Startech 2.5in SATA/SAS SSD/HDD to 3.5in SATA Hard Drive Converter 25SATSAS35

Features

Startech

pdf brochure downloadDownload Brochure


Turn Virtually any 2.5" SATA or SAS Hard Drive into a 3.5" SATA Drive


  • Trayless design: hard drives are not mounted into separate trays/enclosures


  • Supports 2.5" form factor hard drives (HDD) and solid state drives (SSD) up to 15mm in height


  • Power indicator LED


The 25SATSAS35 2.5-inch SATA/SAS to 3.5-inch SATA Hard Drive Converter converts a 2.5-inch SATA or SAS hard drive (HDD) or solid state drive (SSD) into a 3.5-inch form factor SATA Hard Drive.


The converter provides a versatile solution for 2.5-inch drive installations, enabling you to install a 2.5-inch SATA/SAS drive in a 3.5-inch bay, drive drawer caddy/tray, or into a 3.5-inch drive enclosure.


To maximize performance and utilize the full speed potential of your SATA III hard drives, this HDD Backplane supports SATA III for transfer speeds up to 6 Gbps when paired with compatible controller.


Suitable for drives with a height of up to 15mm, virtually any 2.5-inch SATA or SAS hard drive can be made to look and function like a 3.5-inch hard drive. The drive converter includes mounting holes along the side and base, allowing you to mount the drive if needed, into a compatible system.


The Drive Converter features a trayless design for simple drive installation and removal, and is constructed of durable, yet lightweight plastics, with ventilation openings to aid air flow and help keep hard drives running cooler.


Backed by a StarTech.com 2-year warranty and free lifetime technical support.


The StarTech.com Advantage
  • A trayless design and support for 15mm drives enables quick and easy install/removal of drives, including newer high capacity drives
  • Includes mounting holes on the side and base, providing compatibility with some OEM branded systems, such as Dell
  • Can be mounted into a 3.5" front bay as a 2.5" HDD Mobile Rack or treated as a regular 3.5" hard drive
  • Maximize performance, with file transfer speeds up to 6Gbps when paired with SATA III HDD and controller

Applications
  • Use available 2.5" hard drives in place of a 3.5" hard drive
  • Install a 2.5" hard drive into a 3.5" hard drive enclosure or backplane
  • Turn unused 2.5" hard drives into additional storage in a desktop computer
  • Use large capacity 12.5mm SATA drives as a front bay removable drive

Warranty Information

Warranty

2 Years

Hardware

Compatible Drive Types

SAS & SATA

Drive Installation

Removable

Drive Size

2.5in

Fan(s)

No

Key Lock

No

Number of 2.5 inch bays

1

Number of Drives

1

Performance

RAID

No

Temperature Alarm

No

Connector(s)

Drive Connectors

1 - SFF-8482 (29 pin, Data & Power, Internal SAS) Receptacle

Host Connectors

1 - SATA Data & Power Combo (7+15 pin) Plug

Special Notes / Requirements

Note

Although mobile racks can enable a Serial Attached SCSI (SAS) drive to connect using a standard Serial ATA (SATA) connector, the hard drive controller must be SAS compatible to properly support SAS drives. SAS controllers can work with SAS and SATA drives, but most SAS drives will only work with a SAS controller.

Physical Characteristics

Color

Black

Enclosure Type

Plastic

Max Drive Height

0.6 in [15 mm]

Product Height

1 in [25 mm]

Product Length

5.7 in [145 mm]

Product Weight

4.9 oz [140 g]

Product Width

3.9 in [100 mm]

Packaging Information

Package Quantity

1

Shipping (Package) Weight

7 oz [199 g]

What's in the Box

Included in Package

1 - 2.5" to 3.5" HDD Converter



2.5in SATA/SAS SSD/HDD to 3.5in SATA Hard Drive Converter


Brand Name: StarTech.com
Colour: Black
Compatible Drive Bay Width: 3.5"
Drive Interface: Serial ATA/600
Form Factor: Internal
Number of 1.8" Bays: No
Number of 2.5" Bays: 1
Number of 2.5"/3.5" Bays: No
Number of 3.5" Bays: No
Number of 5.25" Bays: No
Number of Total Expansion Bays: 1
Product Type: Drive Bay Adapter


Basic

Brand Name:

StarTech.com

Colour:

Black

Compatible Drive Bay Width:

3.5"

Drive Interface:

Serial ATA/600

Form Factor:

Internal

Number of 1.8" Bays:

No

Number of 2.5" Bays:

1

Number of 2.5"/3.5" Bays:

No

Number of 3.5" Bays:

No

Number of 5.25" Bays:

No

Number of Total Expansion Bays:

1

Product Type:

Drive Bay Adapter
Bays

Number of Total Expansion Bays:

1
General Information

Brand Name:

StarTech.com

Manufacturer Part Number:

25SATSAS35

Manufacturer Website Address:
http://www.startech.com/au

Manufacturer:

StarTech.com

Packaged Quantity:

1

Product Name:

2.5in SATA/SAS SSD/HDD to 3.5in SATA Hard Drive Converter

Product Type:

Drive Bay Adapter
I/O Expansions

Number of 1.8" Bays:

No

Number of 2.5" Bays:

1

Number of 2.5"/3.5" Bays:

No

Number of 3.5" Bays:

No

Number of 5.25" Bays:

No

Number of Total Expansion Bays:

1
Interfaces/Ports

Drive Interface:

6Gb/s SAS

Serial ATA/600
Miscellaneous

Additional Information:
  • A trayless design and support for 15mm drives enables quick and easy install/removal of drives, including newer high capacity drives
  • Uses standard 3.5" form factor mounting points, along with 3 mounting points on the sides, for compatibility with some OEM branded systems, such as Dell
  • Can be mounted into a 3.5" front bay as a 2.5" HDD Mobile Rack or treated as a regular 3.5" hard drive

Certifications & Standards:
  • FCC
  • CE

Form Factor:

Internal

Green Compliance Certificate/Authority:

RoHS

Green Compliant:

Yes
Physical Characteristics

Colour:

Black

Compatible Drive Bay Width:

3.5"

Cooling Fan:

No

Depth:

146 mm

Form Factor:

Internal

Height:

25 mm

Material:

Plastic

Weight (Approximate):

135 g

Width:

101 mm
Product Information

Form Factor:

Internal

Packaged Quantity:

1

Width:

101 mm
Technical Information

Cooling Fan:

No
Warranty

Limited Warranty:

2 Year
