brand Name:
StarTech.com

Form Factor:
Plug-in Card

Host Interface:
PCI Express x1

Product Type:
USB Adapter

Total Number of USB Ports:
2
General Information

Brand Name:
StarTech.com

Manufacturer Part Number:
PEXUSB3S23

Manufacturer Website Address: 		http://www.startech.com/au

Manufacturer:
StarTech.com

Package Contents:
  • 2 Port PCI Express PCIe USB 3.0 Controller Card w SATA Power
  • 1 x Low Profile Bracket
  • 1 x Driver CD
  • 1 x Instruction Manual

Packaged Quantity:
1

Product Name:
2 Port PCI Express PCIe USB 3.0 Controller Card w SATA Power

Product Type:
USB Adapter
Interfaces/Ports

Host Interface:
PCI Express x1

Number of SATA Ports:
1

Number of USB 3.0 Ports:
2

Total Number of USB Ports:
2
Miscellaneous

Form Factor:
Plug-in Card

Green Compliance Certificate/Authority:
RoHS

Green Compliant:
Yes

Package Contents:
  • 2 Port PCI Express PCIe USB 3.0 Controller Card w SATA Power
  • 1 x Low Profile Bracket
  • 1 x Driver CD
  • 1 x Instruction Manual

Platform Supported:
PC
Physical Characteristics

Form Factor:
Plug-in Card

Height:
80 mm

Platform Supported:
PC

Thickness:
21 mm


Weight (Approximate):

60 g

Width:
120 mm
Product Information

Form Factor:
Plug-in Card

Packaged Quantity:
1

Platform Supported:
PC

Thickness:
21 mm

Width:
120 mm
Technical Information

Host Interface:
PCI Express x1

Platform Supported:
PC
Warranty

Limited Warranty:
2 Year
