Startech 2.5” to 3.5” SATA Aluminum Hard Drive Adapter Enclosure with SSD / HDD Height up to 12.5mm 25SAT35HDD

Features

(Pictures are For Illustration Purposes Only)

Startech

pdf brochure downloadDownload Brochure


Turn a 2.5” SATA HDD/SSD into a 3.5” SATA Drive


  • Supports 2.5" SSD/HDD up to 12.5mm in height


  • Standard 3.5" HDD mounting points


  • Support for SATA revision I/II/III (1.5/3.0/6.0 Gbps)


  • Tool-less installation


The 25SAT35HDD 2.5" to 3.5" hard drive adapter enclosure turns a 2.5" SATA hard drive (HDD) or solid state drive (SSD) into a 3.5" drive.


The adapter enclosure lets you substitute a 3.5" hard drive for a 2.5" SSD/HDD in any application that would typically require a 3.5" drive, such as desktop chassis, backplane, or docking station. The enclosure has the same dimensions as a standard 3.5" hard drive, including mounting points, and SATA connector locations.


With support for drives up to 12.5mm in height, and high-capacity SATA I/II/III drives (tested up to 1TB) this HDD adapter ensures compatibility with virtually any 2.5" SATA hard drive or solid state drive.


The 25SAT35HDD is backed by a StarTech.com 2-year warranty and free lifetime technical support.


The StarTech.com Advantage
  • Seamless 2.5" SSD/HDD integration with standard 3.5" hard drive dimensions
  • Maximum drive compatibility with support for SSDs/HDDs up to 12.5mm in height
  • Improve the performance speed of any 3.5" hard drive application by adapting a 2.5in solid state drive

Applications
  • Replace your 3.5" hard drives with same-size SSDs
  • Install a 2.5" SATA HDD/SSD into any 3.5" hard drive bay, such as a desktop chassis, backplane kit, or docking station
  • Repurpose unused laptop hard drives to work with your desktop computer, or as a hot-swap storage solution

Warranty Information

Warranty

2 Years

Hardware

Drive Installation

Removable

Drive Size

2.5in

Interface

SATA

Number of 2.5 inch bays

1

Number of Drives

1

Performance

Max Drive Capacity

Currently tested with up to 1TB 7200 RPM hard drives

Type and Rate

SATA III (6 Gbps)

Connector(s)

Drive Connectors

1 - SATA Data & Power Combo (7+15 pin)

Host Connectors

1 - SATA Data & Power Combo (7+15 pin)

Environmental

Humidity

5% - 85% RH

Operating Temperature

5°C to 55°C (32°F to 131°F)

Storage Temperature

5°C to 55°C (32°F to 131°F)

Physical Characteristics

Enclosure Type

Aluminum and Plastic

Max Drive Height

0.5 in [12.5 mm]

Product Height

1.4 in [36 mm]

Product Length

5.7 in [146 mm]

Product Weight

9.2 oz [260 g]

Product Width

4 in [101.5 mm]

Packaging Information

Shipping (Package) Weight

0.6 lb [0.3 kg]

What's in the Box

Included in Package

1 - 2.5” to 3.5” SATA HDD/SSD Enclosure

1 - Screw kit

1 - Install Guide



2.5 to 3.5 SATA Aluminum Hard Drive Adapter Enclosure with SSD/HDD Height up to 12.5mm - 2.5 to 3.5 SATA SSD/HDD Converter with Mounting points - SATA 2.5 SSD to 3.5 HDD


Brand Name: StarTech.com
Compatible Drive Bay Width: 3.5"
Drive Interface: Serial ATA/600
Form Factor: Internal
Number of 1.8" Bays: No
Number of 2.5" Bays: 1
Number of 2.5"/3.5" Bays: No
Number of 3.5" Bays: No
Number of 5.25" Bays: No
Number of Total Expansion Bays: 1
Product Type: Drive Bay Adapter
Wireless LAN: No


Basic

Brand Name:

StarTech.com

Compatible Drive Bay Width:

3.5"

Drive Interface:

Serial ATA/600

Form Factor:

Internal

Number of 1.8" Bays:

No

Number of 2.5" Bays:

1

Number of 2.5"/3.5" Bays:

No

Number of 3.5" Bays:

No

Number of 5.25" Bays:

No

Number of Total Expansion Bays:

1

Product Type:

Drive Bay Adapter

Wireless LAN:

No
General Information

Brand Name:

StarTech.com

Manufacturer Part Number:

25SAT35HDD

Manufacturer Website Address:
http://www.startech.com/au

Manufacturer:

StarTech.com

Packaged Quantity:

1

Product Name:

2.5" to 3.5" SATA HDD/SSD Enclosure

Product Type:

Drive Bay Adapter
I/O Expansions

Number of 1.8" Bays:

No

Number of 2.5" Bays:

1

Number of 2.5"/3.5" Bays:

No

Number of 3.5" Bays:

No

Number of 5.25" Bays:

No

Number of Total Expansion Bays:

1
Interfaces/Ports

Drive Interface:

Serial ATA/600
Miscellaneous

Certifications & Standards:
  • CE
  • FCC

Environmentally Friendly:

Yes
Network & Communication

Wireless LAN:

No
Physical Characteristics

Compatible Drive Bay Width:

3.5"

Depth:

101.5 mm

Form Factor:

Internal

Height:

25.5 mm

Material:

Aluminium

Plastic

Weight (Approximate):

216 g

Width:

47.5 mm
