APC Smart-UPS X 3000VA Short Depth Tower/Rack Convertible LCD 200-240V with Network Card SMX3000HVNC

Features

APC/Schneider

APC/Schneider's MPN:

SMX3000HVNC




APC Smart-UPS X 3000VA Short Depth Tower/Rack Convertible LCD 200-240V with Network Card

Backup/Run Time (Full Load): 6 Minute
Backup/Run Time (Half Load): 18 Minute
Brand Name: APC
Form Factor: Tower/Rack Mountable
Load Capacity (VA): 3000 VA
Load Capacity (Watt): 2700 W
Product Family: Smart-UPS
Product Type: Line-interactive UPS
Rack Height: 4U
Receptacles: 1 x IEC 60320 C19
Receptacles: 2 x IEC Jumper
Receptacles: 8 x IEC 60320 C13

Battery Information


Backup/Run Time (Full Load):

6 Minute


Backup/Run Time (Half Load):

18 Minute

Battery Characteristics:

Maintenance-free

Battery Chemistry:

Sealed Lead Acid

Hot Swappable:

Yes

Maximum Battery Recharge Time:

3 Hour
General Information

Brand Name:

APC

Manufacturer Part Number:

SMX3000HVNC

Manufacturer Website Address:
http://www.apc.com

Manufacturer:

American Power Conversion Corp

Marketing Information:

Over 20 million units sold - the UPS you can trust
APC award-winning Smart-UPS® is the most popular UPS in the world for servers, storage and network power protection. Trusted to protect critical data and equipment from power problems by supplying clean and reliable network-grade power. In addition to legendary reliability and manageability, Smart-UPS have extremely high efficiency at low, medium and high load levels making them ideal for today's multi-core or virtualized servers that have varying load consumption. Available in a variety of form factors (tower, rack mount, rack/tower convertible) there is a model for every application and budget. Rack mounted Smart-UPS are ideal for powering Blade or density optimized servers in a distributed power protection environment as the primary or redundant protection. Smart-UPS® models have long been considered the benchmark for all network and server UPS's. Smart-UPS feature a 16-segment LED display, extended range automatic voltage regulation (AVR), and pure sine wave output on battery. Additional manageability options are available through the Smart-Slot interface, which is an internal slot for the installation of optional accessory cards. The extended run Smart-UPS XL has the capability to add external battery packs to scale runtime from minutes to hours typically needed for converged voice and data network power protection. The entry level Smart-UPS SC is an economical choice for small and medium businesses looking to protect small switches, networking devices and point-of-sale (POS) equipment.


Product Line:

Smart-UPS

Product Name:

Smart-UPS 3000VA Tower/Rack Mountable UPS

Product Type:

Line-interactive UPS
Interfaces/Ports

Serial Port:

Yes
Management

Alarm:

Low Battery

Network Management:

SNMP/HTTP Remote Monitoring
Miscellaneous

Certifications & Standards:
  • C-tick
  • CE
  • CSA
  • EN 50091-1
  • EN 50091-2
  • EN 55022 Class A
  • EN 60950
  • FCC Part 15 Class A
  • GOST
  • IRAM
  • UL 1778
  • VDE
  • UL 1449

Green Compliance Certificate/Authority:

REACH

RoHS

Green Compliant:

Yes

Package Contents:
  • Smart-UPS 3000VA Tower/Rack Mountable UPS
  • CD with Software
  • Rack Mounting Support Rails
  • Smart UPS Signalling RS-232 Cable
  • Temperature Probe
  • User Manual
  • Web/SNMP Management Card
Physical Characteristics

Colour:

Black

Depth:

483 mm

Form Factor:

Tower/Rack Mountable

Height:

432 mm

Rack Height:

4U


Weight (Approximate):

38.64 kg

Width:

178 mm
Power Description

Input Voltage:

208 V AC

230 V AC


Load Capacity (Va):

3000 VA


Load Capacity (Watt):

2700 W

Output Voltage:

230 V AC

Surge Energy Rating:

645 J

Waveform Type:

Sine Wave
Technical Information

Cord Length:

2.44 m

Emergency Power OFF:

Yes

Plug/Connector Type:

British BS1363A

IEC 60320 C20

SCHUKO CEE 7 EU1-16P

Protection Type:

AC Noise

Surge

Receptacles:

1 x IEC 60320 C19

2 x IEC Jumper

8 x IEC 60320 C13
Warranty

Limited Warranty:

3 Year
