Startech 1 Port PCI Express PCIe Gigabit Network Server Adapter NIC Card - Dual Profile ST1000SPEX2

Features

Startech

pdf brochure downloadDownload Brochure


Add a 10/100/1000Mbps Ethernet port to any PC through a PCI Express slot


  • A single 10/100/1000Mbps compatible RJ45 Ethernet port


  • Gigabit detection and Link/Activity LED indicators


  • Fully Compliant with IEEE 802.3, IEEE 802.3u, IEEE 802.3x and IEEE 802.3ab standards


The ST1000SPEX2 PCIe Gigabit Ethernet Network Card adds a 10/100/1000 Mbps compatible RJ45 Ethernet port to a PCI Express-enabled client, server or workstation, providing a convenient addition or replacement networking interface.


Compliant with IEEE 802.3/u/ab standards, and with support for 9K Jumbo Frames, VLAN tagging and Wake on LAN (WOL), this versatile Gigabit NIC/Server Adapter delivers rock-solid performance.


Plus, the card includes both full profile and low profile/half-height installation brackets for installation in a wide range of computer/server chassis, regardless of form factor.


The ST1000SPEX2 network card is backed by a 2-year StarTech.com warranty and free lifetime technical support.


The StarTech.com Advantage
  • Fits into full-size or low profile/small form factor (SFF) systems, with the addition of a half-height bracket
  • Offers performance flexibility and easy setup with support for advanced features such as Jumbo Frames, Wake-On-LAN and Auto MDIX

Applications
  • Upgrade 10/100 Ethernet capability to Gigabit capability
  • Add an Ethernet port to a workstation or server computer, for redundancy or bridging
  • Add networking capabilities to an old system with no Ethernet port

Warranty Information

Warranty

2 Years

Hardware

Bus Type

PCI Express

Card Type

Standard Profile (LP bracket incl.)

Chipset ID

Realtek RTL8111E

Industry Standards

IEEE 802.3, IEEE 802.3u, IEEE 802.3x, IEEE 802.3ab

Interface

RJ45 (Gigabit Ethernet)

Ports

1

Performance

Auto MDIX

Yes

Compatible Networks

10/100/1000 Mbps

Full Duplex Support

Yes

Jumbo Frame Support

9K max.

Maximum Data Transfer Rate

1000 Mbps

MTBF

376,212 Hours

Promiscuous Mode

Yes

Supported Protocols

CSMA/CD

Connector(s)

Connector Type(s)

1 - PCI Express x1 Male

External Ports

1 - RJ-45 Female

Software

OS Compatibility

Windows® 2000, XP, Vista, 7, 8, 8.1, 10

Windows Server® 2003, 2008 R2, 2012, 2012 R2, 2016

Mac OS X® 10.6 to 10.9
Linux 2.4.x to 4.4.x LTS Versions Only

Special Notes / Requirements

System and Cable Requirements

Available PCI Express expansion card slot

Indicators

LED Indicators

1 - Gigabit Detect (Yellow)

1 - Link/Activity (Green)

Environmental

Humidity

10% ~ 90% RH

Operating Temperature

0°C to 70°C (32°F to 158°F)

Storage Temperature

0°C to 100°C (32°F to 212°F)

Physical Characteristics

Product Height

0.7 in [18 mm]

Product Length

2.7 in [67.9 mm]

Product Weight

1.4 oz [40 g]

Product Width

4.7 in [120.3 mm]

Packaging Information

Shipping (Package) Weight

4.2 oz [120 g]

What's in the Box

Included in Package

1 - Gigabit Ethernet PCI Express Card

1 - Low Profile Bracket

1 - Driver CD

1 - Instruction Manual



1 Port PCIe Gigabit Network Server Adapter NIC Card - Dual Profile - PCI Express Gigabit Desktop Adapter REV E Intel 6 Chip support


Brand Name: StarTech.com
Device Supported: PC
Form Factor: Plug-in Card
Host Interface: PCI Express x1
Network Technology: 10/100/1000Base-T
Number of Network (RJ-45) Ports: 1
Product Type: Gigabit Ethernet Card
Total Number of Ports: 1


Basic

Brand Name:

StarTech.com

Device Supported:

PC

Form Factor:

Plug-in Card

Host Interface:

PCI Express x1

Network Technology:

10/100/1000Base-T

Number of Network (RJ-45) Ports:

1

Product Type:

Gigabit Ethernet Card

Total Number of Ports:

1
Drive Performance

Data Transfer Rate:

128 MB/s
General Information

Brand Name:

StarTech.com

Manufacturer Part Number:

ST1000SPEX2

Manufacturer Website Address:
http://www.startech.com/au

Manufacturer:

StarTech.com

Package Contents:
  • 1 Port PCI Express PCIe Gigabit Network Server Adapter NIC Card - Dual Profile
  • 1 x Low Profile Bracket
  • 1 x Driver CD
  • 1 x Instruction Manual

Product Name:

1 Port PCI Express PCIe Gigabit Network Server Adapter NIC Card - Dual Profile

Product Type:

Gigabit Ethernet Card
Input Devices

Data Transfer Rate:

128 MB/s
Interfaces/Ports

Ethernet AUI:

No

Host Interface:

PCI Express x1

InfiniBand:

No

Network (RJ-45):

Yes

Number of Network (RJ-45) Ports:

1

PoE (RJ-45) Port:

No

Serial Port:

No

Total Number of Ports:

1

USB:

No

XJACK:

No
Media & Performance

Data Transfer Rate:

128 MB/s

Media Type Supported:

Twisted Pair

Network Technology:

10/100/1000Base-T
Miscellaneous

Certifications & Standards:
  • CE
  • FCC


IEEE Standards:

  • 802.3
  • 802.3u
  • 802.3x
  • 802.3ab
  • 802.1q
  • 802.1p

Device Supported:

PC

Form Factor:

Plug-in Card

Green Compliance Certificate/Authority:

RoHS

Green Compliant:

Yes

Package Contents:
  • 1 Port PCI Express PCIe Gigabit Network Server Adapter NIC Card - Dual Profile
  • 1 x Low Profile Bracket
  • 1 x Driver CD
  • 1 x Instruction Manual

Platform Supported:

PC

System Requirements:

Windows 10
Network & Communication

InfiniBand:

No

Network Technology:

10/100/1000Base-T
Network

Network Technology:

10/100/1000Base-T
Physical Characteristics

Card Height:

Full-height

Form Factor:

Plug-in Card

Height:

80 mm

Platform Supported:

PC

Thickness:

20 mm

Weight (Approximate):

36 g

Width:

120 mm
Power Description

PoE (RJ-45) Port:

No
Product Information

Device Supported:

PC

Form Factor:

Plug-in Card

Platform Supported:

PC

Thickness:

20 mm

Width:

120 mm
Storage

Data Transfer Rate:

128 MB/s
Technical Information

Data Transfer Rate:

128 MB/s

Device Supported:

PC

Host Interface:

PCI Express x1

Media Type Supported:

Twisted Pair

Number of Network (RJ-45) Ports:

1

Platform Supported:

PC

USB:

No
Warranty

Limited Warranty:

2 Year
