Sunix PCI Express 2 Port Parallel Card - Low Profile PAR4418AL

Information

Item ID

254062

Item Number

I-PAR4418AL

Manufacturer Part No

PAR4418AL

UPC/EAN Number

Our Stock **

1-3days*

Price

$87.35

Quantity

QR 2D barcode
Product link	.: Product
Manufacturer's link	.: Sunix
Related Product(s)
Review Link(s)

* Indication only, please consult the supplier stock level below.
** This is the stock level in our warehouse.
** Please check Stock Information below for out of stock items.

Stock Information

	Our Qty in Stock	Availability and ETA
Our own stock	0	Usually 1-3 days (when supplier has stock)
	Supplier's Qty in Stock	Availability and ETA	Updated
Supplier one	7		25/05/12 10:31PM

Features

Introduction

UNIX PAR4418AL PCI Express and PCI interface IEEE1284 Parallel communication boards meet the PCI Express Base Specification Revision 1.1 specification. SUNIX PAR4418A is compatible with PCI Express x1, x2, x4, x8 and x16 lane and PCI/PCI-x Bus. The majority of today’s motherboards is not equipped with any RS-232 or parallel port. With SUNIX PAR4418AL IEEE1284 Parallel board, users can expand 2 parallel ports to their system, allowing them to use parallel devices further. SUNIX PAR4418AL built-in SUNIX high performance and realizable single controller, and as well built with many of SUNIX advanced features and technologies, making it the advanced and high efficient solution for commercial and industrial automation application.

Features

High reliability SUNIX chipset designed ASIC SUN1888.

Expands two IEEE1284 Parallel ports on system.

Full single-lane (or x1) PCI Express throughput.

Designed to meet PCI Express Base Specification Revision 1.1.

Support IEEE 1284-1994 parallel port standard
• ECP (Enhance Capacity Port) / EPP (Enhance Parallel Port)
• SPP (Standard Parallel Port) / BPP (Bi-direction Parallel Port).

Plug-n-Play, I/O address and IRQ assigned by system.

Certified by CE, FCC, RoHS approval.

Specifications

Description

Product Description	2 ports IEEE1284 Parallel PCI Low Profile Express Board
Controller	SUN1888 16C650 UART Compatible)
Bus Interface	PCI Express one lane (x1)
IRQ & IO	Assigned by System
PCB connector	DB9 Male & 2 x 13 Pin Header

Parallel Communication

Interface	IEEE1284
No. of Port	2-Port
Connector	DB25 Female
Mode	SPP/ECP/EPP/BPP(PS2)
Speed	Maximum 2.7MBps
FIFO	16 byte (Hardware)

Driver Support

Microsoft	3.1/95/98/NT/ME/2000/XP/2003/Vista (32/64 bit)/CE5.0/XP Embedded
Linux	Linux 2.4.x / 2.6.x
DOS	DOS

Regulatory Approvals

Hardware	EN55022 Class B, EN55024, EN61000-3-2, EN61000-3-3, FCC Part 15 Class B, RoHS
Software	Microsoft WHQL Window XP

Environment

Operating Temperature	0 to 60 °C ( 32 to 140 °F )
Operating Humidity	5% to 95% RH
Storage Temperature	-20 to 85 °C ( -4 to 185 °F )

Connection Cable

Cable

Pin Header to DB25F Connector Bracket Set

Dimension(Unit = mm)

PCB Dimension	120 x 70
Bracket	Standard 121 / Low profile 79.5

Click to view full size

Click to view full size

(Pictures are For Illustration Purposes Only)
