P' Clip Nylon 9.5MM Cable PK 100 PCN-9



Information
Item ID.:257539
Item Number.:G-PCN-9
Manufacturer Part No.:PCN-9
UPC/EAN Number.:9318674628040
Our Stock **.: 1-3days*
Price.:
$17.42
Quantity .:
QR 2D barcode To bookmark with mobile device
Product link.: No link
Manufacturer's link .: Cabac
Related Product(s)
Review Link(s)
* Indication only, please consult the supplier stock level below.
** This is the stock level in our warehouse.
** Please check Stock Information below for out of stock items.

Stock and Freight Information

Stock Information
 Our Qty in StockAvailability and ETA
Our own stock0Usually 1-3 days (when supplier has stock)
 Supplier's Qty in StockAvailability and ETAUpdated
Supplier one
29826/05/12 10:30PM

Features
Cabac

pdf brochure downloadDownload Brochure


P Clips

Cabac "P" clips provide an economical and secure way to mount cables and looms to just about anything. The cable, loom etc is simply slipped in to the clip and then the clip can be screwed or bolted to walls, cabinets etc. They are made from Nylon 66 and are very durable in most applications. The edges are radiused to stop the clip damaging the cable. Available in black or natural.

Catalogue
No.
Dimensions(mm) Standard
Pack
Max Cable
Dia.A
Width
B
Mount
C
D E F
Black range
PCBK-3 3.2 9.6 5.0 9.5 19.8 1.4 100
PCBK-5 4.8 9.6 4.6 10.5 19.8 1.4
PCBK-6 6.4 10 5.0 12.0 22.0 1.4
PCBK-8 7.9 10 4.6 12.0 22.0 1.5
PCBK-9 9.5 12 4.6 15.2 24.0 1.5
PCBK-12 12.7 12 4.6 12.5 31.0 1.5 50
PCBK-16 15.8 12 4.6 18.2 34.3 1.5
PCBK-20 19.4 12 4.6 18.2 35.0 1.5 25
PCBK-25 25.4 12 4.6 22.0 43.0 1.8
Natural Range
PCN-3 3.2 9.6 5.0 9.5 19.8 1.4 100
PCN-5 4.8 9.6 4.6 10.5 19.8 1.4
PCN-6 6.4 10 5.0 12.0 22.0 1.4
PCN-8 7.9 10 4.6 12.0 22.0 1.5
PCN-9 9.5 12 4.6 15.2 24.0 1.5
PCN-12 12.7 12 4.6 12.5 31.0 1.5 50

Technical data

Material

Nylon 66 94V-2 UL approved

Colour

Black or natural

Operating temperature


-400C to 900C

(Pictures are For Illustration Purposes Only)
