Rii Mini - Bluetooth Wireless Keyboard with Touch Pad Combo Black - Laser Pointer - Works with iPad RT-MWK02

This item has been tagged as:

New Addition

Information

Item ID

277553

Item Number

KM-MWK02

Manufacturer Part No

RT-MWK02

UPC/EAN Number

Our Stock **

Und5

Price

$59.97

Quantity

QR 2D barcode
Product link	.: No link
Manufacturer's link	.: Riitek
Related Product(s)
Review Link(s)

** This is the stock level in our warehouse.
** Please check Stock Information below for out of stock items.

Stock Information

	Our Qty in Stock	Availability and ETA
Our own stock	Und5
	Supplier's Qty in Stock	Availability and ETA	Updated
Supplier one	17		25/05/12 10:31PM

Features

Download Brochure

Black colour Unique, Compact, Elegant All Compatible One Month per Charge

Feature:
Unique, Compact, Elegant All Compatible One Month per Charge •Backlight function with a handy keypad •Laser-pointer with remote control •Micro Bluetooth receiver included •Innovative design of the Navigation keys •Smart statues indicators •QWERT full-function mini keyboard •Windows Multimedia Control •Built-in rechargeable lithium-ion battery •Use up to 1 month per charge via USB •Integrated Touchpad and navigation buttons •Touchpad 90-degree flip capacity

System Requirements:
•iPad,iPhone (iOS 4.0 BT-enabled) •Microsoft Windows Mobile OS(6.0+) •Google Android OS •Symbian S60 OS •Windows XP/Vista/Win 7 •Mac OS •Linux OS •PS3, Xbox

1: Size

1.1: Keyboard size: 152mm * 59mm*12.5m

1.2: Giftbox size: 190mm*95mm*45mm

1.3: Carton size: 500mm*400mm*270

2: Weight

2.1: Keyboard weight: 105g

2.2: Giftbox weight: 250G

2.3: Carton weight: 13.6KG

3:
General Specifications for Quality Assurance Test Standard

3.1: Function Check

Check Method:
Visible part(indicators,etc), operation, function and internal set must be checked.

Standard:

A: Quality Assurance Test Standard must be satisfied.

B: There must not be possibility of defect which is caused by parts touch, etc.

3.2: Legibility

Check Method:
A person with an eyesight of 0.8 observe a set at a 30 degree angle surface,with the indication illuminated by 500lx.

Standard:

A: indications need to check for spread,offset,contamination, clarity.

B: External function indications must be legible at a distance of 50cm

C:
Function and explanation indication internal cover must be legible at a distance of 30cm.

3.3:
Key Top`s Operation Key switch operating parameters should comply with those listed below. The force /displacement curve should not exhibit any significant step of plateau from P2 to the end of full travel. Linear measure are in mm and the valuse represent the force and displacemnent of a key switch after it has been preloaded by 10 to 20 grams.

Check Point:

A:
Operating feeling: No definite stickiness or other abnormality shall be allowed. When force is applied with a finger on the key top center at the rate of three times a second.

B:
Key top pulling strength: A key top should come off after applying a force of 0.5kg to 8kg range in the vertical direction.

3.4: Low Temperature Test

Check Method: Leave for 96 hours under -25℃

Standard: The keyboard operates normally after the test.

3.5: High Temperature Test

Check Method: Leave for 96 hours under +55℃

Standard: The keyboard operates normally after the test.

3.6: Humidity test

Standard:
Measurement after the test wth following conditions and lefts in chamber(normal temp, normal humidity) for 24hours.

A: Temperature: +50℃ +/- 2℃

B: Relative humidity: 90 to 95%

C: Time: 72hours

D: Dew condensation shall be removed

3.7: Heat Cycle Test

Check Method: By the condition shown in the figure below, repeat heat cycle

Test For 5 Times:

1. Temperature (2�): 25 – 55 – 55 - -20 - -20 25

2. Humidity( %rh): 50 – 90 – 90 – 0 – 0 – 50

3. Time(Hr): 0 – 1 – 2 – 1.5 – 2 – 1

3.8: Drop Test

Check Method:
The package carton, on the condition of 75cm height, after 1 corner, edges, and 6 faces dropping, electrical and mechanical characers will be in normal conditions.

Standard: When the test is finished, followings must be satisfied.

A: All functions operate normally.

B: There is no serious cosmetic damage.

3.9: Vibration Test

Check Method:

A: Frequency: 10 ~ 50HZ

B: Amplitude: 0.5mm

C: Duration: 2 hours in each direction of X,Y,Z axis

Standard:
When the test is finished, all functions must operates normally.

3.10: Rubber eraser

Standard:

Material: lion#510 or HINODEWASHI #502

Speed: 30 times/min

Stroke: 12mm

Force: 1000gf

Judgment: character shall be legible and have no crack on 200 rounds.

3.11: Key switch life:

Check Method:

A: 10,000,000cycles

B:
Keyboard is qualified using Hasco pneumatic life tester using soft cushion actuator with a 4 cycles/second actuation speed 120 ~ 150gf air pressure.

Standard:
When test is finished, there must be no problem in opration.

3.12: Key top alignment

Standard:

A:
Shift of key tops: less than 0.5mm for full amplitude on both X and Y directions.

B:
Angle twist of key top: The twist of the keytops shall be less than 0.5mm.

C:
Slant: The slant of the keycaps shall be less than 0.5mm from neighboring keycaps in the same row.

D: Line diversity: It shall be less than 0.5mm from neighboring keycaps.

E: Gap between keycaps: More than 0.2mm

4:
Electrical specification The Rii mini wireless keyboard conists of thress major parts: a MCU, a bluetooth module, and a low power UC-Controlled, includes RF antenna supporting circuitry.

4.1:
Range in meters: 10 meter(MAX), without signal disturbance and no direction limit.

4.2: Operational voltage: 3.3V, less than 3.12V,Green LED flicker.

4.3: Power consumption:

A: Operation modes: 55mA(max)

B: sleep modes: about 11mA

Notice:
After 3 minutes without any operating will into sleep mode, press any key about 1s to wakeup.

5: Electronic Characteristics

5.1: Frequency Range: 2.400GHZ ~ 2.483GHZ

5.2: Modulation: GFSK

5.3: Channel: 83channels

5.4: Charge Voltage: 4.4V ~ 5.25V

5.5: TX Power: less than +4dBm

5.6: Transmission rate: 1M bit/sec

5.7: Frequency tolerance: +/-30ppm

5.8:
Direction angle and distance: The product shall meet the mini
mumdistance of 20 meter, and operate in almost every direction.

Click to view full size

Click to view full size

Click to view full size

(Pictures are For Illustration Purposes Only)

Associated Products

Type	Item Number (item id)	Item description		Our Stock	Price inc GST	Qty	Buy
White colour	KM-MWK02-White (id: 280081)	Rii Mini - Bluetooth Wireless Keyboard with Touch Pad Combo White - Laser Pointer - Works with iPad RT-MWK02W		Und5	$61.25
